6SR0960-0AM44-0AD0, A1A10000432.34M, 6SR0960-0AM84-0AD0, A5E34621797030

6SR0960-0AM44-0AD0, A1A10000432.34M, 6SR0960-0AM84-0AD0, A5E34621797030

6SR0960-0AM44-0AD0, A1A10000432.34M, 6SR0960-0AM84-0AD0, A5E34621797030


ID: 109768066 Jun 3, 2019

Products SINAMICS Perfect Harmony GH180 6SR\(3/4\)

Medium voltage variable frequency drives product line SINAMICS Perfect Harmony GH180 6SR(3/4)

Most printed circuit board assemblies used in cell control have been replaced with an improved new design. In addition, variations in design such as the extended altitude version have been consolidated into fewer design variations. This reduces the variety needed as spare parts.
The table below is a cross reference between the obsolete Cell Control Board and the replacement Cell control board.
Original article numberOriginal Part NumberUsed in GH180 DriveReplacement article numberReplacement Part Number
6SR0960-0AM42-0AD0A1A10000432.30M6SR3….-..E..-….
6SR3….-..F..-….		6SR0960-0AM84-0AD0A5E34621797030
6SR0960-0AM43-0AD0A1A10000432.31M6SR3….-..B..-….
6SR3….-..C..-…		6SR0960-0AM86-0AD0A5E34621797031
6SR0960-0AM44-0AD0A1A10000432.34M6SR3….-..D..-….6SR0960-0AM84-0AD0A5E34621797030
6SR0960-0AM45-0AD0A1A10000432.53M6SR3….-..K..-….6SR0960-0AM73-0AD0A5E34621797053
6SR0960-0AM26-0AD0A1A10000432.54M6SR3….-..G..-….
6SR3….-..H..-….
6SR3….-..J..-….		6SR0960-0AM74-0AD0A5E34621797054
6SR0960-0AM85-0AD0A1A10000432.55M6SR3….-..K..-….6SR0960-0AM75-0AD0A5E34621797055
6SR0960-1BA00-0AA0A1A10000432.71M16SR4….-..A..-….
6SR4….-..B..-….
6SR4….-..C..-….
6SR4….-..D..-….		6SR0960-0AM71-0AD0A5E34621797071
6SR0960-1BA01-0AA0A1A10000432.72M6SR4….-..E..-….
6SR4….-..E..-….  		6SR0960-0AM72-0AD0A5E34621797072
6SR0960-0AM51-0AD0A5E035459316SR3….-..K..-….6SR0960-0AM73-0AD0A5E34621797053
6SR0960-0AM52-0AD0A5E035459336SR3….-..G..-….
6SR3….-..H..-….
6SR3….-..J..-….		6SR0960-0AM74-0AD0A5E34621797054

A5E035459346SR3….-..K..-….6SR0960-0AM75-0AD0A5E34621797055
6SR0960-0AM53-0AD0A5E035459356SR4….-..A..-….
6SR4….-..B..-….
6SR4….-..C..-….
6SR4….-..D..-….		6SR0960-0AM71-0AD0A5E34621797071 [1]
6SR0960-0AM54-0AD0A5E035459366SR4….-..E..-….
6SR4….-..F..-….		6SR0960-0AM72-0AD0A5E34621797072
6SR4960-0AM00-0AD0A5E335030060016SR4….-..J..-….
6SR4….-..K..-….		6SR0960-0AM82-0AD0A5E34621797001
6SR4900-0AM27-0AD0A5E335030060026SR4….-..G..-….
6SR4….-..H..-….		6SR0960-0AM81-0AD0A5E34621797002

A5E335030060036SR4….-..J..-….
6SR4….-..K..-….		6SR0960-0AM80-0AD0A5E34621797003
6SR0960-0AM60-0AD0A5E348906860016SR4….-..J..-….
6SR4….-..K..-….		6SR0960-0AM82-0AD0A5E34621797001
6SR0960-0AM61-0AD0A5E348906860026SR4….-..G..-….
6SR4….-..H..-….		6SR0960-0AM81-0AD0A5E34621797002

A5E348906860036SR4….-..N..-….6SR0960-0AM80-0AD0A5E34621797003

 [1] Direct replacement depends upon the specific power semi-conductors used within the cell. Field substitution is not recommended.

Some Cell Control Boards no longer have a direct replacement. These Cell Control Boards will remain available until stock is exhausted. Once stock is exhausted, cells utilizing these specific versions of the cell control board must have the cell power semi-conductors replaced with modern components.  The chart below contains a list of these Cell Control Boards.

Article number

Part Number

Used in GH180 Drive

6SR0960-0AM38-0AD0

A1A10000432.00M

6SR3….-..B..-….

6SR0960-0AM40-0AD0

A1A10000432.01M

6SR3….-..C..-….

6SR0960-0AM41-0AD0

A1A10000432.02M

6SR3….-..D..-….

6SR0960-1BA00-0AA0

A1A10000432.71M[2]

6SR4….-..A..-….
6SR4….-..B..-….
6SR4….-..C..-….
6SR4….-..D..-….

6SR0960-0AM47-0AD0

A1A10000432.91M

6SR3.5..-..C..-….

6SR0960-0AM48-0AD0

A1A10000432.92M

6SR3.5..-..D..-….

6SR0960-0AM50-0AD0

A1A10000432.93M

6SR3.5..-..E..-….
6SR3.5..-..F..-….

[2] Direct replacement is available depending upon the power semi-conductors used within the cell. Field replacement is not recommended.

The table below lists Cell Control Boards which will continue to be available.

Article number

Part Number

Used in GH180 Drive

6SR0960-0AM46-0AD0

A1A10000432.73M

6SR4….-..L..-….

6SR0960-0AM56-0AD0

A5E03545937

6SR4….-..L..-….

John Bousfield
Product Manager

Security information

In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions constitute one element of such a concept. For more information about industrial security, please visit

Affected Products / Portfolio

  • SINAMICS Perfect Harmony GH180
    SINAMICS Perfect Harmony GH180
    Medium-Voltage Converters
