A5E01708486, LDZ01708486C, LDZ10000403.01C, Siemens Robicon Signal Conditioning Pcb Circuit Board
A5E01708486, LDZ01708486C, LDZ10000403.01C, Siemens Robicon Signal Conditioning Pcb Circuit Board
A5E01708486, LDZ01708486C, LDZ10000403.01C, Siemens Robicon Signal Conditioning Pcb Circuit Board
| Signal Control Board | A5E01708486 | PCA, SIGNAL CONDITIONING BOARD | 6SR0960-0CB14-0AD0 | LDZ01708486C/LDZ10000403.01C/363633.00 | |
| KEYPAD | A5E39206479 | DEV_CONTROL_SIMATIC HMI, KTP700 BASIC D | 6SR4900-0SM00-0AM0 | ||
| CABLE ASSY FOR 37BIN | A1A10000163.00 | CABLE ASSY,ANALOG I/O,37 PIN ON I/O BOARD | 6SR0960-0QM08-0AD0 | ||
| CABLE ASSY FOR 50BIN | A1A10000162.00 | CABLE ASSY, DIGITAL I/O,50 PIN ON I/O BOARD | 6SR0960-0QM00-0AD0 | ||
| CABLE ASSY FOR 10BIN | A1A10000540.00 | RIBBON CABLE ASSY, 10 PIN | 6SR3900-0QA00-0AM0 | ||
| I/O Breakout Board 120 V I/O | A5E01649325 | PCA, I/O BREAKOUT BOARD,120VAC | 6SR0960-0CB07-1AD0 | LDZ01649325C | |
| I/O Breakout Board 24 V I/O | A5E01649374 | PCA COATED 24VDC INPUTS SYS I/O BRKOUT | 6SR0960-0CB07-2AD0 | LDZ01649374C | |
| NXGII Power Supply | A1A0100275 | POWER SUPPLY | 6SR0960-0CD01-1AD0 | ||
| NXGII Power Supply | A1A14000461.00 | POWER SUPPLY KIT | |||
| NXGII Power Supply U55 | A5E31055176 | POWER_SPLY | 6SR0960-0EM02-0AD0 | ||
| DB37 PIN cable | A1A096535 | DB37 PIN cable BETWEEN SCB IO BREAKOUT AND DCR | 6SR0960-0QM01-0AD0 | LDZ10504750 | |
| DB50 PIN cable | A5E00993969 | DB 50 PIN cable BETWEEN DCR AND IO BREAKOUT | 6SR0960-0QA02-0AA0 | ||
| DCR FAN | A5E30653347 | AXIALFAN | 6SR0960-0GM02-0AD0 | A5E02381532/LDZ092828 | |
| NXG DCR | NXG DCR | A1A461R57.00 | NXG DCR | LDZ461R57.00C | |
| NXG | CPU Kit | A1A10000623.00M | PCA, SBC, HARMONY NXGII | 6SR0900-0CB00-0AM0 | LDZ10000623.00C / A1A10000623.00 |
| CPU Board | A1A0100521 | CPU board | 6SR0960-0CD03-0AD0 | ||
| Keypad adapter board | A1A10000283.01M | Keypad adapter board | 6SR0960-0SM23-0AD0 | ||
| CF | A1A260986.00 | Compact flash card inside CPU | 6SR0960-0CB11-0AD0 | ||
| System I/O Board | A1A10000423.00M | PCA, W/FIRMARE,NXG SYSTEM I/O | 6SR0960-0CB02-0AD0 | ||
| BGA Modulator | A1A10000350.00M | PCA, W/FIRMWARE, MODULATOR, | 6SR0960-0CB03-0AD0 | ||
| Backplane | A1A363628.00M | PCA, COATED, ISA BACKPLANE, 14SLOT | 6SR3960-0CD01-0AD0 | LDZ363628.00C | |
| Communications Board | A5E03407403 | PCA, COMM BOARD | 6SR3960-0CD02-0AD0 | LDZ363818.00C /A1A363818.00M | |
| CABLE ASSY FOR 10BIN | A1A10000540.00 | RIBBON CABLE ASSY, 10 PIN CABLE BETWEEN MB AND I/O | 6SR3900-0QA00-0AM0 | ||
| NXG Power Supply | LDZ10501382 | Power Supply | 6SR3900-0KA00-0AM0 | ||
| Communications Network | PROFIBUS DP | A1A252241.155S | COMM. KIT,ANYBUS Profibus-DP | 6SR0960-0CD00-0AM0 | LDZ252241.155SC |
SIEMENS PERFECT HARMONY DRIVE GEN 3E Spare Parts, VFD Refer to 6SR3502-1HG41-8AH0-ZZ8-142231307-159,6SR3502-1HH42-5AH0-ZZ8 -142231308-160, 6SR3502-1HK44-0AH0-ZZ8 -142231310-161,6SR3502-1HJ42-7AH0-ZZ8--142231309-162 | ||||
