Automation and Drives ROBICON Perfect Harmony The Topology The System ProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 1© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptAutomation and DrivesShort overviewRPerfect HarmonyOBICON
Page 2
Automation and Drives ROBICON Perfect Harmony The Topology The System ProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 2© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem overviewProduct features▪ Truly Scaleable Technology▪ 300 kW to 30 MW (Single Channel)▪ Large Number of Framesizes▪ Most Motor Voltages Supported▪ Low Harmonic Input▪ High Efficiency and Power Factor▪ Line Disturbance Immune▪ New or Existing Motors▪ Negligible Pulsating Torques▪ High AvailabilitySystem Overview
Page 3
Automation and Drives ROBICON Perfect Harmony The Topology The System ProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 3© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem overviewThe Harmony concept: provide an integrated VFD systemFeaturePerfect HarmonyIsolation TransformerIncludedHarmonic FilteringInherentPower Factor CorrectionInherentPower ConverterIncludedMotor FilterInherent▪ Easy engineering▪ Simple installation▪ Lower installed cost.System Overview
Page 4
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 4© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem overviewProduct historyProduct introduction1994Increased output to 6.6 KV(690 V cells)1995Gen II: Options program1996UL/CSA1996ProToPS™1998Gen III HarmonyCE MarkFast Bypass199819991999Increased max power to 19,000 kVA(1250 A – 690 V cells)2000Introduced Harmony HV for 13.8 KV motors2003Largest PWM VFD 45/60 MW with AFE20043000 Perfect Harmony units sold2005Introduced Gen IV – smallest air-cooled MV VFD2006System Overview
Page 5
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 5© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptPerfect Harmony TopologyTypical Power Section SchematicLocal Controls4160 Volt Drive (750 V Power Cells)VFD ControlFiber opticsThe Topology
Page 6
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 6© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptPerfect Harmony TopologyPrinciple of OperationThese cells are inphase at zero degreeselectricalThese cells are inphase at 240 degreeselectricalThese cells are inphase at 120 degreeselectrical630V630V630V630V630V630V630V630V630V630V630V630V630V630V630V630V630V630VThe Topology
Page 7
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 7© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceIsolation transformerFeaturesCustomer benefitsIsolation transformer:included▪No motor common modevoltage issues▪ Prevents risk of motor damage bycommon mode voltages▪ Enhances the retrofit capability▪ Avoids expensive motor modificationsor the need for a new motor▪Continued operation withone earth fault possible▪ Increased system availability▪Isolation transformer builtinto drive cubicle▪ Easy plug-and-play installation:Three cables in, three cables out▪ Perfect for retrofit projectsPower cellsIntegratedtransformerThe System
Page 8
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 8© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceInput power qualityFeaturesCustomer benefitsHarmonic filter inherent:▪“Clean power” sinusoidalconverter▪Near zero harmonics▪ Meets all new requirements of IEEE 5191992 for both current and voltagedistortion▪ Eliminates needs to do harmonicanalysis▪ Eliminates costly harmonic filtersrequired for distortion control1000 HP / 750 KW VFD, 1100 kVA 5.75% Impedance SourceThe System
Page 9
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 9© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceLoss of power supplyContinued operation when line voltage lost▪ Restored operation with no trip for 5 cycle power interruption▪ Restart Into spinning load with no load or line disturbance as long as motor flux is presentThe System
Page 10
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 10© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceMotor compatibilityFeaturesCustomer benefitsMotor filter inherent:No common mode motorinsulation stress▪ Drive is compatible with both newand existing motors▪ Torque ripple 1% or less on drivenload at all operating frequenciesNo additional VFDinduced motor heating▪ Drive can be safely applied to 1.0service factor motorsNo dv/dt problems▪ Drive creates no motor voltageinsulation stress▪ Motor does not require reinforcedinsulationThe System
Page 11
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 11© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceMotor compatibilityOutput Waveforms @ 60 HZ and 30 HZ∎Wave forms remain high quality at lower speeds due tomulti-level PWM output.The System
Page 12
