LDZ31500082.500, 6SR3902-0AJ00-0AM0, 31000082.5 Siemens Robicon G3E Power Cell, 500A, 690V
LDZ31500082.500, 6SR3902-0AJ00-0AM0, 31000082.5 Siemens Robicon G3E Power Cell, 500A, 690V
LDZ31500082.500, 6SR3902-0AJ00-0AM0, 31000082.5 Siemens Robicon G3E Power Cell, 500A, 690V
| Power Cell* | 315 A Cell | LDZ31500082.315 | G3E CELL,315A, 690V | 6SR3902-0AG00-0AM0 | |
| 375 A Cell | LDZ31500082.375 | G3E CELL,375A, 690V | 6SR3902-0AH00-0AM0 | ||
| 500 A Cell | LDZ31500082.500 | G3E CELL,500A, 690V | 6SR3902-0AJ00-0AM0 | 31000082.5 | |
| 660 A Cell | LDZ31500082.660 | G3E CELL,660A, 690V | 6SR3902-0AK00-0AM0 | 31000082.66 | |
| 720 A Cell | A5E02772515 | G3E CELL,720A, 630V | 6SR3902-0AL00-0AM0 | ||
| Power Cell* U55 | 315 A Cell | A5E31299635 | G3E CELL,315A, 690V, H | 6SR3902-0AG01-0AM0 | |
| 375 A Cell | A5E31299652 | G3E CELL,375A, 690V, H | 6SR3902-0AH01-0AM0 | ||
| 500 A Cell | A5E31299891 | G3E CELL,500A, 690V, H | 6SR3902-0AJ01-0AM0 | ||
| 660 A Cell | A5E31300233 | G3E CELL,660A, 690V, H | 6SR3902-0AK01-0AM0 | ||
| 720 A Cell | A5E31299628 | G3E CELL,720A, 630V, H | 6SR3902-0AL01-0AM0 | ||
| Cell Input Fuses | Cell FUSE | LDZ10506512 | G3E CELL FUSE | 6SR3960-0JA00-0AD0 | |
| Cell FUSE | LDZ10506511 | G3E CELL FUSE | 6SR3960-0JA01-0AD0 | ||
| Cell FUSE | LDZ10506515 | G3E CELL FUSE | 6SR3900-0JM47-0AM0 | ||
| Cell FUSE | LDZ10506516 | G3E CELL FUSE | 6SR3960-0JA03-0AD0 | LDZ095786C | |
| Cell FUSE | A5E01654646 | G3E CELL FUSE | 6SR3900-0JM02-0AD0 | ||
| Cell Control Board | ACCB | A5E34621797054 | PCA 630/690/750V ACCB | 6SR0960-0AM74-0AD0 | |
| CCB | A1A10000432.54M | PCA 630/690/750V CELL CONTROL | 6SR0960-0AM26-0AD0 | LDZ10000432.54C | |
| CCB | A5E03545933 | PCA 630/690/750V CELL CONTROL 4000M | 6SR0960-0AM52-0AD0 | ||
| ACCB | A5E34621797053 | PCA 630/690/750V ACCB | 6SR0960-0AM73-0AD0 | ||
| CCB | A1A10000432.53M | PCA 630/690/750V CELL CONTROL | 6SR0960-0AM45-0AD0 | LDZ10000432.53C | |
| CCB | A5E03545931 | PCA 630/690/750V CELL CONTROL 4000M | 6SR0960-0AM51-0AD0 | ||
| CCB | A1A10000432.73M | PCA 630/690/750V CELL CONTROL | 6SR0960-0AM46-0AD0 | ||
| CCB | A5E03545937 | PCA 630/690/750V CELL CONTROL 4000M | 6SR0960-0AM56-0AD0 |
SIEMENS PERFECT HARMONY DRIVE GEN 3E Spare Parts, VFD Refer to 6SR3502-1HG41-8AH0-ZZ8-142231307-159,6SR3502-1HH42-5AH0-ZZ8 -142231308-160, 6SR3502-1HK44-0AH0-ZZ8 -142231310-161,6SR3502-1HJ42-7AH0-ZZ8--142231309-162 | ||||
# | DESCRIPTION | PART NO | QTY | UNIT |
1 | POWER CELL 500A,VFD, REFER TO VFD, PERFECT HARMONY DRIVE GEN 3E, INPUT:6600,3PH,60HZ,214A 0-3300V,3PH,0-60HZ,423 A,CONTROL:415,3PH,60HZ,20A | LDZ31500082.500,6SR3902-0AJ00-0AM0/G3E | 3 | Each |
2 | POWER CELL 660A, VFD, REFER TO VFD PERFECT HARMONY DRIVE | LDZ31500082.660,6SR3902-0AK00-0AM0 /G3E | 3 | Each |
