Siemens EBM RH56 and Blower EBM RH71 Blower A1A089659, A1A090215, Blower EBM RH50 A1A090428, A1A091243
Siemens EBM RH56 and Blower EBM RH71 Blower A1A089659, A1A090215, Blower EBM RH50 A1A090428, A1A091243
Siemens EBM RH56 and Blower EBM RH71 Blower A1A089659, A1A090215, Blower EBM RH50 A1A090428, A1A091243
Spare Parts
Spare Part Control
Voltage
Item
Part Number
Power Cell*
Qty: 1
70A Cell
A1A460Y83.070
100A Cell
A1A460Y83.100
140A Cell
A1A4608C0.140
200A Cell
A1A461D63.2000
260A Cell
A1A461D63.260
Cell Input
Fuses
Qty: 3 per cell
70A Cell
A1A093503
100A Cell
A1A093502
140A Cell
A1A090391
200A Cell
A1A093504
260A Cell
A1A093505
Transformer
Cabinet
Air Filters
46” Cabinet, A1A090335, Qty 3
60” Cabinet, A1A090053, Qty. 3
80” Cabinet, A1A091389, Qty. 3
Cell Cabinet
Air Filters
77” Cabinet
A1A090335
Qty:8
54” and 112” Cabinets
A1A090053
Qty: 4 for 54” Cabinet and 6 for 112” Cabinet
NXGII
Qty: 1
SBC and Keypad
Adapter
A1A10000623.00M
System I/O Board
A1A10000423.00M
BGA Modulator
A1A10000350.00M
I/O Breakout Board
120V I/O
A5E01649325
Communications
Board
A1A363818.00M
NXGII Power Supply
A1A14000461.00
Signal Control Board
A5E01708486
I/O Breakout Board
24V I/O
A5E01649374
Backplane
A1A363628.00
Fiber Optic Link
board**
A1A461D85.00
Keypad
A1A460A68.23
WAGO I/O
Modules
Qty: 1
1–2 Channel Digital Input, 120 VAC
A1A091537
1– 4 Channel Digital Input, 24 VDC
A1A090789
1– 2 Channel Analog Input, 4-20mA
A1A091113
1– 2 Channel Analog Input, 0-10V
A1A092745
1– 2 Channel Relay Output, 120Vac or 24
VDC
A1A092363
1– 2 Channel Analog Output, 4-20mA
A1A091539
Field bus coupler
A1A091143
Q-Pulse Id Active 17/06/2014 Page 101 of 132
Spare Parts GenIII Product User Manual
9-2
s
A5E03723047A Version AB
9
Control
Transformer
Fuses
575V
Control
Primary Fuse 2.5A, 600 VAC
A1AH024968
Qty: 2
Secondary Fuse 6A, 600 VAC
A1A081099
Qty: 1
480V
Control
Primary Fuse 3.0A, 600 VAC
A1A080752
Qty: 2
230V /
380V /
415V
Control
Primary Fuse 3.5A, 600 VAC
A1A089205
Qty: 2
200V
Control
Primary Fuse 4.0A, 600 VAC
A1A081097
Qty: 2
Input CT
Qty: 2
CT, 50:5
A1A091705
CT, 75:5
A1A091706
CT, 100:5
A1A091707
CT, 150:5
A1A091708
CT, 200:5
A1A091709
CT, 250:5
A1A091710
CT, 300:5
A1A091711
CT, 400:5
A1A091712
CT, 500:5
A1A091713
CT, 600:5
A1A091714
CT, 750:5
A1A091715
CT, 800:5
A1A091716
CT, 1000:5
A1A091717
CT, 200:5
A1A096254
CT, 3000:5
A1A096255
Communicati
ons Network
Qty: 1
Profibus DP
A1A252241.155
Devicenet Profile 12
A1A2252241.156
Modbus Ethernet
A1A252241.157
Control Net
A1A252241.158
Modbus +
A1A252241.159
Input Voltage
Attenuator
Qty: 3
2 4 kV
A1A164877.00
3.0 kV
A1A164877.01
3.3 kV
A1A164877.02
4.16 kV
A1A164877.03
4.8 kV
A1A164877.04
6.0 kV
A1A164877.05
6.6 kV
A1A164877.06
6.9 kV
A1A164877.07
7.2 kV
A1A164877.08
8.4 kV
A1A164877.09
10 kV
A1A164877.10
11 kV
A1A164877.11
12 kV
A1A164877.12
12.5 kV
A1A164877.13
13.2 kV
A1A164877.14
13.8 kV
A1A164877.15
Output
Voltage
Attenuator
Qty: 3
2 4 kV
A1A164877.00
3.0 kV
A1A164877.01
3.3 kV
A1A164877.02
4.16 kV
A1A164877.03
4.8 kV
A1A164877.04
6.0 kV
A1A164877.05
6.6 kV
A1A164877.06
6.9 kV
A1A164877.07
7.2 kV
A1A164877.08
Spare Part Control
Voltage
Item
Part Number
GenIII Product User Manual Spare Parts
Spare Part Control
Voltage
Item
Part Number
A5E03723047A Version AB
Table 9-2: 120 VAC and 24 VDC Transformer/Cell Blower Fuse Control Voltages
Cell Bypass
Bypass Contactor
A1A252090.776
Qty: 1 per cell
Bypass Control PCA
A1A363662.01M
Qty: 1
For 630V Secondaries
Bypass Power Supply
A5A363549.00
Qty: 1
Bypass Power Supply Fuse
A1A090674
Qty: 2
Blower
Qty: 1
EBM RH56 Blower
(46” / 60” / 80”
Transformer Cabinet)
EBM RH50 Blower
(77” Cell Cabinet)
EBM RH71 Blower
(112” Cell Cabinet)
Other than 575V A1A089659 A1A090428 A1A089659
575V A1A090215 A1A091243 A1A090215
Cell Lifter
Qty: 1
A1A163496.04
*Customer may request IGBTs, diode rectifiers, and Cell Control Boards rather than a complete spare cell.
Contact Siemens for further information regarding individual cell P/Ns.
**Used if more than 12 cells.
