Table 9-1:  Spare Parts List



Spare Part



Control

Voltage



Item

Part Number





Power Cell* Qty: 1


70A Cell

A1A460Y83.070

100A Cell

A1A460Y83.100

140A Cell

A1A4608C0.140


200A Cell

A1A461D63.2000

260A Cell

A1A461D63.260




Cell Input

Fuses



Qty: 3 per cell


70A Cell

A1A093503

100A Cell

A1A093502

140A Cell

A1A090391


200A Cell

A1A093504

260A Cell

A1A093505


Transformer

Cabinet

Air Filters


46” Cabinet, A1A090335, Qty 3

60” Cabinet, A1A090053, Qty. 3

80” Cabinet, A1A091389, Qty. 3



Cell Cabinet

Air Filters


77” Cabinet

A1A090335

Qty:8

54” and 112” Cabinets

A1A090053

Qty: 4 for 54” Cabinet and 6 for 112” Cabinet











NXGII Qty: 1


SBC and Keypad Adapter A1A10000623.00M



System I/O Board

A1A10000423.00M



BGA Modulator

A1A10000350.00M

I/O Breakout Board

120V I/O A5E01649325


Communications Board A1A363818.00M



NXGII Power Supply

A1A14000461.00



Signal Control Board

A5E01708486

I/O Breakout Board

24V I/O A5E01649374




Backplane

A1A363628.00

Fiber Optic Link board** A1A461D85.00



Keypad

A1A460A68.23












WAGO I/O Modules



Qty: 1


1–2 Channel Digital Input, 120 VAC A1A091537

1– 4 Channel Digital Input, 24 VDC A1A090789


1– 2 Channel Analog Input, 4-20mA A1A091113

1– 2 Channel Analog Input, 0-10V A1A092745


1– 2 Channel Relay Output, 120Vac or 24

VDC A1A092363



1– 2 Channel Analog Output, 4-20mA A1A091539


Field bus coupler

A1A091143


Spare Part



Control

Voltage



Item

Part Number















Control Transformer Fuses



575V Control

Primary Fuse 2.5A, 600 VAC A1AH024968

Qty: 2

Secondary Fuse 6A, 600 VAC A1A081099

Qty: 1



480V Control

Primary Fuse 3.0A, 600 VAC A1A080752

Qty: 2




230V /

380V /

415V Control

Primary Fuse 3.5A, 600 VAC A1A089205

Qty: 2




200V Control

Primary Fuse 4.0A, 600 VAC A1A081097

Qty: 2












Input CT Qty: 2


CT, 50:5

A1A091705

CT, 75:5

A1A091706

CT, 100:5

A1A091707

CT, 150:5

A1A091708


CT, 200:5

A1A091709

CT, 250:5

A1A091710

CT, 300:5

A1A091711

CT, 400:5

A1A091712


CT, 500:5

A1A091713

CT, 600:5

A1A091714

CT, 750:5

A1A091715

CT, 800:5

A1A091716


CT, 1000:5

A1A091717

CT, 200:5

A1A096254

CT, 3000:5

A1A096255




Communicati ons Network



Qty: 1


Profibus DP A1A252241.155

Devicenet Profile 12

A1A2252241.156

Modbus Ethernet

A1A252241.157


Control Net

A1A252241.158

Modbus + A1A252241.159












Input Voltage

Attenuator



Qty: 3


2 4 kV A1A164877.00

3.0 kV A1A164877.01

3.3 kV A1A164877.02

4.16 kV A1A164877.03


4.8 kV A1A164877.04

6.0 kV A1A164877.05

6.6 kV A1A164877.06

6.9 kV A1A164877.07


7.2 kV A1A164877.08

8.4 kV A1A164877.09

10 kV A1A164877.10

11 kV A1A164877.11


12 kV A1A164877.12

12.5 kV A1A164877.13

13.2 kV A1A164877.14

13.8 kV A1A164877.15





Output Voltage Attenuator

Qty: 3


2 4 kV A1A164877.00

3.0 kV A1A164877.01

3.3 kV A1A164877.02

4.16 kV A1A164877.03


4.8 kV A1A164877.04

6.0 kV A1A164877.05

6.6 kV A1A164877.06

6.9 kV A1A164877.07


7.2 kV A1A164877.08




Spare Part



Control

Voltage



Item

Part Number















Cell Bypass


Bypass Contactor

A1A252090.776

Qty: 1 per cell

Bypass Control PCA A1A363662.01M Qty: 1


For 630V Secondaries



Bypass Power Supply

A5A363549.00

Qty: 1



Bypass Power Supply Fuse

A1A090674

Qty: 2







Blower



Qty: 1



EBM RH56 Blower (46” / 60” / 80” Transformer Cabinet)



EBM RH50 Blower

(77” Cell Cabinet)



EBM RH71 Blower

(112” Cell Cabinet)


Other than 575V

A1A089659

A1A090428

A1A089659


575V

A1A090215

A1A091243

A1A090215

Cell Lifter



Qty: 1




A1A163496.04

*Customer may request IGBTs, diode rectifiers, and Cell Control Boards rather than a complete spare cell. Contact Siemens for further information regarding individual cell P/Ns.

