Motor voltage 3.3 kV | ||||||||
Output current [A] | Type rating [kVA] | Shaft output |
Transformer [kVA] |
Order number (MLFB) |
Generation |
No. of cells |
Outline | |
[kW] [hp] | ||||||||
40 | 225 | 189 | 254 | 300 | 6SR4102-0[]A33-0[][]0 | GenIV | 9 | A |
70 | 400 | 331 | 444 | 450 | 6SR4102-0[]B34-5[][]0 | GenIV | 9 | A |
100 | 570 | 473 | 634 | 700 | 6SR4102-0[]C37-0[][]0 | GenIV | 9 | A |
140 | 800 | 662 | 887 | 900 | 6SR4102-0[]D38-7[][]1 | GenIV | 9 | A |
200 | 1140 | 970 | 1300 | 1500 | 6SR4102-0[]E41-5[][]0 | GenIV | 9 | A |
260 | 1485 | 1261 | 1690 | 1750 | 6SR4102-0[]F41-7[][]0 | GenIV | 9 | A |
315 | 1800 | 1527 | 2047 | 2250 | 6SR3102-1[]G42-2[][]0 | GenIIIe | 9 | B |
375 | 2140 | 1818 | 2437 | 2500 | 6SR3102-1[]H42-5[][]0 | GenIIIe | 9 | B |
500 | 2855 | 2424 | 3250 | 3500 | 6SR3102-1[]J43-5[][]0 | GenIIIe | 9 | B |
Motor voltage 4.0/4.16 kV | ||||||||
Output current [A] | Type rating [kVA] | Shaft output |
Transformer [kVA] |
Order number (MLFB) |
Generation |
No. of cells |
Outline | |
[kW] [hp] | ||||||||
40 | 275 | 229 | 307 | 400 | 6SR4102-0[]A34-0[][]0 | GenIV | 9 | A |
70 | 480 | 401 | 538 | 600 | 6SR4102-0[]B36-0[][]0 | GenIV | 9 | A |
100 | 690 | 573 | 768 | 800 | 6SR4102-0[]C38-0[][]0 | GenIV | 9 | A |
140 | 965 | 802 | 1075 | 1100 | 6SR4102-0[]D41-1[][]0 | GenIV | 9 | A |
200 | 1385 | 1175 | 1576 | 1750 | 6SR4102-0[]E41-7[][]0 | GenIV | 9 | A |
260 | 1800 | 1528 | 2048 | 2250 | 6SR4102-0[]F42-2[][]0 | GenIV | 9 | A |
315 | 2265 | 1925 | 2581 | 3000 | 6SR3102-3[]G43-0[][]0 | GenIIIe | 12 | B |
375 | 2700 | 2292 | 3073 | 3500 | 6SR3102-3[]H43-5[][]0 | GenIIIe | 12 | B |
500 | 3600 | 3056 | 4097 | 5000 | 6SR3102-3[]J45-0[][]0 | GenIIIe | 12 | B |
630 | 4540 | 3851 | 5162 | 6000 | 6SR3102-3[]K46-0[][]0 | GenIIIe | 12 | B |
Motor voltage 6.0 kV | ||||||||
Output current [A] | Type rating [kVA] | Shaft output |
Transformer [kVA] |
Order number (MLFB) |
Generation |
No. of cells |
Outline | |
[kW] [hp] | ||||||||
40 | 415 | 344 | 461 | 500 | 6SR4102-2[]A35-0[][]0 | GenIV | 15 | C |
70 | 725 | 602 | 807 | 900 | 6SR4102-2[]B38-7[][]0 | GenIV | 15 | C |
100 | 1035 | 860 | 1152 | 1250 | 6SR4102-2[]C41-2[][]0 | GenIV | 15 | C |
140 | 1450 | 1203 | 1613 | 1750 | 6SR4102-2[]D41-7[][]0 | GenIV | 15 | C |
200 | 2075 | 1763 | 2363 | 2500 | 6SR4102-2[]E42-5[][]0 | GenIV | 15 | C |
260 | 2700 | 2292 | 3073 | 3500 | 6SR4102-2[]F43-5[][]0 | GenIV | 15 | C |
315 | 3270 | 2777 | 3722 | 4000 | 6SR3102-5[]G44-0[][]0 | GenIIIe | 15 | B |
375 | 3895 | 3306 | 4432 | 5000 | 6SR3102-5[]H45-0[][]0 | GenIIIe | 15 | B |
500 | 5195 | 4408 | 5909 | 6000 | 6SR3102-5[]J46-0[][]0 | GenIIIe | 15 | B |
630 | 6550 | 5554 | 7445 | 8000 | 6SR3102-5[]K48-0[][]0 | GenIIIe | 15 | B |
Motor voltage 6.6 kV | ||||||||
Output current [A] | Type rating [kVA] | Shaft output |
Transformer [kVA] |
Order number (MLFB) |
Generation |
No. of cells |
Outline | |
[kW] [hp] | ||||||||
40 | 455 | 378 | 507 | 600 | 6SR4102-2[]A36-0[][]0 | GenIV | 15 | C |
70 | 800 | 662 | 887 | 900 | 6SR4102-2[]B38-7[][]0 | GenIV | 15 | C |
100 | 1140 | 946 | 1268 | 1500 | 6SR4102-2[]C41-5[][]0 | GenIV | 15 | C |
140 | 1600 | 1324 | 1775 | 2000 | 6SR4102-2[]D42-0[][]0 | GenIV | 15 | C |
200 | 2285 | 1939 | 2600 | 3000 | 6SR4102-2[]E43-0[][]0 | GenIV | 15 | C |
260 | 2970 | 2521 | 3380 | 3500 | 6SR4102-2[]F43-5[][]0 | GenIV | 15 | C |
315 | 3600 | 3055 | 4095 | 5000 | 6SR3102-7[]G45-0[][]0 | GenIIIe | 18 | B |
375 | 4285 | 3636 | 4875 | 5000 | 6SR3102-7[]H45-0[][]0 | GenIIIe | 18 | B |
500 | 5715 | 4849 | 6500 | 7000 | 6SR3102-7[]J47-0[][]0 | GenIIIe | 18 | B |
615 | 7040 | 5968 | 8000 | 8000 | 6SR3102-7[]K48-0[][]0 | GenIIIe | 18 | B |
615A, 6600V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-7.K48-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-7.K48-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:8000 HP
Rated Amps:615 A
Rated Voltage:6600 V
Rated Input Frequency:60 Hz
Output Voltage:6600 V
Output Amperage Rating:615 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
