variable speed drive ATV61 - 75kW 100HP - 200...240V - IP20
ATV61HD75M3X
Compare
Discontinued on:
23 January 2021
Recommended replacement(s)
ATV61HD75M3X is replaced by:
1×
ATV630D75M3 Product picture Schneider Electric
variable speed drive ATV630 - 75kW/100HP - 200...240V - IP00
ATV630D75M3
Contact Sales
Subscribe to the newsletter
Main documents
Documents
Product Datasheet
User guide
Instruction sheet
Catalogue
CAD Document
See all documents
Specifications
Main
Range of product
Altivar 61
Product or component type
Variable speed drive
Product specific application
Pumping and ventilation machine
Component name
ATV61
Motor power kW
75 kW, 3 phases at 200...240 V
Motor power hp
100 hp, 3 phases at 200...240 V
power supply voltage
200...240 V - 15...10 %
supply number of phases
3 phases
Line current
232 A for 240 V 3 phases 75 kW / 100 hp
271 A for 200 V 3 phases 75 kW / 100 hp
EMC filter
Without EMC filter
Assembly style
With heat sink
Apparent power
96.4 kVA at 240 V 3 phases 75 kW / 100 hp
maximum prospective line Isc
35 kA for 3 phases
Maximum transient current
342 A for 60 s, 3 phases
Nominal switching frequency
2.5 kHz
Switching frequency
2.5...8 kHz with derating factor
2.5...8 kHz adjustable
asynchronous motor control
Voltage/frequency ratio - Energy Saving, quadratic U/f
Voltage/frequency ratio, 5 points
Voltage/frequency ratio, 2 points
Flux vector control without sensor, standard
Synchronous motor control profile
Vector control without sensor, standard
Communication port protocol
Modbus
CANopen
Type of polarization
No impedance for Modbus
Option card
Communication card for APOGEE FLN
Communication card for BACnet
Communication card for CC-Link
Controller inside programmable card
Communication card for DeviceNet
Communication card for EtherNet/IP
Communication card for Fipio
I/O extension card
Communication card for Interbus-S
Communication card for LonWorks
Communication card for METASYS N2
Communication card for Modbus Plus
Communication card for Modbus TCP
Communication card for Modbus/Uni-Telway
Multi-pump card
Communication card for Profibus DP
Communication card for Profibus DP V1
Complementary
Product destination
Synchronous motors
Asynchronous motors
power supply voltage limits
170…264 V
power supply frequency
50...60 Hz - 5...5 %
power supply frequency limits
47.5...63 Hz
Continuous output current
285 A at 2.5 kHz, 230 V - 3 phases
Output frequency
0.1…500 Hz
Speed range
1…100 in open-loop mode, without speed feedback
Speed accuracy
+/- 10 % of nominal slip 0.2 Tn to Tn without speed feedback
Torque accuracy
+/- 15 % in open-loop mode, without speed feedback
Transient overtorque
130 % of nominal motor torque +/- 10 % for 60 s
Braking torque
<= 125 % with braking resistor
30 % without braking resistor
Regulation loop
Frequency PI regulator
Motor slip compensation
Automatic whatever the load
Adjustable
Can be suppressed
Not available in voltage/frequency ratio (2 or 5 points)
diagnostic
1 LED (red) for drive voltage
Output voltage
<= power supply voltage
electrical isolation
Between power and control terminals
type of cable for mounting in an enclosure
With an IP21 or an IP31 kit: 3 wire(s)IEC cable at 40 °C, copper 70 °C / PVC
With UL Type 1 kit: 3 wire(s)UL 508 cable at 40 °C, copper 75 °C / PVC
Without mounting kit: 1 wire(s)IEC cable at 45 °C, copper 70 °C / PVC
Without mounting kit: 1 wire(s)IEC cable at 45 °C, copper 90 °C / XLPE/EPR
Electrical connection
Terminal 2.5 mm² / AWG 14 (AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
Terminal 2 x 100 mm² / 2 x 250 kcmil (L1/R, L2/S, L3/T, U/T1, V/T2, W/T3)
Terminal 60 mm² / 250 kcmil (PA, PB)
Terminal 2 x 100 mm² / 2 x 250 kcmil (PC/-, PO, PA/+)
Tightening torque
0.6 N.m (AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
24 N.m, 212 lb.in (L1/R, L2/S, L3/T, U/T1, V/T2, W/T3)
41 N.m, 360 lb.in (PC/-, PO, PA/+)
12 N.m, 106 lb.in (PA, PB)
Supply
