ATV61HD37M3X
Schneider Electric ATV61HD37M3X Picture
Buy online
View all Altivar 61 Variable Frequency Drives VFD
Schneider Electric ATV61HD37M3X Picture
ATV61 37 kW 50HP 240V 3 phases w/o EMC IP20
ATV61HD37M3X
Compare
Discontinued on:
02 December 2020
To be end-of-service on:
01 January 2025
Recommended replacement(s)
ATV61HD37M3X may be replaced by any of the following products:
1×
Schneider Electric ATV630D37M3 Picture
variable speed drive, Altivar Process ATV600, ATV630, 37kW, 50hp, 200 to 240V, IP21, UL type 1
ATV630D37M3
1×
Schneider Electric ATV630D45M3 Picture
variable speed drive, Altivar Process ATV600, ATV630, 45kW, 60hp, 200 to 240V, IP21, UL type 1
ATV630D45M3
Buy online
In Cart
Contact sales
Contact support
Subscribe to the newsletter
Main documents
Documents
Product Datasheet
User guide
Instruction Sheet
Catalog
Technical Drawing
CAD Document
See all documents
Compatible Software
Schneider Electric PSWSANCZZSPEZZ Picture
PSWSANCZZSPEZZ
Power Monitoring Expert Standard Edition BASE licence (incld 1…
Specifications
Main
Range of Product
Altivar 61
Product or Component Type
Variable speed drive
Product Specific Application
Pumping and ventilation machine
Component name
ATV61
Motor power kW
37 kW, 3 phase 200...240 V
Maximum Horse Power Rating
50 hp, 3 phase 200...240 V
power supply voltage
200...240 V - 15...10 %
supply number of phases
3 phase
Line current
127 A 240 V 3 phase 37 kW / 50 hp
141 A 200 V 3 phase 37 kW / 50 hp
EMC filter
Without EMC filter
Assembly style
With heat sink
Apparent power
52.8 kVA 240 V 3 phase 37 kW / 50 hp
maximum prospective line Isc
22 kA 3 phase
Maximum transient current
172.8 A 60 s, 3 phase
Nominal switching frequency
12 kHz
Switching frequency
1...16 kHz adjustable
12...16 kHz with derating factor
asynchronous motor control
Voltage/frequency ratio - Energy Saving, quadratic U/f
Flux vector control without sensor, standard
Voltage/frequency ratio, 5 points
Voltage/frequency ratio, 2 points
Synchronous motor control profile
Vector control without sensor, standard
Communication Port Protocol
Modbus
CANopen
Type of polarization
No impedance Modbus
Option card
Communication card APOGEE FLN
Communication card BACnet
Communication card CC-Link
Controller inside programmable card
Communication card DeviceNet
Communication card EtherNet/IP
Communication card Fipio
I/O extension card
Communication card Interbus-S
Communication card LonWorks
Communication card METASYS N2
Communication card Modbus Plus
Communication card Modbus TCP
Communication card Modbus/Uni-Telway
Multi-pump card
Communication card Profibus DP
Communication card Profibus DP V1
Complementary
Product destination
Synchronous motors
Asynchronous motors
power supply voltage limits
170…264 V
power supply frequency
50...60 Hz - 5...5 %
power supply frequency limits
47.5...63 Hz
Continuous output current
144 A 12 kHz, 230 V - 3 phase
Output frequency
0.1…599 Hz
Speed range
1…100 in open-loop mode, without speed feedback
Speed accuracy
+/- 10 % of nominal slip 0.2 Tn to Tn without speed feedback
Torque accuracy
+/- 15 % in open-loop mode, without speed feedback
Transient overtorque
130 % of nominal motor torque +/- 10 % 60 s
Braking torque
<= 125 % with braking resistor
30 % without braking resistor
Regulation loop
Frequency PI regulator
Motor slip compensation
Not available in voltage/frequency ratio (2 or 5 points)
Can be suppressed
Adjustable
Automatic whatever the load
diagnostic
For drive voltage 1 LED (red)
Output voltage
<= power supply voltage
electrical isolation
Between power and control terminals
type of cable for mounting in an enclosure
With an IP21 or an IP31 kit 3 IEC cable 104 °F (40 °C), copper 70 °C / PVC
With UL Type 1 kit 3 UL 508 cable 104 °F (40 °C), copper 75 °C / PVC
Without mounting kit 1 IEC cable 113 °F (45 °C), copper 70 °C / PVC
Without mounting kit 1 IEC cable 113 °F (45 °C), copper 90 °C / XLPE/EPR