**Used if more than 12 cells.

Line-up



200V/50Hz



230V/60Hz



380V/50Hz



415V/50Hz



460V/60Hz



575V/60Hz





60/54



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

3A, 600V A1A090206



Fuse Class J,

2.25A, 600V A1A090712





60/54 R



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

3A, 600V A1A090206



Fuse Class J,

2.25A, 600V A1A090712











60/77



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4A, 600V A1A090207



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5A, 600V A1A090211















60/77 R



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V A1A090211



Fuse Class J,

2.5A, 600V A1A090714 and

Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637











60/112



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637











60/112 R



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637

Line-up



200V/50Hz



230V/60Hz



380V/50Hz



415V/50Hz



460V/60Hz



575V/60Hz











80/77



Fuse Class J,

7A, 600V A1A090069 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

7A, 600V A1A090069 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

5A, 600V A1A090211 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

4A, 600V A1A090207 and

Fuse Class J,

4.5A, 600V A1A089637















80/77 R



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V, A1A090211



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V A1A090211



Fuse Class J,

2.5A, 600V A1A090714 and

Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637





80/112



Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

4.5A, 600V A1A089637











80/112 R



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637



Transformer/Cell Blower Fuses (24 VDC), Qty: 3





46/54



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

4.5A 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

3A, 600V A1A090206



Fuse Class J,

2.25A, 600V A1A090712











46/77



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4A, 600V A1A090207



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5A, 600V A1A090211

Line-up



200V/50Hz



230V/60Hz



380V/50Hz



415V/50Hz



460V/60Hz



575V/60Hz





60/54



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

3A, 600V A1A090206



Fuse Class J,

2.25A, 600V A1A090712





60/54 R



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

2.8A, 600V A1A090711



Fuse Class J,

3A, 600V A1A090206



Fuse Class J,

2.25A, 600V A1A090712











60/77



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4A, 600V A1A090207



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5A, 600V A1A090211















60/77 R



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

7A, 600V A1A090069



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V A1A090211



Fuse Class J,

2.5A, 600V A1A090714 and

Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637











60/112



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A08133



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637















60/112 R







Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333







Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637







Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148







Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637

Line-up



200V/50Hz



230V/60Hz



380V/50Hz



415V/50Hz



460V/60Hz



575V/60Hz











80/77



Fuse Class J,

7A, 600V A1A090069 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

7A, 600V A1A090069 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

5A, 600V A1A090211 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

4A, 600V A1A090207 and

Fuse Class J,

4.5A, 600V A1A089637















80/77 R



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

3.5A, 600V A1A090713 and

Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

8A, 600V A1A089149



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V A1A090211



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5A, 600V A1A090211



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2A, 600V A1A090715 and

Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637





80/112



Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

4.5A, 600V, A1A089637











80/112 R



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

4.5A, 600V A1A089637 and

Fuse Class J,

9A, 600V A1A081333



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

2.8A, 600V A1A090711 and

Fuse Class J,

5.6A, 600V A1A090716



Fuse Class J,

3A, 600V A1A090206 and

Fuse Class J,

6A, 600V A1A089148



Fuse Class J,

2.25A, 600V A1A090712 and

Fuse Class J,

4.5A, 600V A1A089637


Previous : Siemens Robicon Master Link Board (MLB) 469147.04VT, Keypad (KPD) 460A68.00T, Digital Output Module 362871.00VT, Interface Board (IB) 469564.04VT Next : Siemens Robicon Keypad A1A460A68.23
Siemens Robicon 70A Cell A1A460Y83.070, 100A Cell A1A460Y83.100, 140A Cell A1A4608C0.140, 200A Cell A1A461D63.200, 260A Cell A1A461D63.260
Siemens Robicon 70A Cell A1A460Y83.070, 100A Cell A1A460Y83.100, 140A Cell A1A4608C0.140, 200A Cell A1A461D63.200, 260A Cell A1A461D63.260
Long press to look detail
Copy product links
Long by picture save/share

Siemens Robicon 70A Cell A1A460Y83.070, 100A Cell A1A460Y83.100, 140A Cell A1A4608C0.140, 200A Cell A1A461D63.200, 260A Cell A1A461D63.260

INQUIRY
Inquiry MORE+

  • Email *

  • Submit

    • Security Code
    Refresh the code
    Cancel
    Confirm

Inquiry Content：

You have no items to require

Add Successfully

We are the world's leading supplier of spare parts for medium voltage drives of various brands

GET IN TOUCH

East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong

Call us : +852 5261 7322

Email us : [email protected]

SITEMAP

分类标题

BUSINESS HOURS

Monday to Friday : 9 am to 6 pm

Saturday : 9 am to 12 am

Sunday : Closed Support Hours in 24/7 Everyday

DISCLAIMER:

We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.

© 2020 robiconperfectharmony.com site . All rights reserved     Site Map

添加微信好友，详细了解产品
使用企业微信
“扫一扫”加入群聊
复制成功
添加微信好友，详细了解产品
我知道了
