BYPASS CONTATOR A5E02610994 6SR3960-0EA00-0AM0 PCA BYPASS CONTROL A1A10000416.00M 6SR0960-0EA03-0AD0

Graphic
Detail

BYPASS CONTATOR A5E02610994 6SR3960-0EA00-0AM0 PCA BYPASS CONTROL A1A10000416.00M 6SR0960-0EA03-0AD0

产品详情

Spare Part	Item	Part Number	Description	MLFB	OLD PN
NXG pro DCR	NXGpro DCR 12 Cell	A5E33032452	GH180 NXGpro controller 12 cell	6SR0960-0CC12-0AD0
	NXGpro DCR 15 Cell	A5E37764609	GH180 NXGpro controller 15 cell	6SR0960-0CC15-0AD0
	NXGpro DCR 18 Cell	A5E33032455	GH180 NXGpro controller 18 cell	6SR0960-0CC18-0AD0
	NXGpro DCR 21 Cell	A5E37764770	GH180 NXGpro controller 21 cell	6SR0960-0CC21-0AD0
	NXGpro DCR 24 Cell	A5E33032458	GH180 NXGpro controller 24 cell	6SR0960-0CC24-0AD0
	NXGpro CF	A5E35236834	GH180 NXGpro compact flash card	6SR0960-0CC08-0AD0
	SIB	A5E36968571	GH180 NXGpro System Interface Board	6SR0960-0CC16-0AD0	A5E32168144
	User I/O board 24VDV	A5E32100313	GH180 24VDC User IO Board	6SR0960-0CC07-1AD0
	Fiber Optic For USER I/O	A5E41987327	FIBER OPTIC ASSY, DUPLEX	6SR4900-0LM01-0AM0	A5E36881503
	USER I/O board POWER SUPPLY	A5E37356659	GH180 NXGpro USER I/O board POWER SUPPLY	6SR5902-0CM00-0AM0
	NXGpro CPS 15VDC	A5E37876282	Power Supply NXGpro CPS +/-15V	6SR0960-0CC32-0AD0
	NXGpro CPS 15VDC U55	A5E34916937	Power Supply NXGpro CPS +/-15V High Alt.	6SR0960-0CC05-1AD0	A5E34916905
	NXGpro CPS 15&24VDC	A5E37877003	Power Supply NXGpro CPS 15&24VDC	6SR0960-0CC50-0AD0
	NXGpro CPS 15&24VDC U55	A5E34916937	Power Supply NXGpro CPS 15&24VDC High Alt.
	NXGpro CPS 15&24VDC	A5E44722441	Power Supply NXGpro CPS 15&24VDC	6SR0960-0CC40-0AD0
	NXGpro-Profibus-DP	A1A099201	COMM. KIT,ANYBUS Profibus-DP,NXGpro	6SR0960-0DC00-0AD0
	NXGpro-DeviceNet	A1A098628	COMM. KIT,ANYBUS DeviceNet,NXGpro	6SR0960-0DC01-0AD0
	NXGpro-ModbusTCP/Eth	A1A099202	OMM. KIT,ANYBUS ModbusTCP/Eth,NXGpro	6SR0960-0DC02-0AD0
	NXGpro-ControlNet	A1A099203	COMM KIT,ANYBUS ControlNet,NXGpro	6SR0960-0DC03-0AD0
	NXGpro-MODBUS	A1A10000441.00	COMM. KIT, MODBUS,NXGpro	6SR0960-0DC04-0AD0
	Keypad kit	A5E02669561	KEYPAD KIT (Chinese)	6SR0960-0CC10-0AD0	LDZ252090.11NGSC
	Keypad	A5E02624585	MULTI LANGUAGE KEYPAD ASSEMBLY CHINESE	6SR0960-0CB16-0AD0	A1A460A68.23
