A5E34621797054, Cell Control Board, 6SR0960-0AM74-0AD0, A5E34621797053, 6SR0960-0AM73-0AD0
A5E34621797054, Cell Control Board, 6SR0960-0AM74-0AD0, A5E34621797053, 6SR0960-0AM73-0AD0
A5E34621797054, Cell Control Board, 6SR0960-0AM74-0AD0, A5E34621797053, 6SR0960-0AM73-0AD0
6SR0960-0AM74-0AD0
No picture available
Cell control module PCA 630/690/750 V
List Price Show prices
Customer Price Show prices
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM74-0AD0
Product Description Cell control module PCA 630/690/750 V
Product family Not available
Product Lifecycle (PLM) PM300:Active Product
Price data
Headquarter Price Group 6ZZ
List Price Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations ECCN : EAR99 / AL : N
Standard lead time ex-works 120 Day/Days
Net Weight (kg) 0,001 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin Hong Kong
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Not available
Products SINAMICS Perfect Harmony GH180 6SR\(3/4\)
Medium voltage variable frequency drives product line SINAMICS Perfect Harmony GH180 6SR(3/4)
Most printed circuit board assemblies used in cell control have been replaced with an improved new design. In addition, variations in design such as the extended altitude version have been consolidated into fewer design variations. This reduces the variety needed as spare parts.
The table below is a cross reference between the obsolete Cell Control Board and the replacement Cell control board.
Most printed circuit board assemblies used in cell control have been replaced with an improved new design. In addition, variations in design such as the extended altitude version have been consolidated into fewer design variations. This reduces the variety needed as spare parts.
The table below is a cross reference between the obsolete Cell Control Board and the replacement Cell control board.
| Original article number | Original Part Number | Used in GH180 Drive | Replacement article number | Replacement Part Number |
|---|---|---|---|---|
| 6SR0960-0AM42-0AD0 | A1A10000432.30M | 6SR3….-..E..-…. 6SR3….-..F..-…. | 6SR0960-0AM84-0AD0 | A5E34621797030 |
| 6SR0960-0AM43-0AD0 | A1A10000432.31M | 6SR3….-..B..-…. 6SR3….-..C..-… | 6SR0960-0AM86-0AD0 | A5E34621797031 |
| 6SR0960-0AM44-0AD0 | A1A10000432.34M | 6SR3….-..D..-…. | 6SR0960-0AM84-0AD0 | A5E34621797030 |
| 6SR0960-0AM45-0AD0 | A1A10000432.53M | 6SR3….-..K..-…. | 6SR0960-0AM73-0AD0 | A5E34621797053 |
| 6SR0960-0AM26-0AD0 | A1A10000432.54M | 6SR3….-..G..-…. 6SR3….-..H..-…. 6SR3….-..J..-…. | 6SR0960-0AM74-0AD0 | A5E34621797054 |
| 6SR0960-0AM85-0AD0 | A1A10000432.55M | 6SR3….-..K..-…. | 6SR0960-0AM75-0AD0 | A5E34621797055 |
| 6SR0960-1BA00-0AA0 | A1A10000432.71M1 | 6SR4….-..A..-…. 6SR4….-..B..-…. 6SR4….-..C..-…. 6SR4….-..D..-…. | 6SR0960-0AM71-0AD0 | A5E34621797071 |
| 6SR0960-1BA01-0AA0 | A1A10000432.72M | 6SR4….-..E..-…. 6SR4….-..E..-…. | 6SR0960-0AM72-0AD0 | A5E34621797072 |
| 6SR0960-0AM51-0AD0 | A5E03545931 | 6SR3….-..K..-…. | 6SR0960-0AM73-0AD0 | A5E34621797053 |
| 6SR0960-0AM52-0AD0 | A5E03545933 | 6SR3….-..G..-…. 6SR3….-..H..-…. 6SR3….-..J..-…. | 6SR0960-0AM74-0AD0 | A5E34621797054 |
| A5E03545934 | 6SR3….-..K..-…. | 6SR0960-0AM75-0AD0 | A5E34621797055 | |
| 6SR0960-0AM53-0AD0 | A5E03545935 | 6SR4….-..A..-…. 6SR4….-..B..-…. 6SR4….-..C..-…. 6SR4….-..D..-…. | 6SR0960-0AM71-0AD0 | A5E34621797071 [1] |
| 6SR0960-0AM54-0AD0 | A5E03545936 | 6SR4….-..E..-…. 6SR4….-..F..-…. | 6SR0960-0AM72-0AD0 | A5E34621797072 |
| 6SR4960-0AM00-0AD0 | A5E33503006001 | 6SR4….-..J..-…. 6SR4….-..K..-…. | 6SR0960-0AM82-0AD0 | A5E34621797001 |
| 6SR4900-0AM27-0AD0 | A5E33503006002 | 6SR4….-..G..-…. 6SR4….-..H..-…. | 6SR0960-0AM81-0AD0 | A5E34621797002 |
| A5E33503006003 | 6SR4….-..J..-…. 6SR4….-..K..-…. | 6SR0960-0AM80-0AD0 | A5E34621797003 | |
| 6SR0960-0AM60-0AD0 | A5E34890686001 | 6SR4….-..J..-…. 6SR4….-..K..-…. | 6SR0960-0AM82-0AD0 | A5E34621797001 |
| 6SR0960-0AM61-0AD0 | A5E34890686002 | 6SR4….-..G..-…. 6SR4….-..H..-…. | 6SR0960-0AM81-0AD0 | A5E34621797002 |
| A5E34890686003 | 6SR4….-..N..-…. | 6SR0960-0AM80-0AD0 | A5E34621797003 |
[1] Direct replacement depends upon the specific power semi-conductors used within the cell. Field substitution is not recommended.
