ATV61HD90N4
View all Altivar 61 Variable Frequency Drives VFD
Schneider Electric ATV61HD90N4 Picture
SPEED DRIVE 125 HP 460 V ATV61
ATV61HD90N4
Compare
Discontinued on:
01 January 2017
End-of-service on:
29 January 2021
Recommended replacement(s)
ATV61HD90N4 is replaced by:
1×
Schneider Electric ATV630D90N4 Picture
variable speed drive, Altivar Process ATV600, ATV630, 90kW, 125hp, 380 to 480V, IP21, UL type 1
ATV630D90N4
Environmental performance of the product Learn more
Sustainable by Design
Green Premium™
RoHS/REACh
RoHS/REACh
Contact sales
Contact support
Subscribe to the newsletter
Main documents
Documents
Product Datasheet
User guide
Instruction Sheet
Catalog
Technical Drawing
CAD Document
Environmental Disclosure
See all documents
Compatible Software
Schneider Electric PSWSANCZZSPEZZ Picture
PSWSANCZZSPEZZ
Power Monitoring Expert Standard Edition BASE licence (incld 1 Engineering C)
Specifications
Main
Range of Product
Altivar 61
Product or Component Type
Variable speed drive
Product Specific Application
Pumping and ventilation machine
Component name
ATV61
Motor power kW
90 kW, 3 phase 380...480 V
Maximum Horse Power Rating
125 hp, 3 phase 380...480 V
power supply voltage
380...480 V - 15...10 %
supply number of phases
3 phase
Line current
143 A 480 V 3 phase 90 kW / 125 hp
166 A 380 V 3 phase 90 kW / 125 hp
EMC filter
Level 3 EMC filter
Assembly style
With heat sink
Apparent power
109.3 kVA 380 V 3 phase 90 kW / 125 hp
maximum prospective line Isc
35 kA 3 phase
Maximum transient current
214.8 A 60 s, 3 phase
Nominal switching frequency
4 kHz
Switching frequency
2...8 kHz adjustable
4...8 kHz with derating factor
asynchronous motor control
Voltage/frequency ratio, 5 points
Voltage/frequency ratio, 2 points
Flux vector control without sensor, standard
Voltage/frequency ratio - Energy Saving, quadratic U/f
Synchronous motor control profile
Vector control without sensor, standard
Communication Port Protocol
Modbus
CANopen
Type of polarization
No impedance Modbus
Option card
Communication card APOGEE FLN
Communication card BACnet
Communication card CC-Link
Controller inside programmable card
Communication card DeviceNet
Communication card EtherNet/IP
Communication card Fipio
I/O extension card
Communication card Interbus-S
Communication card LonWorks
Communication card METASYS N2
Communication card Modbus Plus
Communication card Modbus TCP
Communication card Modbus/Uni-Telway
Multi-pump card
Communication card Profibus DP
Communication card Profibus DP V1
Complementary
Product destination
Asynchronous motors
Synchronous motors
power supply voltage limits
323…528 V
power supply frequency
50...60 Hz - 5...5 %
power supply frequency limits
47.5...63 Hz
Continuous output current
179 A 4 kHz, 380 V - 3 phase
179 A 4 kHz, 460 V - 3 phase
Output frequency
0.1…500 Hz
Speed range
1…100 in open-loop mode, without speed feedback
Speed accuracy
+/- 10 % of nominal slip 0.2 Tn to Tn without speed feedback
Torque accuracy
+/- 15 % in open-loop mode, without speed feedback
Transient overtorque
130 % of nominal motor torque +/- 10 % 60 s