# | DESCRIPTION | PART NO | QTY | UNIT |
1 | POWER CELL 500A,VFD, REFER TO VFD, PERFECT HARMONY DRIVE GEN 3E, INPUT:6600,3PH,60HZ,214A 0-3300V,3PH,0-60HZ,423 A,CONTROL:415,3PH,60HZ,20A | LDZ31500082.500,6SR3902-0AJ00-0AM0/G3E | 3 | Each |
2 | POWER CELL 660A, VFD, REFER TO VFD PERFECT HARMONY DRIVE | LDZ31500082.660,6SR3902-0AK00-0AM0 /G3E | 3 | Each |
3 | POWER CELL 375A,VFD,REFER TO VFD PERFECT HARMONY DRIVE GEN 3E INPUT: 6600,3PH,60HZ,195A OUTPUT: | LDZ31500082.375,6SR3902-0AK00-0AM0 /G3E | 3 | Each |
4 | CELL INPUT FUSE, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HG41-8AH0-ZZ8-142231307-159,Siemens | A1A095788 | 6 | Each |
5 | SINAMICS PH GH180 AC 6SR3 POWER CELL | LDZ31500082.315 | 3 | Each |
6 | ELECTRONIC MODULE INPUT BORD SCB, PERFECT HARMONY DRIVE GEN 3E | A5E01708486 | 1 | Each |
7 | FILTER LOWPASS,PERFECT HARMONY DRIVE GEN 3E | A5E30204948 | 1 | Each |
8 | RELAY CLOSING WMIT BASE,PERFECT HARMONY DRIVE GEN 3E | LDZ10506452 | 1 | Each |
9 | FAN AC IMPELLER, PERFECT | A1A089659 | 1 | Each |
10 | ATTENUATOR PH 6.6KV,PERFECT HARMONY DRIVE GEN 3E | A1A164877.06 | 1 | Each |
11 | CONTROL TRANSFORMER,PERFECT HARMONY DRIVE GEN 3E | LDZ13500012.00 | 1 | Each |
12 | ELECTRONIC MODULE 24 V,PERFECT HARMONY DRIVE GEN 3E | A5E01649374 | 1 | Each |
13 | I/O MODULE, ELECTRONIC MODULE,PERFECT HARMONY DRIVE GEN 3E | A1A10000423.00M | 1 | Each |
14 | PCA OPERATOR PANEL,PERFECT HARMONY DRIVE GEN 3E | A1A10000283.01M | 1 | Each |
15 | SINAMICS PH GH180 CF CARD NXG2,SOFTWARE,PERFECT,HARMONY DRIVE GEN 3E | A1A260986.00 | 1 | Each |
16 | KEYBOARD KIT ENGLISH,PERFECT HARMONY DRIVE GEN 3E | A5E02669560 | 1 | Each |
17 | ATTENUATOR PH 3.3KV,PERFECT HARMONY DRIVE GEN 3E | A1A164877.02 | 1 | Each |
18 | AXIAL BLOWER FAD1,PERFECT HARMONY DRIVE GEN 3E | A5E30653347 | 1 | Each |
19 | POWER SUPPLY 700W,PERFECT HARMONY DRIVE GEN 3E | A1A0100275 | 1 | Each |
20 | FILTER FOR G3E, PERFECT HARMONY DRIVE GEN 3E | LDZ10501463 | 1 | Each |
21 | CURRENT TRANSFORMER D87,PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HG41-8AH0-ZZ8-142231307-159 | LDZ10501929 | 1 | Each |
22 | SINAMICS PH GH 180 AXIAL BLOWER,PERFECT HARMONY DRIVE GEN 3E | A5E30771774 | 3 | Each |
23 | RESISTOR HALL EFFECT BURDEN 1,, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HJ42-7AH0-Z Z8-142231309-162 | A1A13000346.04 | 1 | Each |
24 | FUSE FOR CELL G3E , 450A ,690 V, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HJ42-7AH0-Z Z8-142231309-162 | LDZ10506515 | 6 | Each |
25 | CURRENT TRANSFORMER,PERFECT HARMONY DRIVE GEN 3E, | D88 LDZ10501930 | 1 | Each |
26 | RESISTOR HALL EFFECT BURDEN 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A13000346.02 | 1 | Each |
27 | CELL INPUT FUSE 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A095786 | 6 | Each |
28 | FAN AC IMPELLER 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A091386 | 1 | Each |
29 | CELL INPUT FUSE 3,PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HH42-5AH0-ZZ8-142231308-160 | A1A095787 | 6 | Each |
30 | RESISTOR HALL EFFECT BURDEN 4 | A1A3000346.05 | 1 | Each |
31 | CURRENT TRANSFORMER CLOSED CIRCUIT | LDZ10501376 | 1 | Each |