	SHIELD CABLE RIBBON	A1A260913.08	SHIELDED RIBBON CABLE ASSY,87"	6SR0960-0QM04-0AD0
	FLAT MOUNT	A1A072323	FLAT CABLE MOUNT,ADHESIVE BACK
	BACK COVER	A1A283739.00	KEYPAD COVER, GLASTIC
	keypad kit	A5E02669560	KEYPAD KIT (English)	6SR3900-0SM20-0BD0	LDZ252090.11NGSC
	Keypad	A5E02363383	MULTI LANGUAGE KEYPAD ASSEMBLY ENGLISH	6SR0960-0CB15-0AD0	A1A460A68.23
	SHIELD CABLE RIBBON	A1A260913.08	SHIELDED RIBBON CABLE ASSY,87"	6SR0960-0QM04-0AD0
	FLAT MOUNT	A1A072323	FLAT CABLE MOUNT,ADHESIVE BACK
	BACK COVER	A1A283739.00	KEYPAD COVER, GLASTIC
	keypad kit	A5E02982002	KEYPAD KIT (Russia)	6SR0900-0CM07-0AD0	LDZ252090.11NGSC
	Keypad	A5E02669580	MULTI LANGUAGE KEYPAD ASSEMBLY RUSSIA	6SR0960-0CB18-0AD0	A1A460A68.23
	SHIELD CABLE RIBBON	A1A260913.08	SHIELDED RIBBON CABLE ASSY,87"	6SR0960-0QM04-0AD0
	FLAT MOUNT	A1A072323	FLAT CABLE MOUNT,ADHESIVE BACK
	BACK COVER	A1A283739.00	KEYPAD COVER, GLASTIC
	keypad kit	A5E39808478	KEYPAD KIT (Simatic)	6SR0960-0SM60-0AD0
	KEYPAD	A5E39206479	DEV_CONTROL_SIMATIC HMI, KTP700 BASIC D	6SR4900-0SM00-0AM0
	SHIELD CABLE	A5E39047590003	6SR5 KTP700 CABLE ASSEMBLY 96''	6SR5900-0QM00-0AD0
NXGII DCR	NXGII DCR with FOHB kit	A5E33065979	NXGII DCR with FOHB kit	6SR0960-0CB01-0AM0
	NXGII DCR without FOHB Kit	A5E03931016	NXGII DCR without FOHB Kit	6SR0960-0CB21-0AD0	A1A10000313.00
	NXGII DCR with FOHB kit U55	A5E33561398	NXGII DCR with FOHB kit U55	6SR0960-0CB02-0AM0
	NXGII DCR without FOHB Kit U55	A5E33561420	NXGII DCR without FOHB Kit U55	6SR0960-0CB04-0AM0
NXGII	CPU Kit	A1A10000623.00M	PCA, SBC, HARMONY NXGII	6SR0900-0CB00-0AM0	LDZ10000623.00C / A1A10000623.00
	CPU Board	A1A0100521	CPU board	6SR0960-0CD03-0AD0
	Keypad adapter board	A1A10000283.01M	Keypad adapter board	6SR0960-0SM23-0AD0
	CF	A1A260986.00	Compact flash card inside CPU	6SR0960-0CB11-0AD0
	System I/O Board	A1A10000423.00M	PCA, W/FIRMARE,NXG SYSTEM I/O	6SR0960-0CB02-0AD0	LDZ10000423.00C
	BGA Modulator	A1A10000350.00M	PCA, W/FIRMWARE, MODULATOR,	6SR0960-0CB03-0AD0	LDZ10000225.00C
	Backplane	A1A098194	PCA, COATED, ISA BACKPLANE, 8 SLOT	6SR0960-0CB01-0AA0
	Communications Board	A5E03407403	PCA, COMM BOARD	6SR3960-0CD02-0AD0	LDZ363818.00C /A1A363818.00M/461F11.00
	FOHB Kit	A1A252241.55S	FOHB Kit	6SR0900-0CD00-0AM0	LDZ252241.55SC