Braking torque
<= 125 % with braking resistor
30 % without braking resistor
Regulation loop
Frequency PI regulator
Motor slip compensation
Automatic whatever the load
Can be suppressed
Not available in voltage/frequency ratio (2 or 5 points)
Adjustable
diagnostic
For drive voltage 1 LED (red)
Output voltage
<= power supply voltage
electrical isolation
Between power and control terminals
type of cable for mounting in an enclosure
With an IP21 or an IP31 kit 3 IEC cable 104 °F (40 °C), copper 70 °C / PVC
With UL Type 1 kit 3 UL 508 cable 104 °F (40 °C), copper 75 °C / PVC
Without mounting kit 1 IEC cable 113 °F (45 °C), copper 70 °C / PVC
Without mounting kit 1 IEC cable 113 °F (45 °C), copper 90 °C / XLPE/EPR
Electrical connection
Terminal 2.5 mm² / AWG 14 AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
Terminal 2 x 100 mm² / 2 x 250 kcmil L1/R, L2/S, L3/T, U/T1, V/T2, W/T3)
Terminal 60 mm² / 250 kcmil PA, PB)
Terminal 2 x 100 mm² / 2 x 250 kcmil PC/-, PO, PA/+)
Tightening torque
5.31 lbf.in (0.6 N.m) AI1-/AI1+, AI2, AO1, R1A, R1B, R1C, R2A, R2B, LI1...LI6, PWR)
212.42 lbf.in (24 N.m), 212 lb.in L1/R, L2/S, L3/T, U/T1, V/T2, W/T3)
362.88 lbf.in (41 N.m), 360 lb.in PC/-, PO, PA/+)
106.21 lbf.in (12 N.m), 106 lb.in PA, PB)
Supply
Internal supply for reference potentiometer (1 to 10 kOhm) 10.5 V DC, +/- 5 %, <10 mA overload and short-circuit protection
Internal supply 24 V DC 21…27 V), <200 mA overload and short-circuit protection
External supply 24 V DC 19…30 V)
Analogue input number
2
Analogue input type
AI1-/Al1+ bipolar differential voltage +/- 10 V DC 24 V max 11 bits + sign
AI2 software-configurable current 0...20 mA 242 Ohm 11 bits
AI2 software-configurable voltage 0...10 V DC 24 V max 30000 Ohm 11 bits
sampling time
2 ms +/- 0.5 ms AI1-/Al1+) - analog input
2 ms +/- 0.5 ms Al2) - analog input
2 ms +/- 0.5 ms AO1) - analog output
2 ms +/- 0.5 ms LI1...LI5) - discrete input
2 ms +/- 0.5 ms LI6)if configured as logic input - discrete input
absolute accuracy precision
+/- 0.6 % AI1-/Al1+) for a temperature variation 60 °C
+/- 0.6 % AI2) for a temperature variation 60 °C
+/- 1 % AO1) for a temperature variation 60 °C
Linearity error
+/- 0.15 % of maximum value AI1-/Al1+)
+/- 0.15 % of maximum value AI2)
+/- 0.2 % AO1)
Analogue output number
1
Analogue output type
AO1 software-configurable current 0...20 mA 500 Ohm 10 bits
AO1 software-configurable voltage 0...10 V DC 470 Ohm 10 bits
AO1 software-configurable logic output 10 V, 20 mA
Discrete output number
2
Discrete output type
Configurable relay logic R1A, R1B, R1C) NO/NC - 100000 cycles
Configurable relay logic R2A, R2B) NO - 100000 cycles
maximum response time
<= 100 ms in STO (Safe Torque Off)
R1A, R1B, R1C <= 7 ms +/- 0.5 ms
R2A, R2B <= 7 ms +/- 0.5 ms
Minimum switching current
3 mA 24 V DC configurable relay logic
Maximum switching current
R1, R2 2 A 250 V AC inductive, cos phi = 0.4 7 ms
R1, R2 2 A 30 V DC inductive, cos phi = 0.4 7 ms
R1, R2 5 A 250 V AC resistive, cos phi = 1 0 ms
R1, R2 5 A 30 V DC resistive, cos phi = 1 0 ms
Discrete input number
7
Discrete input type