Electrical connection
Terminal 2.5 mm² / AWG 14 AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
Terminal 150 mm² / 300 kcmil L1/R, L2/S, L3/T, U/T1, V/T2, W/T3, PC/-, PO, PA/+, PA, PB)
Tightening torque
5.31 lbf.in (0.6 N.m) AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
362.88 lbf.in (41 N.m), 360 lb.in L1/R, L2/S, L3/T, U/T1, V/T2, W/T3, PC/-, PO, PA/+, PA, PB)
Supply
Internal supply for reference potentiometer (1 to 10 kOhm) 10.5 V DC, +/- 5 %, <10 mA overload and short-circuit protection
Internal supply 24 V DC 21…27 V), <200 mA overload and short-circuit protection
External supply 24 V DC 19…30 V)
Analogue input number
2
Analogue input type
AI1-/Al1+ bipolar differential voltage +/- 10 V DC 24 V max 11 bits + sign
AI2 software-configurable current 0...20 mA 242 Ohm 11 bits
AI2 software-configurable voltage 0...10 V DC 24 V max 30000 Ohm 11 bits
sampling time
2 ms +/- 0.5 ms AI1-/Al1+) - analog input
2 ms +/- 0.5 ms Al2) - analog input
2 ms +/- 0.5 ms AO1) - analog output
2 ms +/- 0.5 ms LI1...LI5) - discrete input
2 ms +/- 0.5 ms LI6)if configured as logic input - discrete input
absolute accuracy precision
+/- 0.6 % AI1-/Al1+) for a temperature variation 60 °C
+/- 0.6 % AI2) for a temperature variation 60 °C
+/- 1 % AO1) for a temperature variation 60 °C
Linearity error
+/- 0.15 % of maximum value AI1-/Al1+)
+/- 0.15 % of maximum value AI2)
+/- 0.2 % AO1)
Analogue output number
1
Analogue output type
AO1 software-configurable current 0...20 mA 500 Ohm 10 bits
AO1 software-configurable voltage 0...10 V DC 470 Ohm 10 bits
AO1 software-configurable logic output 10 V, 20 mA
Discrete output number
2
Discrete output type
Configurable relay logic R1A, R1B, R1C) NO/NC - 100000 cycles
Configurable relay logic R2A, R2B) NO - 100000 cycles
maximum response time
<= 100 ms in STO (Safe Torque Off)
R1A, R1B, R1C <= 7 ms +/- 0.5 ms
R2A, R2B <= 7 ms +/- 0.5 ms
Minimum switching current
3 mA 24 V DC configurable relay logic
Maximum switching current
R1, R2 2 A 250 V AC inductive, cos phi = 0.4 7 ms
R1, R2 2 A 30 V DC inductive, cos phi = 0.4 7 ms
R1, R2 5 A 250 V AC resistive, cos phi = 1 0 ms
R1, R2 5 A 30 V DC resistive, cos phi = 1 0 ms
Discrete input number
7
Discrete input type
Programmable LI1...LI5) 24 V DC <= 30 V)level 1 PLC - 3500 Ohm
Switch-configurable LI6) 24 V DC <= 30 V)level 1 PLC - 3500 Ohm
Switch-configurable PTC probe LI6)0…6 - 1500 Ohm
Safety input PWR) 24 V DC <= 30 V) - 1500 Ohm
Discrete input logic
Negative logic (sink) LI1...LI5), > 16 V, < 10 V
Positive logic (source) LI1...LI5), < 5 V, > 11 V
Negative logic (sink) LI6)if configured as logic input, > 16 V, < 10 V
Positive logic (source) LI6)if configured as logic input, < 5 V, > 11 V
Acceleration and deceleration ramps
S, U or customized
Linear adjustable separately from 0.01 to 9000 s
Automatic adaptation of ramp if braking capacity exceeded, by using resistor
Braking to standstill
By DC injection
Protection type
Against exceeding limit speed drive
Against input phase loss drive
Break on the control circuit drive
Input phase breaks drive
Line supply overvoltage drive
Line supply undervoltage drive
Overcurrent between output phases and earth drive
Overheating protection drive
Overvoltages on the DC bus drive
Power removal drive
Short-circuit between motor phases drive
Thermal protection drive
Motor phase break motor
Power removal motor
Thermal protection motor
Insulation resistance
> 1 mOhm 500 V DC for 1 minute to earth
Frequency resolution
Analog input 0.024/50 Hz
Display unit 0.1 Hz
Connector type
1 RJ45 on front face)Modbus
1 RJ45 on terminal)Modbus
Male SUB-D 9 on RJ45CANopen
Physical interface
2-wire RS 485 Modbus
Transmission frame
RTU Modbus
Transmission rate
4800 bps, 9600 bps, 19200 bps, 38.4 Kbps Modbus on terminal
9600 bps, 19200 bps Modbus on front face
20 kbps, 50 kbps, 125 kbps, 250 kbps, 500 kbps, 1 Mbps CANopen