	FLAT CABLE	A1A260901.00	FLAT LINK CABLE BETWEEN MB AND FOHB	6SR0960-0QM07-0AD0
	Fiber Optic Link board	A1A461D85.00M	PCA, FIBER OPTIC, 12 CHANNEL	6SR3900-0LM00-1AD0	LDZ461D85.00C/A1A461D85.00
	Signal Control Board	A5E01708486	PCA, SIGNAL CONDITIONING BOARD	6SR0960-0CB14-0AD0	LDZ01708486C/LDZ10000403.01C/363633.00
	KEYPAD	A5E39206479	DEV_CONTROL_SIMATIC HMI, KTP700 BASIC D	6SR4900-0SM00-0AM0
	CABLE ASSY FOR 37BIN	A1A10000163.00	CABLE ASSY,ANALOG I/O,37 PIN ON I/O BOARD	6SR0960-0QM08-0AD0
	CABLE ASSY FOR 50BIN	A1A10000162.00	CABLE ASSY, DIGITAL I/O,50 PIN ON I/O BOARD	6SR0960-0QM00-0AD0
	CABLE ASSY FOR 10BIN	A1A10000540.00	RIBBON CABLE ASSY, 10 PIN	6SR3900-0QA00-0AM0
	I/O Breakout Board 120 V I/O	A5E01649325	PCA, I/O BREAKOUT BOARD,120VAC	6SR0960-0CB07-1AD0	LDZ01649325C
	I/O Breakout Board 24 V I/O	A5E01649374	PCA COATED 24VDC INPUTS SYS I/O BRKOUT	6SR0960-0CB07-2AD0	LDZ01649374C
	NXGII Power Supply	A1A0100275	POWER SUPPLY	6SR0960-0CD01-1AD0
	NXGII Power Supply	A1A14000461.00	POWER SUPPLY KIT
	NXGII Power Supply U55	A5E31055176	POWER_SPLY	6SR0960-0EM02-0AD0
	DB37 PIN cable	A1A096535	DB37 PIN cable BETWEEN SCB IO BREAKOUT AND DCR	6SR0960-0QM01-0AD0	LDZ10504750
	DB50 PIN cable	A5E00993969	DB 50 PIN cable BETWEEN DCR AND IO BREAKOUT	6SR0960-0QA02-0AA0
	DCR FAN	A5E30653347	AXIALFAN	6SR0960-0GM02-0AD0	A5E02381532/LDZ092828
NXG DCR	NXG DCR	A1A461R57.00	NXG DCR		LDZ461R57.00C
NXG	CPU Kit	A1A10000623.00M	PCA, SBC, HARMONY NXGII	6SR0900-0CB00-0AM0	LDZ10000623.00C / A1A10000623.00
	CPU Board	A1A0100521	CPU board	6SR0960-0CD03-0AD0
	Keypad adapter board	A1A10000283.01M	Keypad adapter board	6SR0960-0SM23-0AD0
	CF	A1A260986.00	Compact flash card inside CPU	6SR0960-0CB11-0AD0
	System I/O Board	A1A10000423.00M	PCA, W/FIRMARE,NXG SYSTEM I/O	6SR0960-0CB02-0AD0
	BGA Modulator	A1A10000350.00M	PCA, W/FIRMWARE, MODULATOR,	6SR0960-0CB03-0AD0
	Backplane	A1A363628.00M	PCA, COATED, ISA BACKPLANE, 14SLOT	6SR3960-0CD01-0AD0	LDZ363628.00C
	Communications Board	A5E03407403	PCA, COMM BOARD	6SR3960-0CD02-0AD0	LDZ363818.00C /A1A363818.00M
	CABLE ASSY FOR 10BIN	A1A10000540.00	RIBBON CABLE ASSY, 10 PIN CABLE BETWEEN MB AND I/O	6SR3900-0QA00-0AM0
	NXG Power Supply	LDZ10501382	Power Supply	6SR3900-0KA00-0AM0