Programmable LI1...LI5) 24 V DC <= 30 V)level 1 PLC - 3500 Ohm
Switch-configurable LI6) 24 V DC <= 30 V)level 1 PLC - 3500 Ohm
Switch-configurable PTC probe LI6)0…6 - 1500 Ohm
Safety input PWR) 24 V DC <= 30 V) - 1500 Ohm
Discrete input logic
Negative logic (sink) LI1...LI5), > 16 V, < 10 V
Positive logic (source) LI1...LI5), < 5 V, > 11 V
Negative logic (sink) LI6)if configured as logic input, > 16 V, < 10 V
Positive logic (source) LI6)if configured as logic input, < 5 V, > 11 V
Acceleration and deceleration ramps
Linear adjustable separately from 0.01 to 9000 s
S, U or customized
Automatic adaptation of ramp if braking capacity exceeded, by using resistor
Braking to standstill
By DC injection
Protection type
Against exceeding limit speed drive
Against input phase loss drive
Break on the control circuit drive
Input phase breaks drive
Line supply overvoltage drive
Line supply undervoltage drive
Overcurrent between output phases and earth drive
Overheating protection drive
Overvoltages on the DC bus drive
Power removal drive
Short-circuit between motor phases drive
Thermal protection drive
Motor phase break motor
Power removal motor
Thermal protection motor
Insulation resistance
> 1 mOhm 500 V DC for 1 minute to earth
Frequency resolution
Analog input 0.024/50 Hz
Display unit 0.1 Hz
Connector type
1 RJ45 on front face)Modbus
1 RJ45 on terminal)Modbus
Male SUB-D 9 on RJ45CANopen
Physical interface
2-wire RS 485 Modbus
Transmission frame
RTU Modbus
Transmission rate
4800 bps, 9600 bps, 19200 bps, 38.4 Kbps Modbus on terminal
9600 bps, 19200 bps Modbus on front face
20 kbps, 50 kbps, 125 kbps, 250 kbps, 500 kbps, 1 Mbps CANopen
Data format
8 bits, 1 stop, even parity Modbus on front face
8 bits, odd even or no configurable parity Modbus on terminal
Number of addresses
1…127 CANopen
1…247 Modbus
Method of access
Slave CANopen
marking
CE
Operating position
Vertical +/- 10 degree
Product Weight
185.19 lb(US) (84 kg)
Width
12.60 in (320 mm)
Height
36.22 in (920 mm)
Depth
14.84 in (377 mm)
Environment
Noise level
60.5 dB 86/188/EEC
Dielectric strength
3535 V DC between earth and power terminals
5092 V DC between control and power terminals
Electromagnetic compatibility
Conducted radio-frequency immunity test level 3 IEC 61000-4-6
Electrical fast transient/burst immunity test level 4 IEC 61000-4-4
Electrostatic discharge immunity test level 3 IEC 61000-4-2
Radiated radio-frequency electromagnetic field immunity test level 3 IEC 61000-4-3
Voltage dips and interruptions immunity test IEC 61000-4-11
standards
EN 61800-3 environments 2 category C3
EN 55011 class A group 2
UL Type 1
IEC 60721-3-3 class 3C2
EN/IEC 61800-5-1
EN 61800-3 environments 1 category C3
EN/IEC 61800-3
Product Certifications
C-tick
DNV
GOST
CSA
UL
NOM 117
Pollution degree
3 EN/IEC 61800-5-1
3 UL 840
degree of proctection
IP41 on upper part EN/IEC 60529
IP41 on upper part EN/IEC 61800-5-1
IP54 on lower part EN/IEC 60529
IP54 on lower part EN/IEC 61800-5-1
IP00 EN/IEC 60529
IP00 EN/IEC 61800-5-1
IP30 on side parts EN/IEC 60529
IP30 on side parts EN/IEC 61800-5-1