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 12© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.ppt∎Less Than 2% VFD Induced Torque Ripple on Driven LoadOutput Harmonics - Robicon Perfect Harmony Series@ 30 HZ, Full LoadSystem performanceOutput harmonicsThe System
Page 13
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 13© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptOutput Harmonics - Robicon Perfect Harmony motor operating from Generator vs. PerfectHarmonySystem performanceMotor harmonic temperature riseRecirc Pump Motor 2B Temperature Rise(Based on 3 hour Averages)-1001020304050604005006007008009001000110012001300140015001600Speed (RPM)Temp Rise(degF)MG SetVFDThe System
Page 14
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 14© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptSystem performanceFactory integrationFeaturesCustomer benefitsFactory integration:▪Fully integrated atSiemens A&D LD A▪Fast and safe commissioning atcustomer site▪Complete In-factory test-tested as completesystems in our plant▪Comprehensive proof ofperformance▪Enhances reliability by weeding outearly failuresThe System
Page 15
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 16© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptProToPS™Advanced Cell BypassAdvanced CellBypass ResultsProToPS™
Page 16
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 17© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptProToPS™Bypass Contactor and ControlRedundantcontrolCell Bypass ControlLogicBypass Contactor▪ Traction DC Contactor▪ Automatic bypass of a failed power cell in 250 ms▪ Completely redundant bypass control: Physically separate from cell▪ Allows bypass down to (1) one cell per phase▪ Allows unequal number of active cells per phase▪ U.S. Patent No. 5,986,909 issued November 16, 1999ProToPS™
Page 17
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 19© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptControl InterfaceControlAuto Tuning▪ Provides motor information to optimize control▪ Is a two-stage process▪ Stage 1: Stator resistance, leakage inductance▪ Stage 2: Motor no-load current, inertiaOpen Loop Sensorless Vector Control▪ Motor-mounted encoder NOT required▪ Duplicates two-quadrant DC operation▪ Provides precision speed/torque control▪ Features fast dynamic response▪ Has low speed/high torque capabilityControl Interface
Page 18
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 20© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptControl InterfacePower monitoringCan determine and display information about input waveform and drive output∎ Input voltage∎ Input voltage harmonics(one at a time)∎ Input current∎ Input current harmonics(one at a time)∎ Input PF∎ Input power (kW)∎ Input reactive power (kVAR)∎ Input kW-Hr∎ Input phase sequence∎ Loss of phase∎ Low voltage∎ Transformer overload∎ Output power (kW)∎ kW-Hr∎ Output current – RMS∎ Output voltage – RMS∎ VFD efficiency∎ Motor torque∎ Motor speed (RPM)∎ Motor slip (%)∎ Drive output frequency (Hz)∎ Magnetizing current∎ Torque current∎ Motor fluxInput display parametersControl Interface
Page 19
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 21© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptMenu structure windowGraphics windowDrive status windowControl InterfaceControl Drive Tool▪ Provides Windows-based graphical user interface▪ Provides full drive functionality▪ Features same structure as keypad interface▪ Has multiple language supportControl Interface
Page 20
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 22© Siemens AG 2007 - We reserve the right to make changesROBICON Perfect Harmonyrobicon-perfect-harmony-e.pptMotorsThe perfect products for a broad spectrum of motorsH-compactIEC200 - 3000 kW2 - 11 kV2 - 12 poleSquirrel cageCast iron housingwith cooling ribsIP55H-modynIEC, ANEMA7000 - 50000 kW9390 – 67000HP6 - 13.2 kV2 - 12 poleSquirrel cageSynchronousBase frame,Water coolingIP55, WP IISeries1R.5/S.5IEC7000 - 10000 kW3.3 - 13.2 kV4 - 24 poleSquirrel cageslip ring rotorSynchronousCast iron-/Steel housing,cooler assemblyIP55, WP IIH-compactPLUSIEC, ANEMA1000 - 7000 kW1340 – 9390 HP3.3 - 13.2 kV2 - 12 poleSquirrel cageCast iron-/Steel housing,cooler assemblyIP23, IP55, WP IISpecialmotors2000 - 65000 kW690 V - 13.2 kVSquirrel cagesynchronousExample:HighspeedcompressordriveANEMA150 - 2500 HP0.2 – 11 kV2 - 16 poleSquirrel cageCast iron housingwith cooling ribsIP55/TEFC200 - 10000 HP0.2 - 13.8 kV2 - 16 poleSquirrel cageCast iron housingcooler assemblyODP, WP I, WP II,TEAAC/TEWACANEMARetrofit• Existing motorswith standardwindingsMotors
Page 21
Automation and DrivesROBICON Perfect HarmonyThe TopologyThe SystemProToPS™Control InterfaceSystem OverviewApplicationsMotors14.03.2007 23© Siemens AG 2007 - We reserve the right to make changes