Some Cell Control Boards no longer have a direct replacement. These Cell Control Boards will remain available until stock is exhausted. Once stock is exhausted, cells utilizing these specific versions of the cell control board must have the cell power semi-conductors replaced with modern components. The chart below contains a list of these Cell Control Boards.
Article number | Part Number | Used in GH180 Drive |
|---|---|---|
6SR0960-0AM38-0AD0 | A1A10000432.00M | 6SR3….-..B..-…. |
6SR0960-0AM40-0AD0 | A1A10000432.01M | 6SR3….-..C..-…. |
6SR0960-0AM41-0AD0 | A1A10000432.02M | 6SR3….-..D..-…. |
6SR0960-1BA00-0AA0 | A1A10000432.71M[2] | 6SR4….-..A..-…. |
6SR0960-0AM47-0AD0 | A1A10000432.91M | 6SR3.5..-..C..-…. |
6SR0960-0AM48-0AD0 | A1A10000432.92M | 6SR3.5..-..D..-…. |
6SR0960-0AM50-0AD0 | A1A10000432.93M | 6SR3.5..-..E..-…. |
[2] Direct replacement is available depending upon the power semi-conductors used within the cell. Field replacement is not recommended.
The table below lists Cell Control Boards which will continue to be available.
Article number | Part Number | Used in GH180 Drive |
|---|---|---|
6SR0960-0AM46-0AD0 | A1A10000432.73M | 6SR4….-..L..-…. |
6SR0960-0AM56-0AD0 | A5E03545937 | 6SR4….-..L..-…. |
6SR0960-0AM84-0AD0
Product
Image similar
Power cell control module PCA 630V (6SR3 AC 140/200/260A)
List Price (w/o VAT) Show prices
Customer Price Show prices
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM84-0AD0
Product Description Power cell control module PCA 630V (6SR3 AC 140/200/260A)
Product family Ordering Data Overview
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 6ZZ
List Price (w/o VAT) Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations AL : N / ECCN : EAR99
Factory Production Time On request
Net Weight (kg) 0.001 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin Hong Kong
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Version Classification
eClass 6 27-15-06-91
eClass 7.1 27-15-06-91
eClass 8 27-15-06-91
eClass 9 27-15-06-91
eClass 9.1 27-15-06-91
6SR0960-0AM74-0AD0
No picture available
Cell control module PCA 630/690/750 V
List Price Show prices
Customer Price Show prices
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM74-0AD0
Product Description Cell control module PCA 630/690/750 V
Product family Not available
Product Lifecycle (PLM) PM300:Active Product
Price data
Headquarter Price Group 6ZZ
List Price Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations ECCN : EAR99 / AL : N
Standard lead time ex-works 120 Day/Days
Net Weight (kg) 0,001 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin Hong Kong
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Not available
6SR0960-0AM75-0AD0
Product
Image similar
Cell control module PCA 630/690/750 V
List Price (w/o VAT) Show prices
Customer Price Show prices
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM75-0AD0
Product Description Cell control module PCA 630/690/750 V
Product family Ordering Data Overview
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 6ZZ
List Price (w/o VAT) Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations AL : N / ECCN : EAR99
Factory Production Time 120 Day/Days
Net Weight (kg) 0.544 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin United States of America
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Version Classification
eClass 6 27-15-06-91
eClass 7.1 27-15-06-91
eClass 8 27-15-06-91
eClass 9 27-15-06-91
eClass 9.1 27-15-06-91
6SR0960-0AM71-0AD0
No picture available
Cell control module PCA 630/690/750V
List Price Show prices
Customer Price Show prices
Additional Services
For this product we can offer Services like Spare Part Delivery/Repair/Exchange. You have currently no rights to enter the Service Web Shop for that. For further information & to order this service, please contact your local Spares&Repair Partner
Please find an overview our product related services here
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM71-0AD0
Product Description Cell control module PCA 630/690/750V
Product family Not available
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 6ZZ
List Price Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations ECCN : EAR99 / AL : N
Standard lead time ex-works 120 Day/Days
Net Weight (kg) 0.680 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin China
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Not available
6SR0960-0AM72-0AD0
No picture available
Cell control module PCA 630/690/750V
List Price Show prices