IP30 on the front panel EN/IEC 60529
IP30 on the front panel EN/IEC 61800-5-1
Vibration resistance
0.6 gn 10…200 Hz)EN/IEC 60068-2-6
1.5 mm peak to peak 3…10 Hz)EN/IEC 60068-2-6
Shock resistance
7 gn 11 ms EN/IEC 60068-2-27
Relative humidity
5…95 % without condensation IEC 60068-2-3
5…95 % without dripping water IEC 60068-2-3
Ambient air temperature for operation
14…113 °F (-10…45 °C) without derating)
113…140 °F (45…60 °C) with derating factor)
Ambient Air Temperature for Storage
-13…158 °F (-25…70 °C)
Operating altitude
<= 3280.84 ft (1000 m) without derating
3280.84...9842.52 ft (1000...3000 m) with current derating 1 % per 100 m
Ordering and shipping details
Category
22138-ATV61 60 THRU 150 HP DRIVES
Discount Schedule
CP4C
GTIN
00785901639640
Returnability
No
Country of origin
IN
Contractual warranty
Warranty
18 months
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
Single-phase supply voltage: 200…240 V 50/60 Hz | ||||||
| 0.37 | 0.5 | 6.9 | 5.8 | 1.4 | 5 | 3 | 3.6 | ATV61H075M3 | 3.000 | |
| 0.75 | 1 | 12 | 9.9 | 2.4 | 5 | 4.8 | 5.7 | ATV61HU15M3 | 3.000 | |
| 1.5 | 2 | 18.2 | 15.7 | 3.7 | 5 | 8 | 9.6 | ATV61HU22M3 | 4.000 | |
| 2.2 | 3 | 25.9 | 22.1 | 5.3 | 5 | 11 | 13.2 | ATV61HU30M3 | 4.000 | |
| 3 | – | 25.9 | 22 | 5.3 | 5 | 13.7 | 16.4 | ATV61HU40M3 (3) | 4.000 | |
| 4 | 5 | 34.9 | 29.9 | 7 | 5 | 17.5 | 21 | ATV61HU55M3 (3) | 5.500 | |
| 5.5 | 7.5 | 47.3 | 40.1 | 9.5 | 22 | 27.5 | 33 | ATV61HU75M3 (3) | 7.000 |
IP 20 drives | ||||||
Motor | Line supply | Altivar 61 | ||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference current for 60 s
A | Weight
kg |
200 V 240 V A A | 240 V kVA | 230 V A | ||||
| Three-phase supply voltage: 200…240 V 50/60 Hz | ||||||
0.75 | 1 | 6.1 | 5.3 | 2.2 | 5 | 4.8 | 5.7 | ATV61H075M3 | 3.000 |
1.5 | 2 | 11.3 | 9.6 | 4 | 5 | 8 | 9.6 | ATV61HU15M3 | 3.000 |
2.2 | 3 | 15 | 12.8 | 5.3 | 5 | 11 | 13.2 | ATV61HU22M3 | 4.000 |
3 | – | 19.3 | 16.4 | 6.8 | 5 | 13.7 | 16.4 | ATV61HU30M3 | 4.000 |
4 | 5 | 25.8 | 22.9 | 9.5 | 5 | 17.5 | 21 | ATV61HU40M3 | 4.000 |
5.5 | 7.5 | 35 | 30.8 | 12.8 | 22 | 27.5 | 33 | ATV61HU55M3 | 5.500 |
7.5 | 10 | 45 | 39.4 | 16.4 | 22 | 33 | 39.6 | ATV61HU75M3 | 7.000 |
11 | 15 | 53.3 | 45.8 | 19 | 22 | 54 | 64.8 | ATV61HD11M3X (4) | 22.000 |
15 | 20 | 71.7 | 61.6 | 25.6 | 22 | 66 | 79.2 | ATV61HD15M3X (4) | 22.000 |
18.5 | 25 | 77 | 69 | 28.7 | 22 | 75 | 90 | ATV61HD18M3X (4) | 30.000 |
22 | 30 | 88 | 80 | 33.3 | 22 | 88 | 105.6 | ATV61HD22M3X (4) | 30.000 |
30 | 40 | 124 | 110 | 45.7 | 22 | 120 | 144 | ATV61HD30M3X (4) | 37.000 |
37 | 50 | 141 | 127 | 52.8 | 22 | 144 | 172.8 | ATV61HD37M3X (4) | 37.000 |
45 | 60 | 167 | 147 | 61.1 | 22 | 176 | 211.2 | ATV61HD45M3X (4) | 37.000 |
55 | 75 | 200 | 173 | 71.9 | 35 | 221 | 265.2 | ATV61HD55M3X (4) | 84.000 |
75 | 100 | 271 | 232 | 96.4 | 35 | 285 | 342 | ATV61HD75M3X (4) | 84.000 |
90 | 125 | 336 | 288 | 119.7 | 35 | 359 | 431 | ATV61HD90M3X (4) | 106.000 |
IP 20 drives with integrated category C2 or C3 EMC filter | |||||
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent Max. power prospective line Isc 380 V