Data format
8 bits, 1 stop, even parity Modbus on front face
8 bits, odd even or no configurable parity Modbus on terminal
Number of addresses
1…127 CANopen
1…247 Modbus
Method of access
Slave CANopen
marking
CE
Operating position
Vertical +/- 10 degree
Product Weight
81.57 lb(US) (37 kg)
Width
12.60 in (320 mm)
Height
21.65 in (550 mm)
Depth
10.47 in (266 mm)
Environment
Noise level
64 dB 86/188/EEC
Dielectric strength
2830 V DC between earth and power terminals
4230 V DC between control and power terminals
Electromagnetic compatibility
Conducted radio-frequency immunity test level 3 IEC 61000-4-6
Electrical fast transient/burst immunity test level 4 IEC 61000-4-4
Electrostatic discharge immunity test level 3 IEC 61000-4-2
Radiated radio-frequency electromagnetic field immunity test level 3 IEC 61000-4-3
Voltage dips and interruptions immunity test IEC 61000-4-11
standards
IEC 60721-3-3 class 3S2
UL Type 1
IEC 60721-3-3 class 3C1
Product Certifications
NOM 117
GOST
C-tick
CSA
UL
DNV
Pollution degree
3 EN/IEC 61800-5-1
3 UL 840
degree of proctection
IP20 on upper part without blanking plate on cover EN/IEC 60529
IP20 on upper part without blanking plate on cover EN/IEC 61800-5-1
IP21 EN/IEC 60529
IP21 EN/IEC 61800-5-1
IP41 on upper part EN/IEC 60529
IP41 on upper part EN/IEC 61800-5-1
IP54 on lower part EN/IEC 60529
IP54 on lower part EN/IEC 61800-5-1
Vibration resistance
1 gn 13…200 Hz)EN/IEC 60068-2-6
1.5 mm peak to peak 3…13 Hz)EN/IEC 60068-2-6
Shock resistance
15 gn 11 ms EN/IEC 60068-2-27
Relative humidity
5…95 % without condensation IEC 60068-2-3
5…95 % without dripping water IEC 60068-2-3
Ambient air temperature for operation
14…122 °F (-10…50 °C) without derating)
122…140 °F (50…60 °C) with derating factor)
Ambient Air Temperature for Storage
-13…158 °F (-25…70 °C)
Operating altitude
<= 3280.84 ft (1000 m) without derating
3280.84...9842.52 ft (1000...3000 m) with current derating 1 % per 100 m
Ordering and shipping details
Category
22137-ATV61 7.5 THRU 50 HP DRIVES
Discount Schedule
CP4C
GTIN
00785901435631
Returnability
No
Country of origin
IN
Contractual warranty
Warranty
18 months
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
Single-phase supply voltage: 200…240 V 50/60 Hz | ||||||
| 0.37 | 0.5 | 6.9 | 5.8 | 1.4 | 5 | 3 | 3.6 | ATV61H075M3 | 3.000 | |
| 0.75 | 1 | 12 | 9.9 | 2.4 | 5 | 4.8 | 5.7 | ATV61HU15M3 | 3.000 | |
| 1.5 | 2 | 18.2 | 15.7 | 3.7 | 5 | 8 | 9.6 | ATV61HU22M3 | 4.000 | |
| 2.2 | 3 | 25.9 | 22.1 | 5.3 | 5 | 11 | 13.2 | ATV61HU30M3 | 4.000 | |
| 3 | – | 25.9 | 22 | 5.3 | 5 | 13.7 | 16.4 | ATV61HU40M3 (3) | 4.000 | |
| 4 | 5 | 34.9 | 29.9 | 7 | 5 | 17.5 | 21 | ATV61HU55M3 (3) | 5.500 | |
| 5.5 | 7.5 | 47.3 | 40.1 | 9.5 | 22 | 27.5 | 33 | ATV61HU75M3 (3) | 7.000 |
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
| Three-phase supply voltage: 200…240 V 50/60 Hz | ||||||
0.75 | 1 | 6.1 | 5.3 | 2.2 | 5 | 4.8 | 5.7 | ATV61H075M3 | 3.000 |
1.5 | 2 | 11.3 | 9.6 | 4 | 5 | 8 | 9.6 | ATV61HU15M3 | 3.000 |
2.2 | 3 | 15 | 12.8 | 5.3 | 5 | 11 | 13.2 | ATV61HU22M3 | 4.000 |
3 | – | 19.3 | 16.4 | 6.8 | 5 | 13.7 | 16.4 | ATV61HU30M3 | 4.000 |
4 | 5 | 25.8 | 22.9 | 9.5 | 5 | 17.5 | 21 | ATV61HU40M3 | 4.000 |
5.5 | 7.5 | 35 | 30.8 | 12.8 | 22 | 27.5 | 33 | ATV61HU55M3 | 5.500 |
7.5 | 10 | 45 | 39.4 | 16.4 | 22 | 33 | 39.6 | ATV61HU75M3 | 7.000 |
11 | 15 | 53.3 | 45.8 | 19 | 22 | 54 | 64.8 | ATV61HD11M3X (4) | 22.000 |
15 | 20 | 71.7 | 61.6 | 25.6 | 22 | 66 | 79.2 | ATV61HD15M3X (4) | 22.000 |
18.5 | 25 | 77 | 69 | 28.7 | 22 | 75 | 90 | ATV61HD18M3X (4) | 30.000 |
22 | 30 | 88 | 80 | 33.3 | 22 | 88 | 105.6 | ATV61HD22M3X (4) | 30.000 |
30 | 40 | 124 | 110 | 45.7 | 22 | 120 | 144 | ATV61HD30M3X (4) | 37.000 |
37 | 50 | 141 | 127 | 52.8 | 22 | 144 | 172.8 | ATV61HD37M3X (4) | 37.000 |
45 | 60 | 167 | 147 | 61.1 | 22 | 176 | 211.2 | ATV61HD45M3X (4) | 37.000 |