Communications Network	PROFIBUS DP	A1A252241.155S	COMM. KIT,ANYBUS Profibus-DP	6SR0960-0CD00-0AM0	LDZ252241.155SC
	DEVICENET PROFILE12	A1A252241.156S	COMM. KIT,ANYBUS DeviceNet	6SR0960-0DA01-0AD0	LDZ252241.156SC
	MODBUS ETHERNET TCP	A1A252241.157	COMM. KIT,ANYBUS ModbusTCP/Eth	6SR0960-0DA02-0AD0	LDZ252241.157SC
	CONTROL NET	A1A252241.158	COMM KIT,ANYBUS ControlNet	6SR0960-0DA03-0AD0	LDZ252241.158SC
	MODBUS +	A1A252241.159	COMM. KIT,ANYBUS Modbus Plus	6SR0960-0DA04-0AD0	LDZ252241.159SC
	GATAWAY	A5E33654250	COMM. KIT,GATAWAY, Modbus ethnet to IP ethnet	6SR0960-0CD01-0AM0
	MODBUS RTU	A1A252241.160	COMM. KIT, MODBUS	6SR0960-0DA06-0AD0
WAGO I/O Modules	Field Bus Coupler	A5E43665372	750-316，WAGO FIELD BUS COUPLER	6SR0960-0RA03-0AD0	LDZ10501502
	Power supply module	LDZ10501501	750-612，WAGO POWER SUPPLY MODULE	6SR0960-0RA36-0AD0
	Analog Output, 4-20mA	LDZ10501504	750-554, WAGO ANOLOG OUTPUT MO	6SR0960-0RA05-0AD0
	Analog Input, 4-20mA	LDZ10501505	750-452, WAGO ANOLOG INPUT MOD	6SR0960-0RA02-0AD0
	Analog Input, 0-10V	LDZ10501491	750-467,WAGO ANOLOG INPUT MODULE,0-10V	6SR3960-0RA05-0AM0	LDZ092745C
	4 Channel Digital Input, 24VDC	LDZ10501500	750-402, WAGO DI MOD,24V,4 CH	6SR0960-0RA30-0AD0
	2 Channel Digital Input, 120Vac	LDZ10501507	750-406,WAGO DI MODULE,120V	6SR3960-0RA03-0AM0
	2 Channel Digital Input, 230Vac	LDZ10501508	750-405 WAGODI MODULE,230V	6SR3960-0RA02-0AM0
	2 Channel Relay Output	LDZ10501506	750-517, WAGO DIGITAL OUTPUT MODULE	6SR0960-0RA38-0AD0
	END MODULE	LDZ10501503	750-600WAGO END MODULE	6SR0960-0RA01-0AD0
	9 Pin cable	LDZ10504751	9 PIN cable between CPU baord and WAGO field bus coupler	6SR3960-0QA00-0AM0
	Hall effect power supply	LDZ10501526	POWER SUPPLY		A5E33980468
	WAGO power supply	A5E37356659	NXGpro POWER SUPPLY	6SR5902-0CM00-0AM0	LDZ10501526
	Circuit breaker	A5E35282730	Switch_OVERCURRENT
	WAGO power supply	A5E30112609	POWER_SPLY_230V_24V_10A	6SR0960-0RA10-0AM0
	WAGO power supply	LDZ10501360	POWER SUPPLY	6SR5902-0SM01-0AM0
ATTENUATOR RESISTOR	2.4 kV	A5E42739821001	ATTENUATOR RESISTOR MOD	6SR0960-0MM02-0AD0	LDZ164877.00C / A1A164877.00
	3.0 kV	A5E42739821002	ATTENUATOR RESISTOR MOD	6SR0960-0MM04-0AD0	LDZ164877.01C / A1A164877.01