kVA kA | Maximum continuous current (1) | Max. transient Reference current for 60 s | Weight
kg |
380 V 480 V
A A | 380 V 460 V (IEC) (NEC) A A | ||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 3.7 | 3 | 2.4 | 5 | 2.3 | 2.1 | 2.7 | ATV61H075N4 | 3.000 |
| 1.5 | 2 | 5.8 | 5.3 | 3.8 | 5 | 4.1 | 3.4 | 4.9 | ATV61HU15N4 | 3.000 |
| 2.2 | 3 | 8.2 | 7.1 | 5.4 | 5 | 5.8 | 4.8 | 6.9 | ATV61HU22N4 | 3.000 |
| 3 | – | 10.7 | 9 | 7 | 5 | 7.8 | 6.2 | 9.3 | ATV61HU30N4 | 4.000 |
| 4 | 5 | 14.1 | 11.5 | 9.3 | 5 | 10.5 | 7.6 | 12.6 | ATV61HU40N4 | 4.000 |
| 5.5 | 7.5 | 20.3 | 17 | 13.4 | 22 | 14.3 | 11 | 17.1 | ATV61HU55N4 | 5.500 |
| 7.5 | 10 | 27 | 22.2 | 17.8 | 22 | 17.6 | 14 | 21.1 | ATV61HU75N4 | 5.500 |
| 11 | 15 | 36.6 | 30 | 24.1 | 22 | 27.7 | 21 | 33.2 | ATV61HD11N4 | 7.000 |
| 15 | 20 | 48 | 39 | 31.6 | 22 | 33 | 27 | 39.6 | ATV61HD15N4 | 22.000 |
| 18.5 | 25 | 45.5 | 37.5 | 29.9 | 22 | 41 | 34 | 49.2 | ATV61HD18N4 | 22.000 |
| 22 | 30 | 50 | 42 | 32.9 | 22 | 48 | 40 | 57.6 | ATV61HD22N4 | 30.000 |
| 30 | 40 | 66 | 56 | 43.4 | 22 | 66 | 52 | 79.2 | ATV61HD30N4 | 37.000 |
| 37 | 50 | 84 | 69 | 55 | 22 | 79 | 65 | 94.8 | ATV61HD37N4 | 37.000 |
| 45 | 60 | 104 | 85 | 68.5 | 22 | 94 | 77 | 112.8 | ATV61HD45N4 | 44.000 |
| 55 | 75 | 120 | 101 | 79 | 22 | 116 | 96 | 139.2 | ATV61HD55N4 | 44.000 |
| 75 | 100 | 167 | 137 | 109.9 | 22 | 160 | 124 | 192 | ATV61HD75N4 | 44.000 |
| 90 | 125 | 166 | 143 | 109.3 | 35 | 179 | 179 | 214.8 | ATV61HD90N4 | 84.000 |
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61HC11N4 | 84.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61HC13N4 | 106.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61HC16N4 | 116.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 427 | 427 | 512.4 | ATV61HC22N4 | 163.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | |||||
| 250 | 400 | 444 | 435 | 292.2 | 50 | 481 | 481 | 577.2 | ATV61HC25N4 | 207.000 |
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61HC31N4 | 207.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61HC40N4 | 320.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61HC50N4 | 330.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61HC63N4 | 435.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Water-cooled IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1)
kW HP | Line current Apparent (2) power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s
A kg |
380 V 480 V 380 V
A A kVA | 380 V 460 V (IEC) (NEC) A | |||
Three-phase supply voltage: 380…480 V 50/60 Hz | ||||
| 110 | 150 | 202 | 168 | 133 | 35 | 215 | 215 | 258 | ATV61QC11N4 | 80.000 |
| 132 | 200 | 239 | 224 | 157.3 | 35 | 259 | 259 | 310.8 | ATV61QC13N4 | 80.000 |
| 160 | 250 | 289 | 275 | 190.2 | 50 | 314 | 314 | 376.8 | ATV61QC16N4 | 80.000 |
| 200 | 300 | 357 | 331 | 235 | 50 | 387 | 387 | 464 | ATV61QC20N4 | 140.000 |
| 220 | 350 | 396 | 383 | 260.6 | 50 | 481 | 481 | 577.2 | ATV61QC25N4 | 140.000 |
| 250 | 400 | 444 | 435 | 292.2 | 50 | |||||
| 280 | 450 | 494 | 494 | 325.1 | 50 | 616 | 616 | 739.2 | ATV61QC31N4 | 140.000 |
| 315 | 500 | 555 | 544 | 365.3 | 50 | |||||