55 | 75 | 200 | 173 | 71.9 | 35 | 221 | 265.2 | ATV61HD55M3X (4) | 84.000 |
75 | 100 | 271 | 232 | 96.4 | 35 | 285 | 342 | ATV61HD75M3X (4) | 84.000 |
90 | 125 | 336 | 288 | 119.7 | 35 | 359 | 431 | ATV61HD90M3X (4) | 106.000 |
IP 20 drives with integrated category C2 or C3 EMC filter | |||||
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent Max. power prospective line Isc 380 V
kVA kA | Maximum continuous current (1) | Max. transient Reference current for 60 s | Weight
kg |
380 V 480 V
A A | 380 V 460 V (IEC) (NEC) A A | ||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 3.7 | 3 | 2.4 | 5 | 2.3 | 2.1 | 2.7 | ATV61H075N4 | 3.000 |
| 1.5 | 2 | 5.8 | 5.3 | 3.8 | 5 | 4.1 | 3.4 | 4.9 | ATV61HU15N4 | 3.000 |
| 2.2 | 3 | 8.2 | 7.1 | 5.4 | 5 | 5.8 | 4.8 | 6.9 | ATV61HU22N4 | 3.000 |
| 3 | – | 10.7 | 9 | 7 | 5 | 7.8 | 6.2 | 9.3 | ATV61HU30N4 | 4.000 |
| 4 | 5 | 14.1 | 11.5 | 9.3 | 5 | 10.5 | 7.6 | 12.6 | ATV61HU40N4 | 4.000 |
| 5.5 | 7.5 | 20.3 | 17 | 13.4 | 22 | 14.3 | 11 | 17.1 | ATV61HU55N4 | 5.500 |
| 7.5 | 10 | 27 | 22.2 | 17.8 | 22 | 17.6 | 14 | 21.1 | ATV61HU75N4 | 5.500 |
| 11 | 15 | 36.6 | 30 | 24.1 | 22 | 27.7 | 21 | 33.2 | ATV61HD11N4 | 7.000 |
| 15 | 20 | 48 | 39 | 31.6 | 22 | 33 | 27 | 39.6 | ATV61HD15N4 | 22.000 |
| 18.5 | 25 | 45.5 | 37.5 | 29.9 | 22 | 41 | 34 | 49.2 | ATV61HD18N4 | 22.000 |
| 22 | 30 | 50 | 42 | 32.9 | 22 | 48 | 40 | 57.6 | ATV61HD22N4 | 30.000 |
| 30 | 40 | 66 | 56 | 43.4 | 22 | 66 | 52 | 79.2 | ATV61HD30N4 | 37.000 |
| 37 | 50 | 84 | 69 | 55 | 22 | 79 | 65 | 94.8 | ATV61HD37N4 | 37.000 |
| 45 | 60 | 104 | 85 | 68.5 | 22 | 94 | 77 | 112.8 | ATV61HD45N4 | 44.000 |
| 55 | 75 | 120 | 101 | 79 | 22 | 116 | 96 | 139.2 | ATV61HD55N4 | 44.000 |
| 75 | 100 | 167 | 137 | 109.9 | 22 | 160 | 124 | 192 | ATV61HD75N4 | 44.000 |
| 90 | 125 | 166 | 143 | 109.3 | 35 | 179 | 179 | 214.8 | ATV61HD90N4 | 84.000 |
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61HC11N4 | 84.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61HC13N4 | 106.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61HC16N4 | 116.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 427 | 427 | 512.4 | ATV61HC22N4 | 163.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | |||||
| 250 | 400 | 444 | 435 | 292.2 | 50 | 481 | 481 | 577.2 | ATV61HC25N4 | 207.000 |
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61HC31N4 | 207.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61HC40N4 | 320.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61HC50N4 | 330.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61HC63N4 | 435.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Water-cooled IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1)
kW HP | Line current Apparent (2) power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s
A kg |
380 V 480 V 380 V
A A kVA | 380 V 460 V (IEC) (NEC) A | |||
Three-phase supply voltage: 380…480 V 50/60 Hz | ||||
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61QC11N4 | 80.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61QC13N4 | 80.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61QC16N4 | 80.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 387 | 387 | 464 | ATV61QC20N4 | 140.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | 481 | 481 | 577.2 | ATV61QC25N4 | 140.000 |
| 250 | 400 | 444 | 435 | 292.2 | 50 | |||||