Internal supply for reference potentiometer (1 to 10 kOhm): 10.5 V DC, +/- 5 %, <10 mA with overload and short-circuit protection
Internal supply: 24 V DC (21…27 V), <200 mA with overload and short-circuit protection
External supply: 24 V DC (19…30 V)
Analogue input number
2
Analogue input type
AI1-/Al1+ bipolar differential voltage: +/- 10 V DC 24 V max, resolution 11 bits + sign
AI2 software-configurable current: 0...20 mA, impedance: 242 Ohm, resolution 11 bits
AI2 software-configurable voltage: 0...10 V DC 24 V max, impedance: 30000 Ohm, resolution 11 bits
sampling time
2 ms +/- 0.5 ms (AI1-/Al1+) - analog input
2 ms +/- 0.5 ms (Al2) - analog input
2 ms +/- 0.5 ms (AO1) - analog output
2 ms +/- 0.5 ms (LI1...LI5) - discrete input
2 ms +/- 0.5 ms (LI6)if configured as logic input - discrete input
absolute accuracy precision
+/- 0.6 % (AI1-/Al1+) for a temperature variation 60 °C
+/- 0.6 % (AI2) for a temperature variation 60 °C
+/- 1 % (AO1) for a temperature variation 60 °C
Linearity error
+/- 0.15 % of maximum value (AI1-/Al1+)
+/- 0.15 % of maximum value (AI2)
+/- 0.2 % (AO1)
Analogue output number
1
Analogue output type
AO1 software-configurable current, analogue output range 0...20 mA, impedance: 500 Ohm, resolution 10 bits
AO1 software-configurable voltage, analogue output range 0...10 V DC, impedance: 470 Ohm, resolution 10 bits
AO1 software-configurable logic output 10 V, 20 mA
Discrete output number
2
Discrete output type
Configurable relay logic: (R1A, R1B, R1C) NO/NC - 100000 cycles
Configurable relay logic: (R2A, R2B) NO - 100000 cycles
maximum response time
<= 100 ms in STO (Safe Torque Off)
R1A, R1B, R1C <= 7 ms, tolerance +/- 0.5 ms
R2A, R2B <= 7 ms, tolerance +/- 0.5 ms
Minimum switching current
3 mA at 24 V DC for configurable relay logic
Maximum switching current
R1, R2: 2 A at 250 V AC inductive load, cos phi = 0.4 and L/R = 7 ms
R1, R2: 2 A at 30 V DC inductive load, cos phi = 0.4 and L/R = 7 ms
R1, R2: 5 A at 250 V AC resistive load, cos phi = 1 and L/R = 0 ms
R1, R2: 5 A at 30 V DC resistive load, cos phi = 1 and L/R = 0 ms
Discrete input number
7
Discrete input type
Programmable (LI1...LI5)24 V DC (<= 30 V), with level 1 PLC - 3500 Ohm
Switch-configurable (LI6)24 V DC (<= 30 V), with level 1 PLC - 3500 Ohm
Switch-configurable PTC probe (LI6)0…6 probes - 1500 Ohm
Safety input (PWR)24 V DC (<= 30 V) - 1500 Ohm
Discrete input logic
Negative logic (sink) (LI1...LI5), > 16 V (state 0), < 10 V (state 1)
Positive logic (source) (LI1...LI5), < 5 V (state 0), > 11 V (state 1)
Negative logic (sink) (LI6)if configured as logic input, > 16 V (state 0), < 10 V (state 1)
Positive logic (source) (LI6)if configured as logic input, < 5 V (state 0), > 11 V (state 1)
Acceleration and deceleration ramps
Linear adjustable separately from 0.01 to 9000 s
Automatic adaptation of ramp if braking capacity exceeded, by using resistor
S, U or customized
Braking to standstill
By DC injection
Protection type
Against exceeding limit speed: drive
Against input phase loss: drive
Break on the control circuit: drive
Input phase breaks: drive
Line supply overvoltage: drive
Line supply undervoltage: drive
Overcurrent between output phases and earth: drive
Overheating protection: drive
Overvoltages on the DC bus: drive
Power removal: drive
Short-circuit between motor phases: drive
Thermal protection: drive
Motor phase break: motor
Power removal: motor
Thermal protection: motor
Insulation resistance
> 1 mOhm 500 V DC for 1 minute to earth
Frequency resolution
Analog input: 0.024/50 Hz
Display unit: 0.1 Hz
Connector type
1 RJ45 (on front face) for Modbus
1 RJ45 (on terminal) for Modbus
Male SUB-D 9 on RJ45 for CANopen
Physical interface
2-wire RS 485 for Modbus
Transmission frame
RTU for Modbus
Transmission rate
4800 bps, 9600 bps, 19200 bps, 38.4 Kbps for Modbus on terminal
9600 bps, 19200 bps for Modbus on front face
20 kbps, 50 kbps, 125 kbps, 250 kbps, 500 kbps, 1 Mbps for CANopen