| 355 | – | 637 | 597 | 419.3 | 50 | 759 | 759 | 910.8 | ATV61QC40N4 | 300.000 |
| 400 | 600 | 709 | 644 | 466.6 | 50 | |||||
| 500 | 700 | 876 | 760 | 576.6 | 50 | 941 | 941 | 1129.2 | ATV61QC50N4 | 300.000 |
| 560 | 800 | 978 | 858 | 643.6 | 50 | 1188 | 1188 | 1425.6 | ATV61QC63N4 | 300.000 |
| 630 | 900 | 1091 | 964 | 718 | 50 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C2 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4 | 13.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4 | 13.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4 | 13.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4 | 14.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4 | 16.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4 | 16.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4 | 22.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4 | 22.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4 | 28.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4 | 36.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4 | 36.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4 | 51.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4 | 64.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4 | 65.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4 | 92.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4 | 92.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4 | 92.000 |
Motor | Line supply | Altivar 61 | |||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current (1) | Max. transient Reference Weight current for 60 s |
380 V 480 V
A A | 380 V
kVA | 380 V 460 V (IEC) (NEC) A A kg | |||
IP 54 drives with integrated category C1 EMC filter | |||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61W075N4C | 19.000 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61WU15N4C | 19.000 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61WU22N4C | 20.000 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61WU30N4C | 20.000 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61WU40N4C | 23.000 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61WU55N4C | 23.000 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61WU75N4C | 32.000 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61WD11N4C | 32.000 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61WD15N4C | 40.000 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61WD18N4C | 51.000 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61WD22N4C | 50.000 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61WD30N4C | 68.000 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61WD37N4C | 85.000 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61WD45N4C | 85.000 |
| 55 | 75 | 104.8 | 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61WD55N4C | 119.000 |
| 75 | 100 | 140.3 | 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61WD75N4C | 119.000 |
| 90 | 125 | 171.8 | 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61WD90N4C | 119.000 |
IP 54 drives with integrated Vario switch disconnector and category C2 EMC filter | |||||||||
