Green renewal, creating a better future Medium Voltage Frequency Converter Typical Case Studies Innomotics China June 2024

Green renewal, creating a better future Medium Voltage Frequency Converter Typical Case Studies Innomotics China June 2024 © Copyright by InnmonticsTransmission Technology (Shanghai) Co., Ltd. | 2024.05 Americas Market #1 Asia Pacific and Middle East Market #3 Product portfolio China Market #1 Europe and Africa Market #2 Global Market #1 Market Positioning Production Base Distribution Main industry sectors (typical) R&D Base Production Base O& Global Medium Voltage Inverter Drive Business Overview GH180 Air Cooling GL150 / SL150 GH180 Water Cooling GH150 / SH150 Water supply and Wastewater treatment metallurgy Oil & Gas mining © Copyright by Innomotics Transmission Technology (Shanghai) Co., Ltd. I 2024.06 GM150 / SM150 ustomized GH180 High altitude conditions 17 units 5000+m High Altitude Mining At high altitudes, thin air, low oxygen content, active cosmic rays, and large temperature differences between day and nightpose extreme challenges to the reliability of the inverter. Innomotics customized the design of the GH180 for customers , achievingreliable operation at altitudes above 5,000 meters through higher robustness of performance and stronger protection of corecomponents. Currently, 17 GH180s are serving the project, helping customers continuously break through the boundaries ofoperating conditions and ensure production capacity safety with larger-scale electrification applications. Multinational mining group's high altitude copper mine: © Copyright by InnomoticsTransmission Technology (Shanghai) Co., Ltd. I 2024.06  17KM 8 units © Copyright by InnomoticsTransmission Technology (Shanghai) Co., Ltd. I 2024.06 Long submarine cable power supply Subsea oil and gas development The world's top 500 submarine oil and gas development projects: Customized GH180 According to the characteristics of long-distance submarine cables, GH180 is customized and developed for customers. It adoptsadvanced harmonic-free technology to effectively eliminate the capacitance effect and harmonic distortion of long cables, whileachieving motor or power grid friendly characteristics, and constantly breaking through the limits of submarine applications.The application of up to 8 GH180s has increased the scale of electrification and ensured the safety, reliability and efficiency ofcustomers' submarine oil and gas production . 1st © Copyright by InnomoticsTransmission Technology (Shanghai) Co., Ltd. I 2024.06 7% Marine shipbuilding The world's largest container ship (24,000 containers): Application of shaft power supply for Chinese ships Carbon emissions/year Severe sea conditions, shipping vibrations and high-voltage insulation have put forward higher requirements for the stability of shaftpower supply. Through the customization of SH150, the stability of shaft voltage and frequency has been greatly improved, meetingthe requirements of connecting to the ship's power grid, improving the energy efficiency of ships, and reducing carbon emissions by up to7% per year .  ↓Carbon emissions/year CO2 content 76% 1 million tons Carbon capture in steel blast furnaces Removing carbon dioxide through gas compression can effectively reduce carbon emissions in the steel industry. This project is equipped withthe Perfect Harmony GH180 inverter to ensure the reliable operation of the gas compression and purification process. The carbon dioxide contentis reduced from 30% to less than 7%, and the blast furnace efficiency is increased by 40%. It is expected that annual carbon emissions will bereduced by about 1 million tons, and it can be widely popularized and applied to the energy-saving and carbon-reduction transformation ofdomestic blast furnaces. Leading steel enterprises in Northwest China: © Copyright by InnomoticsTransmission Technology (Shanghai) Co., Ltd. I 2024.06 ↓ ↓ Medium voltage inverter R&D and manufacturing base in China-Innomotics (Shanghai) Electric Drive Co., Ltd. • Innomotics is the world's largest medium-voltage inverter R&D and manufacturingbase• Former Siemens (Shanghai) Electric Drive Co., Ltd. (renamed in March 2024)• National Green Factory • National high-tech enterprise • Shanghai Smart Factory • Founded: 2005• Location: Pudong, Shanghai• Number of employees: 310• Floor space: 15,293 sqm• Shipments: 2,200+ units/ year © Copyright by InnomoticsTransmission Technology (Shanghai) Co., Ltd. I 2024.06