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61QC31N4 | 140.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61QC40N4 | 300.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61QC50N4 | 300.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61QC63N4 | 300.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C2 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4 | 13.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4 | 13.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4 | 13.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4 | 14.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4 | 16.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4 | 16.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4 | 22.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4 | 22.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4 | 28.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4 | 36.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4 | 36.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4 | 51.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4 | 64.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4 | 65.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4 | 92.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4 | 92.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4 | 92.000 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C1 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4C | 19.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4C | 19.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4C | 20.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4C | 20.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4C | 23.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4C | 23.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4C | 32.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4C | 32.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4C | 40.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4C | 51.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4C | 50.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4C | 68.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4C | 85.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4C | 85.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4C | 119.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4C | 119.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4C | 119.000 |
IP 54 drives with integrated Vario switch disconnector and category C2 EMC filter | |||||||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||||||
Motor | Line supply | Altivar 61 | |||||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current In (1) | Max. Reference Weight transient current for 60 s
A kg | ||||
380 V A | 480 V 380 V A kVA | 380 V A | 460 V A | ||||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61E5075N4 | 16.400 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61E5U15N4 | 16.400 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61E5U22N4 | 16.400 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61E5U30N4 | 16.400 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61E5U40N4 | 18.400 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61E5U55N4 | 18.400 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61E5U75N4 | 22.700 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61E5D11N4 | 22.700 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61E5D15N4 | 36.700 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61E5D18N4 | 45.400 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61E5D22N4 | 45.400 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61E5D30N4 | 52.800 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61E5D37N4 | 65.800 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61E5D45N4 | 65.800 |
| 55 | 75 | 104.8 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61E5D55N4 | 84.400 | |
| 75 | 100 | 140.3 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61E5D75N4 | 84.400 | |
| 90 | 125 | 171.8 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61E5D90N4 | 84.400 | |
IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference Weight
kg |
500 V 575 V kW HP | 500 V 600 V A A | 500 V 575 V A A | ||
Three-phase supply voltage: 500…600 V 50/60 Hz | ||||
2.2 |
3 |
7.6 |
6.7 |
22 |
4.5 |
3.9 |
ATV61HU22S6X |
7.500 |
