Siemens Arc Defense Technology is your best defense against the dangers of arc faults

Designed to defend.

Siemens Arc Defense Technology is your best

defense against the dangers of arc faults.

usa.siemens.com/perfectharmony

The world’s leading drive system

now offers a fully reinforced

structural arc solution

In the Siemens Large Drives Robicon Perfect Harmony GH180 Sinamics Perfect Harmony

Applications facility, where

medium voltage drives are running at

all times, safety is more than just a

watchword—it’s a guiding principle.

With over twenty years of experience

operating in a medium-voltage

environment, Siemens has set the

standard in medium voltage drive

safety. In 2016, the Siemens medium

voltage drive manufacturing facility

reached the impressive record of over

4 million hours without a lost-time

incident. It is the Siemens mission to

extend this exemplary safety record to

medium voltage drive users.

Superior quality performance

Through rigorous testing and stringent

safety certification, Siemens has

always upheld the highest quality and

safety standards in the manufacturing

of medium voltage drives.

Siemens is raising the bar and taking

safety a step further. By introducing

the new Arc Defense Technology,

Siemens is the first in the industry to

apply passive arc-resistant features

to medium voltage drives with

integral transformers.

Smart upgrades such as pressure-relief

panels and custom arc filters help to

contain dangerous arc energy in the

event of an arc occurrence. When used

along with personal protective

equipment (PPE), Arc Defense

Technology can help provide a

superior level of protection for your

personnel and plant equipment.

Superior operator safety

Despite the challenges associated with

drives that feature integral

transformers, Siemens used the

existing design to its advantage. A

reinforced structure and the addition

of integrated pressure-relief panels to

the cabinet roof made it possible for

the drive to effectively redirect arc

energy up and out. This top-venting

approach has the added benefit

of being more cost-efficient than

ducted solutions.

Key safety features

• Integral pressure￾relief panels

• Enhanced internal bracing

• More robust

mechanical structure

• Inclusion of special arc filters

• Optional arc-flash detection

Maximum equipment protection

Additionally, standard air filters were

replaced with custom arc filters that

are nonflammable and metalized.

IP42-rated louvers add another

potential layer of safety. All of these

solutions were designed to meet

testing requirements consistent with

the existing switchgear standard

that defines burn indicators and

their positions, as well as cabinet

integrity requirements.

12 3 4

Compliance and

Testing Standards

Complies with:

• IEC 62271-200

Edition 2.0 (2011)

• CSA C22.2 No. 0.22 (2011)

• IEEE C 37.20.7

(2007—including

Corrigendum 1-2010)

Successfully passed the

following testing criteria:

• Accessibility grade—

Type A, FLR for IEC and Type

2A for IEEE

• Short circuit current—

35 kA @ 7.2 kV

• Time duration—500ms

Proactive regulatory compliance

Though not yet mandatory, arc resistance

requirements are right around the corner.

Siemens first began arc-fault-testing its

medium voltage drives in 1998. Ever since,

all Siemens medium voltage drives have

been—and continue to be—rigorously

tested and certified to the most current

safety standards, including IEC, UL and CSA.

Reduced operational losses

Protecting your people and your

equipment from an arc occurrence also

protects against lost production. Combined

with personal protective equipment, a

drive with Arc Defense Technology is

another valuable layer of defense against

arc-related dangers and downtime.

Optional arc-flash detection can help

prevent further intensification of an arc

event by sensing the arc energy and

blocking the influx of additional power.

Arc protection starts with the drive itself.

Siemens Arc Defense Technology helps

Siemens Industry Inc.

100 Technology Drive

Alpharetta, GA 30005

[email protected]

(800) 241-4453

Subject to changes without prior notice.

All rights reserved.

Order No: LAFL-02100-0616

Printed in USA

© 2016 Siemens Industry Inc.

direct the hazards of arc events away from

personnel and plant equipment to mitigate

damage and allow a faster return to normal

operations. The result is a highly efficient,

fault-tolerant drive that can help limit

operational losses and prepare you for

future regulations.

3 Enhanced internal

cable bracing to

eliminate cabinet

burnthrough and the

possibility of cable

separation

4 Inclusion of special

arc filters to ensure

the highest level

of safety

2 More robust

mechanical design to

significantly increase

the level of safety

in the event of an

arc incident

1 Integral pressure￾relief panels to

ensure all material

is vented up and

away from personnel