Three-phase supply voltage: 380…480 V 50/60 Hz | |||||||||
Motor | Line supply | Altivar 61 | |||||||
Power indicated on rating plate (1)
kW HP | Line current (2) | Apparent power | Max. prospective line Isc
kA | Maximum continuous current In (1) | Max. Reference Weight transient current for 60 s
A kg | ||||
380 V A | 480 V 380 V A kVA | 380 V A | 460 V A | ||||||
| 0.75 | 1 | 1.8 | 1.5 | 1.2 | 5 | 2.3 | 2.1 | 2.5 | ATV61E5075N4 | 16.400 |
| 1.5 | 2 | 3.5 | 3 | 2.3 | 5 | 4.1 | 3.4 | 4.5 | ATV61E5U15N4 | 16.400 |
| 2.2 | 3 | 5 | 4.1 | 3.3 | 5 | 5.1 | 4.8 | 5.6 | ATV61E5U22N4 | 16.400 |
| 3 | – | 6.7 | 5.6 | 4.4 | 5 | 7.2 | 6.2 | 7.9 | ATV61E5U30N4 | 16.400 |
| 4 | 5 | 8.8 | 7.4 | 5.8 | 5 | 9.1 | 7.6 | 10 | ATV61E5U40N4 | 18.400 |
| 5.5 | 7.5 | 11.4 | 9.2 | 7.5 | 22 | 12 | 11 | 13.2 | ATV61E5U55N4 | 18.400 |
| 7.5 | 10 | 15.8 | 13.3 | 10.4 | 22 | 16 | 14 | 17.6 | ATV61E5U75N4 | 22.700 |
| 11 | 15 | 21.9 | 17.8 | 14.4 | 22 | 22.5 | 21 | 24.7 | ATV61E5D11N4 | 22.700 |
| 15 | 20 | 30.5 | 25.8 | 20 | 22 | 30.5 | 27 | 33.5 | ATV61E5D15N4 | 36.700 |
| 18.5 | 25 | 37.5 | 32.3 | 24.7 | 22 | 37 | 34 | 40.7 | ATV61E5D18N4 | 45.400 |
| 22 | 30 | 43.6 | 36.6 | 28.7 | 22 | 43.5 | 40 | 47.8 | ATV61E5D22N4 | 45.400 |
| 30 | 40 | 56.7 | 46.2 | 37.3 | 22 | 58.5 | 52 | 64.3 | ATV61E5D30N4 | 52.800 |
| 37 | 50 | 69.5 | 56.8 | 45.7 | 22 | 71.5 | 65 | 78.6 | ATV61E5D37N4 | 65.800 |
| 45 | 60 | 85.1 | 69.6 | 56 | 22 | 85 | 77 | 93.5 | ATV61E5D45N4 | 65.800 |
| 55 | 75 | 104.8 87 | 69 | 35 | 103 | 96 | 113.3 | ATV61E5D55N4 | 84.400 | |
| 75 | 100 | 140.3 113.8 | 92.3 | 35 | 137 | 124 | 150.7 | ATV61E5D75N4 | 84.400 | |
| 90 | 125 | 171.8 140.9 | 113 | 35 | 163 | 156 | 179.3 | ATV61E5D90N4 | 84.400 | |
IP 20 drives | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference Weight
kg |
500 V 575 V kW HP | 500 V 600 V A A | 500 V 575 V A A | ||
Three-phase supply voltage: 500…600 V 50/60 Hz | ||||
2.2 |
3 |
7.6 |
6.7 |
22 |
4.5 |
3.9 |
ATV61HU22S6X |
7.500 |
3 | – | 9.9 | 10 | 22 | 5.8 | – | ATV61HU30S6X | 7.500 |
4 | 5 | 12.5 | 10.9 | 22 | 7.5 | 6.1 | ATV61HU40S6X | 7.500 |
5.5 | 7.5 | 16.4 | 14.2 | 22 | 10 | 9 | ATV61HU55S6X | 7.500 |
7.5 | 10 | 21.4 | 18.4 | 22 | 13.5 | 11 | ATV61HU75S6X | 7.500 |
IP 20 drives with integrated category C3 EMC filter | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
2.2 | 3 | 5.2 | 4.4 | 5.2 | 22 | 4.5 | 3.9 | 4.5 | ATV61HU30Y | 30.000 |
3 | 4 | 6.8 | – | 6.6 | 22 | 5.8 | – | 5.5 | ATV61HU40Y | 30.000 |
4 | 5.5 | 8.6 | 7.2 | 8.6 | 22 | 7.5 | 6.1 | 7.5 | ATV61HU55Y | 30.000 |
5.5 | 7.5 | 11.2 | 9.5 | 11.2 | 22 | 10 | 9 | 10 | ATV61HU75Y | 30.000 |
7.5 | 11 | 14.6 | 12.3 | 15.5 | 22 | 13.5 | 11 | 13.5 | ATV61HD11Y | 30.000 |
11 | 15 | 19.8 | 16.7 | 20.2 | 22 | 18.5 | 17 | 18.5 | ATV61HD15Y | 30.000 |
15 | 18.5 | 24.6 | 20.7 | 24 | 22 | 24 | 22 | 24 | ATV61HD18Y | 30.000 |
18.5 | 22 | 29 | 24 | 27 | 22 | 29 | 27 | 27 | ATV61HD22Y | 30.000 |
22 | 30 | 33 | 28 | 34 | 22 | 35 | 32 | 35 | ATV61HD30Y | 30.000 |
30 | 37 | 48 | 41 | 47 | 22 | 47 | 41 | 43 | ATV61HD37Y | 68.000 |
37 | 45 | 62 | 51 | 55 | 22 | 59 | 52 | 54 | ATV61HD45Y | 68.000 |