Data format
8 bits, 1 stop, even parity for Modbus on front face
8 bits, odd even or no configurable parity for Modbus on terminal
Number of addresses
1…127 for CANopen
1…247 for Modbus
Method of access
Slave CANopen
marking
CE
Operating position
Vertical +/- 10 degree
Product weight
84 kg
Width
320 mm
Height
920 mm
Depth
377 mm
Environment
Noise level
60.5 dB conforming to 86/188/EEC
Dielectric strength
2830 V DC between earth and power terminals
4230 V DC between control and power terminals
Electromagnetic compatibility
Conducted radio-frequency immunity test level 3 conforming to IEC 61000-4-6
Electrical fast transient/burst immunity test level 4 conforming to IEC 61000-4-4
Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2
Radiated radio-frequency electromagnetic field immunity test level 3 conforming to IEC 61000-4-3
Voltage dips and interruptions immunity test conforming to IEC 61000-4-11
standards
IEC 60721-3-3 class 3C2
UL Type 1
Product certifications
GOST
NOM 117
CSA
DNV
C-Tick
UL
Pollution degree
3 conforming to EN/IEC 61800-5-1
3 conforming to UL 840
degree of proctection
IP41 on upper part conforming to EN/IEC 60529
IP41 on upper part conforming to EN/IEC 61800-5-1
IP54 on lower part conforming to EN/IEC 60529
IP54 on lower part conforming to EN/IEC 61800-5-1
IP00 conforming to EN/IEC 60529
IP00 conforming to EN/IEC 61800-5-1
IP30 on side parts conforming to EN/IEC 60529
IP30 on side parts conforming to EN/IEC 61800-5-1
IP30 on the front panel conforming to EN/IEC 60529
IP30 on the front panel conforming to EN/IEC 61800-5-1
Vibration resistance
0.6 gn (f= 10…200 Hz) conforming to EN/IEC 60068-2-6
1.5 mm peak to peak (f= 3…10 Hz) conforming to EN/IEC 60068-2-6
Shock resistance
7 gn for 11 ms conforming to EN/IEC 60068-2-27
Relative humidity
5…95 % without condensation conforming to IEC 60068-2-3
5…95 % without dripping water conforming to IEC 60068-2-3
Ambient air temperature for operation
-10…50 °C (without derating)
50…60 °C (with derating factor)
Ambient air temperature for storage
-25…70 °C
Operating altitude
<= 1000 m without derating
1000...3000 m with current derating 1 % per 100 m
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
53.0 cm
Package 1 Width
41.5 cm
Package 1 Length
123.0 cm
Package 1 Weight
100.0 kg
Unit Type of Package 2
PAL
Number of Units in Package 2
1
Package 2 Height
85.0 cm
Package 2 Width
92.0 cm
Package 2 Length
135.0 cm
Package 2 Weight
101.0 kg
Contractual warranty
Warranty
18 months
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
Single-phase supply voltage: 200…240 V 50/60 Hz | ||||||
| 0.37 | 0.5 | 6.9 | 5.8 | 1.4 | 5 | 3 | 3.6 | ATV61H075M3 | 3.000 | |
| 0.75 | 1 | 12 | 9.9 | 2.4 | 5 | 4.8 | 5.7 | ATV61HU15M3 | 3.000 | |
| 1.5 | 2 | 18.2 | 15.7 | 3.7 | 5 | 8 | 9.6 | ATV61HU22M3 | 4.000 | |
| 2.2 | 3 | 25.9 | 22.1 | 5.3 | 5 | 11 | 13.2 | ATV61HU30M3 | 4.000 | |
| 3 | – | 25.9 | 22 | 5.3 | 5 | 13.7 | 16.4 | ATV61HU40M3 (3) | 4.000 | |
| 4 | 5 | 34.9 | 29.9 | 7 | 5 | 17.5 | 21 | ATV61HU55M3 (3) | 5.500 | |
| 5.5 | 7.5 | 47.3 | 40.1 | 9.5 | 22 | 27.5 | 33 | ATV61HU75M3 (3) | 7.000 |
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
| Three-phase supply voltage: 200…240 V 50/60 Hz | ||||||
0.75 | 1 | 6.1 | 5.3 | 2.2 | 5 | 4.8 | 5.7 | ATV61H075M3 | 3.000 |
1.5 | 2 | 11.3 | 9.6 | 4 | 5 | 8 | 9.6 | ATV61HU15M3 | 3.000 |
2.2 | 3 | 15 | 12.8 | 5.3 | 5 | 11 | 13.2 | ATV61HU22M3 | 4.000 |
3 | – | 19.3 | 16.4 | 6.8 | 5 | 13.7 | 16.4 | ATV61HU30M3 | 4.000 |
4 | 5 | 25.8 | 22.9 | 9.5 | 5 | 17.5 | 21 | ATV61HU40M3 | 4.000 |
5.5 | 7.5 | 35 | 30.8 | 12.8 | 22 | 27.5 | 33 | ATV61HU55M3 | 5.500 |
7.5 | 10 | 45 | 39.4 | 16.4 | 22 | 33 | 39.6 | ATV61HU75M3 | 7.000 |
11 | 15 | 53.3 | 45.8 | 19 | 22 | 54 | 64.8 | ATV61HD11M3X (4) | 22.000 |
15 | 20 | 71.7 | 61.6 | 25.6 | 22 | 66 | 79.2 | ATV61HD15M3X (4) | 22.000 |
18.5 | 25 | 77 | 69 | 28.7 | 22 | 75 | 90 | ATV61HD18M3X (4) | 30.000 |