Customer Price Show prices
Additional Services
For further information & to order this service, please contact your local Spares&Repair Partner
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM72-0AD0
Product Description Cell control module PCA 630/690/750V
Product family Not available
Product Lifecycle (PLM) PM300:Active Product
Price data
Region Specific PriceGroup / Headquarter Price Group 6ZZ / 6ZZ
List Price Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations ECCN : EAR99 / AL : N
Standard lead time ex-works 120 Day/Days
Net Weight (kg) 0,001 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin China
Compliance with the substance restrictions according to RoHS directive Given
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Not available
6SR0960-0AM01-0AD0
No picture available
SIGNAL CONDITIONING BOARD KIT 1250A - CONSISTS OF 4 PCS. A1A13000346.00 - RESISTOR, 7.07 OHM = 6SR0960-1CM00-0AD0
Notes
Product is no longer available. Successor: 6SR0960-1CM00-0AD0
List Price Show prices
Customer Price Show prices
Additional Services
For further information & to order this service, please contact your local Spares&Repair Partner
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM01-0AD0
Product Description SIGNAL CONDITIONING BOARD KIT 1250A - CONSISTS OF 4 PCS. A1A13000346.00 - RESISTOR, 7.07 OHM = 6SR0960-1CM00-0AD0
Product family Not available
Product Lifecycle (PLM) PM500:Discontinued Product or end of PLM & Support
PLM Effective Date End of product lifecycle since: 14.01.2017
Notes
Product is no longer available. Successor: 6SR0960-1CM00-0AD0
Successor information
Successor 6SR0960-1CM00-0AD0
Successor Description resistor
Price data
Region Specific PriceGroup / Headquarter Price Group 6ZZ / 6ZZ
List Price Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations ECCN : EAR99 / AL : N
Standard lead time ex-works On request
Net Weight (kg) 0,500 Kg
Package size unit of measure Not available
Quantity Unit 0 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 85049099
LKZ_FDB/ CatalogID GG_LD
Product Group 3646
Group Code P1S4
Country of origin United States of America
Compliance with the substance restrictions according to RoHS directive not available
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation -
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Not available
6SR0960-0AM81-0AD0
Product
Image similar
Cell control module AC CCB 750 V assembly
List Price (w/o VAT) Show prices
Customer Price Show prices
Service & Support (Manuals, Certificates, FAQs...) Download
Product
Article Number (Market Facing Number) 6SR0960-0AM81-0AD0
Product Description Cell control module AC CCB 750 V assembly
Product family Ordering Data Overview
Product Lifecycle (PLM) PM300:Active Product
Price data
Price Group / Headquarter Price Group 6ZZ
List Price (w/o VAT) Show prices
Customer Price Show prices
Metal Factor None
Delivery information
Export Control Regulations AL : N / ECCN : EAR99
Factory Production Time 120 Day/Days
Net Weight (kg) 0.001 Kg
Package size unit of measure Not available
Quantity Unit 1 Piece
Packaging Quantity 1
Additional Product Information
EAN Not available
UPC Not available
Commodity Code 8504907500
LKZ_FDB/ CatalogID GG_LD
Product Group 3662
Group Code P1S4
Country of origin Hong Kong
Compliance with the substance restrictions according to RoHS directive not available
Product class A: Standard product which is a stock item could be returned within the returns guidelines/period.
WEEE (2012/19/EU) Take-Back Obligation No
REACH Art. 33 Duty to inform according to the current list of candidates
Reach Information
Classifications
Version Classification
eClass 6 27-15-06-91
eClass 7.1 27-15-06-91
eClass 8 27-15-06-91
eClass 9 27-15-06-91
eClass 9.1 27-15-06-91
Previous : A5E32539903, 6SR4902-0AD00-0AM1, Siemens SINAMICS PERFECT HARMONY GH180, G4 Power CELL 140A, 750V
Next : Siemens A5E03927689, Air Filter, 6SR0900-0FM00-0AM0, Filter_Assembly
Copy product links
Long by picture save/share
INQUIRY
Add Successfully
We are the world's leading supplier of spare parts for medium voltage drives of various brands
点击右上角
分享给朋友吧
GET IN TOUCH
East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong
Call us : +852 5261 7322
Email us : [email protected]
SITEMAP
BUSINESS HOURS
Monday to Friday : 9 am to 6 pm
Saturday : 9 am to 12 am
Sunday : Closed Support Hours in 24/7 Everyday
DISCLAIMER:
We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.
© 2020 robiconperfectharmony.com site . All rights reserved Site Map