45 | 55 | 68 | 57 | 63 | 22 | 68 | 62 | 62 | ATV61HD55Y | 68.000 |
55 | 75 | 79 | 67.0 | 82 | 22 | 85 | 77 | 84 | ATV61HD75Y | 68.000 |
75 | 90 | 109 | 92 | 101 | 22 | 110 | 99 | 104 | ATV61HD90Y | 68.000 |
90 | 110 | 128 | 113 | 117 | 22 | 136 | 125 | 125 | ATV61HC11Y (4) | 102.000 |
110 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61HC13Y (4) | 102.000 |
132 | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61HC16Y (4) | 102.000 |
160 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61HC20Y (4) | 102.000 |
200 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61HC25Y (4) | 181.000 |
250 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61HC31Y (4) | 181.000 |
315 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61HC40Y (4) | 181.000 |
400 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61HC50Y (4) | 383.000 |
500 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61HC63Y (4) | 383.000 |
630 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61HC80Y (4) | 383.000 |
Water-cooled IP 20 drives | ||||
Three-phase supply voltage: 500…690 V 50/60 Hz | ||||
Motor | Line supply | Altivar 61 | ||
Power indicated on rating plate (1) | Line current (2) | Max. prospective line Isc
kA | Maximum continuous current (1) (3) | Reference (4) Weight
kg |
500 V 575 V 690 V kW HP kW | 500 V 600 V 690 V A A A | 500 V 575 V 690 V A A A | ||
110 | 150 | 132 | 153 | 133 | 137 | 28 | 165 | 144 | 150 | ATV61QC13Y | 80.000 |
132 | – | 160 | 182 | 158.9 | 163 | 28 | 200 | – | 180 | ATV61QC16Y | 80.000 |
160 | 200 | 200 | 218 | 197 | 199 | 35 | 240 | 192 | 220 | ATV61QC20Y | 80.000 |
200 | 250 | 250 | 277 | 250 | 257 | 35 | 312 | 242 | 290 | ATV61QC25Y | 140.000 |
250 | 350 | 315 | 342 | 311 | 317 | 35 | 390 | 336 | 355 | ATV61QC31Y | 140.000 |
315 | 450 | 400 | 426 | 390 | 394 | 35 | 462 | 412 | 420 | ATV61QC40Y | 140.000 |
400 | 550 | 500 | 547 | 494 | 505 | 35 | 590 | 528 | 543 | ATV61QC50Y | 300.000 |
500 | 700 | 630 | 673 | 613 | 616 | 42 | 740 | 672 | 675 | ATV61QC63Y | 300.000 |
630 | 800 | 800 | 847 | 771 | 775 | 42 | 900 | 768 | 840 | ATV61QC80Y | 300.000 |
Previous : Schneider Electric Altivar61 VFD VSD AC Drive 75kw/100hp 380V/167A 480V/137A Schneider ATV61HD75N4 Weight 44kg
Next : 6SR0960-0CB13-0AA0, fiber-optic cable module 461D85.00 NXGII-Version, LDZ461D85.00C, A1A461D85.00, Successor: 6SR3900-0LM00-1AD0(A1A461D85.00M)
Copy product links
Long by picture save/share
Schneider Electric Altivar61 VFD VSD AC Drive 90kw/125hp 380V/166A 480V/143A Schneider ATV61HD90N4 Weight 84kg
INQUIRY
Add Successfully
We are the world's leading supplier of spare parts for medium voltage drives of various brands
点击右上角
分享给朋友吧
GET IN TOUCH
East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong
Call us : +852 5261 7322
Email us : [email protected]
SITEMAP
BUSINESS HOURS
Monday to Friday : 9 am to 6 pm
Saturday : 9 am to 12 am
Sunday : Closed Support Hours in 24/7 Everyday
DISCLAIMER:
We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.
© 2020 robiconperfectharmony.com site . All rights reserved Site Map