22 | 30 | 88 | 80 | 33.3 | 22 | 88 | 105.6 | ATV61HD22M3X (4) | 30.000 |
30 | 40 | 124 | 110 | 45.7 | 22 | 120 | 144 | ATV61HD30M3X (4) | 37.000 |
37 | 50 | 141 | 127 | 52.8 | 22 | 144 | 172.8 | ATV61HD37M3X (4) | 37.000 |
45 | 60 | 167 | 147 | 61.1 | 22 | 176 | 211.2 | ATV61HD45M3X (4) | 37.000 |
55 | 75 | 200 | 173 | 71.9 | 35 | 221 | 265.2 | ATV61HD55M3X (4) | 84.000 |
75 | 100 | 271 | 232 | 96.4 | 35 | 285 | 342 | ATV61HD75M3X (4) | 84.000 |
90 | 125 | 336 | 288 | 119.7 | 35 | 359 | 431 | ATV61HD90M3X (4) | 106.000 |
IP 20 drives with integrated category C2 or C3 EMC filter | |||||
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent Max. power prospective line Isc 380 V
kVA kA | Maximum continuous current (1) | Max. transient Reference current for 60 s | Weight
kg |
380 V 480 V
A A | 380 V 460 V (IEC) (NEC) A A | ||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 3.7 | 3 | 2.4 | 5 | 2.3 | 2.1 | 2.7 | ATV61H075N4 | 3.000 |
| 1.5 | 2 | 5.8 | 5.3 | 3.8 | 5 | 4.1 | 3.4 | 4.9 | ATV61HU15N4 | 3.000 |
| 2.2 | 3 | 8.2 | 7.1 | 5.4 | 5 | 5.8 | 4.8 | 6.9 | ATV61HU22N4 | 3.000 |
| 3 | – | 10.7 | 9 | 7 | 5 | 7.8 | 6.2 | 9.3 | ATV61HU30N4 | 4.000 |
| 4 | 5 | 14.1 | 11.5 | 9.3 | 5 | 10.5 | 7.6 | 12.6 | ATV61HU40N4 | 4.000 |
| 5.5 | 7.5 | 20.3 | 17 | 13.4 | 22 | 14.3 | 11 | 17.1 | ATV61HU55N4 | 5.500 |
| 7.5 | 10 | 27 | 22.2 | 17.8 | 22 | 17.6 | 14 | 21.1 | ATV61HU75N4 | 5.500 |
| 11 | 15 | 36.6 | 30 | 24.1 | 22 | 27.7 | 21 | 33.2 | ATV61HD11N4 | 7.000 |
| 15 | 20 | 48 | 39 | 31.6 | 22 | 33 | 27 | 39.6 | ATV61HD15N4 | 22.000 |
| 18.5 | 25 | 45.5 | 37.5 | 29.9 | 22 | 41 | 34 | 49.2 | ATV61HD18N4 | 22.000 |
| 22 | 30 | 50 | 42 | 32.9 | 22 | 48 | 40 | 57.6 | ATV61HD22N4 | 30.000 |
| 30 | 40 | 66 | 56 | 43.4 | 22 | 66 | 52 | 79.2 | ATV61HD30N4 | 37.000 |
| 37 | 50 | 84 | 69 | 55 | 22 | 79 | 65 | 94.8 | ATV61HD37N4 | 37.000 |
| 45 | 60 | 104 | 85 | 68.5 | 22 | 94 | 77 | 112.8 | ATV61HD45N4 | 44.000 |
| 55 | 75 | 120 | 101 | 79 | 22 | 116 | 96 | 139.2 | ATV61HD55N4 | 44.000 |
| 75 | 100 | 167 | 137 | 109.9 | 22 | 160 | 124 | 192 | ATV61HD75N4 | 44.000 |
| 90 | 125 | 166 | 143 | 109.3 | 35 | 179 | 179 | 214.8 | ATV61HD90N4 | 84.000 |
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61HC11N4 | 84.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61HC13N4 | 106.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61HC16N4 | 116.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 427 | 427 | 512.4 | ATV61HC22N4 | 163.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | |||||
| 250 | 400 | 444 | 435 | 292.2 | 50 | 481 | 481 | 577.2 | ATV61HC25N4 | 207.000 |
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61HC31N4 | 207.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61HC40N4 | 320.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61HC50N4 | 330.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61HC63N4 | 435.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Water-cooled IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1)
kW HP | Line current Apparent (2) power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s
A kg |
380 V 480 V 380 V
A A kVA | 380 V 460 V (IEC) (NEC) A | |||
Three-phase supply voltage: 380…480 V 50/60 Hz | ||||
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61QC11N4 | 80.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61QC13N4 | 80.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61QC16N4 | 80.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 387 | 387 | 464 | ATV61QC20N4 | 140.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | 481 | 481 | 577.2 | ATV61QC25N4 | 140.000 |
| 250 | 400 | 444 | 435 | 292.2 | 50 | |||||