	3.3 kV	A5E42739821003	ATTENUATOR RESISTOR MOD	6SR0960-0MM05-0AD0	LDZ164877.02C / A1A164877.02
	4.16 kV	A5E42739821004	ATTENUATOR RESISTOR MOD	6SR0960-0MM06-0AD0	LDZ164877.03C / A1A164877.03
	4.8 kV	A5E42739821005	ATTENUATOR RESISTOR MOD	6SR0960-0MM07-0AD0	LDZ164877.04C / A1A164877.04
	6.0 kV	A5E42739821006	ATTENUATOR RESISTOR MOD	6SR0960-0MM08-0AD0	LDZ164877.05C / A1A164877.05
	6.3 kV	A5E42739821007	ATTENUATOR RESISTOR MOD	6SR0960-0MM41-0AD0	A5E03003839
	6.6 kV	A5E42739821008	ATTENUATOR RESISTOR MOD	6SR0960-0MM10-0AD0	LDZ164877.06C / A1A164877.06
	6.9 kV	A5E42739821009	ATTENUATOR RESISTOR MOD	6SR0960-0MM11-0AD0	LDZ164877.07C / A1A164877.07
	7.2 kV	A5E42739821010	ATTENUATOR RESISTOR MOD	6SR0960-0NM01-0AD0	LDZ164877.08C / A1A164877.08
	8.4 kV	A5E42739821011	ATTENUATOR RESISTOR MOD	6SR0960-0MM12-0AD0	LDZ164877.09C / A1A164877.09
	10 kV	A5E42739821012	ATTENUATOR RESISTOR MOD	6SR0960-0MM13-0AD0	LDZ164877.10C / A1A164877.10
	11 kV	A5E42739821013	ATTENUATOR RESISTOR MOD	6SR0960-0MM14-0AD0	LDZ164877.11C / A1A164877.11
	12 kV	A5E42739821014	ATTENUATOR RESISTOR MOD	6SR0960-0MM15-0AD0	LDZ164877.12C / A1A164877.12
	12.5 kV	A5E42739821015	ATTENUATOR RESISTOR MOD	6SR0960-0MM16-0AD0	LDZ164877.13C / A1A164877.13
	13.2 kV	A5E42739821016	ATTENUATOR RESISTOR MOD	6SR0960-0MM17-0AD0	LDZ164877.14C / A1A164877.14
	13.8 kV	A5E42739821017	ATTENUATOR RESISTOR MOD	6SR0960-0MM01-0AD0	LDZ164877.15C / A1A164877.15
Input CT	CT	LDZ10501925	CURRENT TRANSFORMER	6SR0960-0HA00-0AM0
	CT	LDZ10501926	CURRENT TRANSFORMER	6SR0960-0HA01-0AM0
	CT	LDZ10501927	CURRENT TRANSFORMER	6SR0960-0HA02-0AM0
	CT	LDZ10501928	CURRENT TRANSFORMER	6SR0960-0HA03-0AM0
	CT	LDZ10501929	CURRENT TRANSFORMER	6SR0960-0HA04-0AM0
	CT	LDZ10501930	CURRENT TRANSFORMER	6SR0960-0HA05-0AM0
	CT	LDZ10501931	CURRENT TRANSFORMER	6SR0960-0HA07-0AM0
	CT	LDZ10501932	CURRENT TRANSFORMER	6SR0960-0HA06-0AM0
	CT	LDZ10501933	CURRENT TRANSFORMER	6SR0960-0HA08-0AM0
	CT	LDZ10501934	CURRENT TRANSFORMER	6SR0960-0HA10-0AM0
	CT	LDZ10501935	CURRENT TRANSFORMER	6SR3900-0HM16-0AM0
	CT	LDZ10501936	CURRENT TRANSFORMER	6SR3900-0HM12-0AM0
	CT	LDZ10501937	CURRENT TRANSFORMER	6SR3900-0HM18-0AM0