3 | POWER CELL 375A,VFD,REFER TO VFD PERFECT HARMONY DRIVE GEN 3E INPUT: 6600,3PH,60HZ,195A OUTPUT: | LDZ31500082.375,6SR3902-0AK00-0AM0 /G3E | 3 | Each |
4 | CELL INPUT FUSE, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HG41-8AH0-ZZ8-142231307-159,Siemens | A1A095788 | 6 | Each |
5 | SINAMICS PH GH180 AC 6SR3 POWER CELL | LDZ31500082.315 | 3 | Each |
6 | ELECTRONIC MODULE INPUT BORD SCB, PERFECT HARMONY DRIVE GEN 3E | A5E01708486 | 1 | Each |
7 | FILTER LOWPASS,PERFECT HARMONY DRIVE GEN 3E | A5E30204948 | 1 | Each |
8 | RELAY CLOSING WMIT BASE,PERFECT HARMONY DRIVE GEN 3E | LDZ10506452 | 1 | Each |
9 | FAN AC IMPELLER, PERFECT | A1A089659 | 1 | Each |
10 | ATTENUATOR PH 6.6KV,PERFECT HARMONY DRIVE GEN 3E | A1A164877.06 | 1 | Each |
11 | CONTROL TRANSFORMER,PERFECT HARMONY DRIVE GEN 3E | LDZ13500012.00 | 1 | Each |
12 | ELECTRONIC MODULE 24 V,PERFECT HARMONY DRIVE GEN 3E | A5E01649374 | 1 | Each |
13 | I/O MODULE, ELECTRONIC MODULE,PERFECT HARMONY DRIVE GEN 3E | A1A10000423.00M | 1 | Each |
14 | PCA OPERATOR PANEL,PERFECT HARMONY DRIVE GEN 3E | A1A10000283.01M | 1 | Each |
15 | SINAMICS PH GH180 CF CARD NXG2,SOFTWARE,PERFECT,HARMONY DRIVE GEN 3E | A1A260986.00 | 1 | Each |
16 | KEYBOARD KIT ENGLISH,PERFECT HARMONY DRIVE GEN 3E | A5E02669560 | 1 | Each |
17 | ATTENUATOR PH 3.3KV,PERFECT HARMONY DRIVE GEN 3E | A1A164877.02 | 1 | Each |
18 | AXIAL BLOWER FAD1,PERFECT HARMONY DRIVE GEN 3E | A5E30653347 | 1 | Each |
19 | POWER SUPPLY 700W,PERFECT HARMONY DRIVE GEN 3E | A1A0100275 | 1 | Each |
20 | FILTER FOR G3E, PERFECT HARMONY DRIVE GEN 3E | LDZ10501463 | 1 | Each |
21 | CURRENT TRANSFORMER D87,PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HG41-8AH0-ZZ8-142231307-159 | LDZ10501929 | 1 | Each |
22 | SINAMICS PH GH 180 AXIAL BLOWER,PERFECT HARMONY DRIVE GEN 3E | A5E30771774 | 3 | Each |
23 | RESISTOR HALL EFFECT BURDEN 1,, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HJ42-7AH0-Z Z8-142231309-162 | A1A13000346.04 | 1 | Each |
24 | FUSE FOR CELL G3E , 450A ,690 V, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HJ42-7AH0-Z Z8-142231309-162 | LDZ10506515 | 6 | Each |
25 | CURRENT TRANSFORMER,PERFECT HARMONY DRIVE GEN 3E, | D88 LDZ10501930 | 1 | Each |
26 | RESISTOR HALL EFFECT BURDEN 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A13000346.02 | 1 | Each |
27 | CELL INPUT FUSE 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A095786 | 6 | Each |
28 | FAN AC IMPELLER 2, PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HK44-0AH0-ZZ8-142231310-161 | A1A091386 | 1 | Each |
29 | CELL INPUT FUSE 3,PERFECT HARMONY DRIVE GEN 3E, REFERE TO 6SR3502-1HH42-5AH0-ZZ8-142231308-160 | A1A095787 | 6 | Each |
30 | RESISTOR HALL EFFECT BURDEN 4 | A1A3000346.05 | 1 | Each |
31 | CURRENT TRANSFORMER CLOSED CIRCUIT | LDZ10501376 | 1 | Each |