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61QC31N4 | 140.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61QC40N4 | 300.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61QC50N4 | 300.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61QC63N4 | 300.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C2 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4 | 13.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4 | 13.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4 | 13.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4 | 14.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4 | 16.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4 | 16.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4 | 22.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4 | 22.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4 | 28.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4 | 36.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4 | 36.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4 | 51.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4 | 64.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4 | 65.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4 | 92.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4 | 92.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4 | 92.000 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C1 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4C | 19.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4C | 19.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4C | 20.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4C | 20.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4C | 23.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4C | 23.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4C | 32.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4C | 32.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4C | 40.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4C | 51.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4C | 50.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4C | 68.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4C | 85.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4C | 85.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4C | 119.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4C | 119.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4C | 119.000 |
IP 54 drives with integrated Vario switch disconnector and category C2 EMC filter | |||||||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||||||
Motor | Line supply | Altivar 61 | |||||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current In (1) | Max. Reference Weight transient current for 60 s
A kg | ||||
380 V A | 480 V 380 V A kVA | 380 V A | 460 V A | ||||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61E5075N4 | 16.400 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61E5U15N4 | 16.400 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61E5U22N4 | 16.400 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61E5U30N4 | 16.400 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61E5U40N4 | 18.400 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61E5U55N4 | 18.400 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61E5U75N4 | 22.700 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61E5D11N4 | 22.700 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61E5D15N4 | 36.700 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61E5D18N4 | 45.400 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61E5D22N4 | 45.400 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61E5D30N4 | 52.800 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61E5D37N4 | 65.800 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61E5D45N4 | 65.800 |
| 55 | 75 | 104.8 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61E5D55N4 | 84.400 | |
| 75 | 100 | 140.3 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61E5D75N4 | 84.400 | |
| 90 | 125 | 171.8 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61E5D90N4 | 84.400 | |
IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference Weight
kg |