500A, 6600V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-7.J47-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-7.J47-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:6500 HP
Rated Amps:500 A
Rated Voltage:6600 V
Rated Input Frequency:60 Hz
Output Voltage:6600 V
Output Amperage Rating:500 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
375A, 6600V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-7.H45-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-7.H45-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:4875 HP
Rated Amps:375 A
Rated Voltage:6600 V
Rated Input Frequency:60 Hz
Output Voltage:6600 V
Output Amperage Rating:375 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
315A, 6600V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-7.G45-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-7.G45-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:4095 HP
Rated Amps:315 A
Rated Voltage:6600 V
Rated Input Frequency:60 Hz
Output Voltage:6600 V
Output Amperage Rating:315 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
630A, 6000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-5.K48-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-5.K48-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:7445 HP
Rated Amps:630 A
Rated Voltage:6000 V
Rated Input Frequency:60 Hz
Output Voltage:6000 V
Output Amperage Rating:630 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
500A, 6000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-5.J46-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-5.J46-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:5909 HP
Rated Amps:500 A
Rated Voltage:6000 V
Rated Input Frequency:60 Hz
Output Voltage:6000 V
Output Amperage Rating:500 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
375A, 6000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-5.H45-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-5.H45-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:4432 HP
Rated Amps:375 A
Rated Voltage:6000 V
Rated Input Frequency:60 Hz
Output Voltage:6000 V
Output Amperage Rating:375 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
315A, 6000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-5.G44-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-5.G44-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:3722 HP
Rated Amps:315 A
Rated Voltage:6000 V
Rated Input Frequency:60 Hz
Output Voltage:6000 V
Output Amperage Rating:315 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
630A, 4000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-3.K46-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-3.K46-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:5162 HP
Rated Amps:630 A
Rated Voltage:4000 V
Rated Input Frequency:60 Hz
Output Voltage:4000 V
Output Amperage Rating:630 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
500A, 4000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-3.J45-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-3.J45-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:4097 HP
Rated Amps:500 A
Rated Voltage:4000 V
Rated Input Frequency:60 Hz
Output Voltage:4000 V
Output Amperage Rating:500 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
375A, 4000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-3.H43-5..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-3.H43-5..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:3073 HP
Rated Amps:375 A
Rated Voltage:4000 V
Rated Input Frequency:60 Hz
Output Voltage:4000 V
Output Amperage Rating:375 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
315A, 4000V, Siemens ROBICON Perfect Harmony GenIIIe VFD (6SR3102-3.G43-0..0)
Series:ROBICON Perfect Harmony GenIIIe
Model:6SR3102-3.G43-0..0
Brand:SIEMENS
Product Condition:New
Horsepower Rating:2581 HP
Rated Amps:315 A
Rated Voltage:4000 V
Rated Input Frequency:60 Hz
Output Voltage:4000 V
Output Amperage Rating:315 A
Phase Rating:3 Phase Input - 3 Phase Output
Phase:Three Phase
Ambient Tempurature Rating:40 °C
Enclosure Rating:IP 21
Frame Size:B
Weight:0.01 LBS