3 | – | 9.9 | 10 | 22 | 5.8 | – | ATV61HU30S6X | 7.500 |
4 | 5 | 12.5 | 10.9 | 22 | 7.5 | 6.1 | ATV61HU40S6X | 7.500 |
5.5 | 7.5 | 16.4 | 14.2 | 22 | 10 | 9 | ATV61HU55S6X | 7.500 |
7.5 | 10 | 21.4 | 18.4 | 22 | 13.5 | 11 | ATV61HU75S6X | 7.500 |
IP 20 drives with integrated category C3 EMC filter | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
2.2 | 3 | 5.2 | 4.4 | 5.2 | 22 | 4.5 | 3.9 | 4.5 | ATV61HU30Y | 30.000 |
3 | 4 | 6.8 | – | 6.6 | 22 | 5.8 | – | 5.5 | ATV61HU40Y | 30.000 |
4 | 5.5 | 8.6 | 7.2 | 8.6 | 22 | 7.5 | 6.1 | 7.5 | ATV61HU55Y | 30.000 |
5.5 | 7.5 | 11.2 | 9.5 | 11.2 | 22 | 10 | 9 | 10 | ATV61HU75Y | 30.000 |
7.5 | 11 | 14.6 | 12.3 | 15.5 | 22 | 13.5 | 11 | 13.5 | ATV61HD11Y | 30.000 |
11 | 15 | 19.8 | 16.7 | 20.2 | 22 | 18.5 | 17 | 18.5 | ATV61HD15Y | 30.000 |
15 | 18.5 | 24.6 | 20.7 | 24 | 22 | 24 | 22 | 24 | ATV61HD18Y | 30.000 |
18.5 | 22 | 29 | 24 | 27 | 22 | 29 | 27 | 27 | ATV61HD22Y | 30.000 |
22 | 30 | 33 | 28 | 34 | 22 | 35 | 32 | 35 | ATV61HD30Y | 30.000 |
30 | 37 | 48 | 41 | 47 | 22 | 47 | 41 | 43 | ATV61HD37Y | 68.000 |
37 | 45 | 62 | 51 | 55 | 22 | 59 | 52 | 54 | ATV61HD45Y | 68.000 |
45 | 55 | 68 | 57 | 63 | 22 | 68 | 62 | 62 | ATV61HD55Y | 68.000 |
55 | 75 | 79 | 67.0 | 82 | 22 | 85 | 77 | 84 | ATV61HD75Y | 68.000 |
75 | 90 | 109 | 92 | 101 | 22 | 110 | 99 | 104 | ATV61HD90Y | 68.000 |
90 | 110 | 128 | 113 | 117 | 22 | 136 | 125 | 125 | ATV61HC11Y (4) | 102.000 |
110 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61HC13Y (4) | 102.000 |
132 | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61HC16Y (4) | 102.000 |
160 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61HC20Y (4) | 102.000 |
200 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61HC25Y (4) | 181.000 |
250 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61HC31Y (4) | 181.000 |
315 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61HC40Y (4) | 181.000 |
400 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61HC50Y (4) | 383.000 |
500 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61HC63Y (4) | 383.000 |
630 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61HC80Y (4) | 383.000 |
Water-cooled IP 20 drives | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
110 | 150 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61QC13Y | 80.000 |
132 | – | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61QC16Y | 80.000 |
160 | 200 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61QC20Y | 80.000 |
200 | 250 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61QC25Y | 140.000 |
250 | 350 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61QC31Y | 140.000 |
315 | 450 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61QC40Y | 140.000 |
400 | 550 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61QC50Y | 300.000 |
500 | 700 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61QC63Y | 300.000 |
630 | 800 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61QC80Y | 300.000 |
Previous : Schneider Electric Altivar VFD VSD AC Drive 45kw/60hp 200V/167A 240V/147A Schneider ATV61HD45M3X Weight 37kg
Next : Schneider Electric Altivar61 VFD VSD AC Drive 37kw/50hp 380V/84A 480V/69A Schneider ATV61HD37N4 Weight 37kg
Copy product links
Long by picture save/share
Schneider Electric Altivar VFD VSD AC Drive 37kw/50hp 200V/141A 240V/127A Schneider ATV61HD37M3X Weight 37kg
INQUIRY
Add Successfully
We are the world's leading supplier of spare parts for medium voltage drives of various brands
点击右上角
分享给朋友吧
GET IN TOUCH
East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong
Call us : +852 5261 7322
Email us : [email protected]
SITEMAP
BUSINESS HOURS
Monday to Friday : 9 am to 6 pm
Saturday : 9 am to 12 am
Sunday : Closed Support Hours in 24/7 Everyday
DISCLAIMER:
We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.
© 2020 robiconperfectharmony.com site . All rights reserved Site Map