500 V 575 V kW HP | 500 V 600 V A A | 500 V 575 V A A | ||
Three-phase supply voltage: 500…600 V 50/60 Hz | ||||
2.2 |
3 |
7.6 |
6.7 |
22 |
4.5 |
3.9 |
ATV61HU22S6X |
7.500 |
3 | – | 9.9 | 10 | 22 | 5.8 | – | ATV61HU30S6X | 7.500 |
4 | 5 | 12.5 | 10.9 | 22 | 7.5 | 6.1 | ATV61HU40S6X | 7.500 |
5.5 | 7.5 | 16.4 | 14.2 | 22 | 10 | 9 | ATV61HU55S6X | 7.500 |
7.5 | 10 | 21.4 | 18.4 | 22 | 13.5 | 11 | ATV61HU75S6X | 7.500 |
IP 20 drives with integrated category C3 EMC filter | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
2.2 | 3 | 5.2 | 4.4 | 5.2 | 22 | 4.5 | 3.9 | 4.5 | ATV61HU30Y | 30.000 |
3 | 4 | 6.8 | – | 6.6 | 22 | 5.8 | – | 5.5 | ATV61HU40Y | 30.000 |
4 | 5.5 | 8.6 | 7.2 | 8.6 | 22 | 7.5 | 6.1 | 7.5 | ATV61HU55Y | 30.000 |
5.5 | 7.5 | 11.2 | 9.5 | 11.2 | 22 | 10 | 9 | 10 | ATV61HU75Y | 30.000 |
7.5 | 11 | 14.6 | 12.3 | 15.5 | 22 | 13.5 | 11 | 13.5 | ATV61HD11Y | 30.000 |
11 | 15 | 19.8 | 16.7 | 20.2 | 22 | 18.5 | 17 | 18.5 | ATV61HD15Y | 30.000 |
15 | 18.5 | 24.6 | 20.7 | 24 | 22 | 24 | 22 | 24 | ATV61HD18Y | 30.000 |
18.5 | 22 | 29 | 24 | 27 | 22 | 29 | 27 | 27 | ATV61HD22Y | 30.000 |
22 | 30 | 33 | 28 | 34 | 22 | 35 | 32 | 35 | ATV61HD30Y | 30.000 |
30 | 37 | 48 | 41 | 47 | 22 | 47 | 41 | 43 | ATV61HD37Y | 68.000 |
37 | 45 | 62 | 51 | 55 | 22 | 59 | 52 | 54 | ATV61HD45Y | 68.000 |
45 | 55 | 68 | 57 | 63 | 22 | 68 | 62 | 62 | ATV61HD55Y | 68.000 |
55 | 75 | 79 | 67.0 | 82 | 22 | 85 | 77 | 84 | ATV61HD75Y | 68.000 |
75 | 90 | 109 | 92 | 101 | 22 | 110 | 99 | 104 | ATV61HD90Y | 68.000 |
90 | 110 | 128 | 113 | 117 | 22 | 136 | 125 | 125 | ATV61HC11Y (4) | 102.000 |
110 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61HC13Y (4) | 102.000 |
132 | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61HC16Y (4) | 102.000 |
160 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61HC20Y (4) | 102.000 |
200 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61HC25Y (4) | 181.000 |
250 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61HC31Y (4) | 181.000 |
315 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61HC40Y (4) | 181.000 |
400 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61HC50Y (4) | 383.000 |
500 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61HC63Y (4) | 383.000 |
630 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61HC80Y (4) | 383.000 |
Water-cooled IP 20 drives | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
110 | 150 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61QC13Y | 80.000 |
132 | – | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61QC16Y | 80.000 |
160 | 200 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61QC20Y | 80.000 |
200 | 250 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61QC25Y | 140.000 |
250 | 350 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61QC31Y | 140.000 |
315 | 450 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61QC40Y | 140.000 |
400 | 550 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61QC50Y | 300.000 |
500 | 700 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61QC63Y | 300.000 |
630 | 800 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61QC80Y | 300.000 |
Previous : ATV61 VFD VSD AC Drive 55kw/75hp 200V/200A 240V/173A Schneider ATV61HD55M3X Weight 84kg
Next : Schneider Electric Altivar VFD VSD AC Drive 90kw/125hp 200V/336A 240V/288A Schneider ATV61HD90M3X Weight 106kg
Copy product links
Long by picture save/share
INQUIRY
Add Successfully
We are the world's leading supplier of spare parts for medium voltage drives of various brands
点击右上角
分享给朋友吧
GET IN TOUCH
East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong
Call us : +852 5261 7322
Email us : [email protected]
SITEMAP
BUSINESS HOURS
Monday to Friday : 9 am to 6 pm
Saturday : 9 am to 12 am
Sunday : Closed Support Hours in 24/7 Everyday
DISCLAIMER:
We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.
© 2020 robiconperfectharmony.com site . All rights reserved Site Map