TRANSIENT SUPPRESSOR	INPUT SUPRESSOR KIT	A5E31796141	SUPRESSOR&CAPACITOR KIT INPUT FOR EACH PHASE	6SR0960-0CC40-0AD0
	DIODE	LDZ10501982	TRANSIENT SUPPRESSOR
	CAP FOR INPUT	LDZ10501981	CAP,.0047uF
	OUTPUT SUPRESSOR KIT	A5E31808912	SUPRESSOR&CAPACITOR KIT OUTPUT FOR EACH PHASE	6SR0960-0NM10-0AD0
	DIODE	LDZ10501982	TRANSIENT SUPPRESSOR
	CAP FOR OUTPUT	LDZ10501980	CAP,0.001uF
DOOR INTERLOCK	DOOR IINTERLOCK	LDZ10501378	SW,DOOR INTERLOCK
	DOOR INTERLOCK KIT	A5E33199486	DOOR INTERLOCK KIT	6SR0900-0SM00-0AM0
	DOOR IINTERLCOK	A5E32784169	SW,DOOR INTERLOCK	6SR0900-0RM00-0AM0
	INTERLOCK SUPPORT	A5E31961282	INTERLOCK SUPPORT	6SR0900-0SM04-0AM0
	DOOR INTERLOCK KIT	A5E41813036	DOOR INTERLOCK KIT	6SR0960-0SM61-0AD0
	DOOR IINTERLCOK	A1A472563	SW,DOOR INTERLOCK
	INTERLOCK SUPPORT	A5E41214878	INTERLOCK SUPPORT	6SR0960-0SM62-0AD0
CDS1	AUX CONTACT	LDZ10501487	AUX CONTACT	6SR3900-0KM00-0AM0
	CIRCUIT BREAKER	A5E02529974	DISCONN_NON FUSIBLE	6SR3900-0KM03-0AM0
	HANDLE PISTOL	A5E02530095	ACC_SWITCH_HANDLE_PISTOL_6mm_Y/R	6SR0960-0SM03-0AM0
	SHAFT	A5E02530097	ACC_SWITCH_SHAFT	6SR0960-0SM04-0AM0
	SHROUND	A5E02530093	ACC_SWITCH_SHROUD_3P_SNAP ON	6SR0960-0SM05-0AM0
CDS1	HANDLE	A5E30572769	SWITCH_COMMAND_ROT_STOP
	CIRCUIT BREAKER	A5E30572768	SWITCH_COMMAND_ROT_STOP
	AUX CONTACTOR	A5E02350404	accessories switch_cover_3-pol
Control Transformer	Control Transfomer	LDZ13500012.00	Control transformer	6SR0900-0KM00-0AM0
	CB21	A5E35282959	Switch_OVERCURRENT
	CB41	A5E35282730	Switch_OVERCURRENT
	CB42	A5E35282720	Switch_OVERCURRENT
UPS	UPS Pulsar 220VAC	LDZ10501472	UPS 700VA,230V,50/60HZ	6SR0960-0SM01-0AM0
	UPS GES-N1K	A5E31321302	UPS, 1000VA, 220V	6SR0900-0KM02-0AM0
	UPS	A5E35632577	POWER_SPLY_UPS	6SR5902-0KM00-0AM0
	UPS 120VAC	A5E34166880	UPS,700VA,120V,50/60HZ	6SR0900-0KM03-0AM0	A1A097618/LDZ097618C
	CONTACTOR CR2	A5E35282647	CONTACTOR_COPL
	ACC CONTACTOR CR2	A5E35328473	ACC_CONTACTORS
	CB8	A5E35282730	Switch_OVERCURRENT
E-stop	E-STOP BUTTON	A5E35334140	SWITCH_COMMAND_PRESS	6SR0900-0SM10-0AM0
	AUX CONTACTOR	A5E35334106	Auxiliary_switch	6SR0900-0SM11-0AM0
	SHROUND	A5E35334092	ACC_PUSH_BUTTON	6SR0900-0SM12-0AM0
	HOLDER	A5E35334172	6SR0900-0RM03-0AM0 \ACC_SWITCH_BRACKET_P	6SR0900-0RM03-0AM0
SW 3POS	FIX BRACKET	A5E35334172	ACC_SWITCH_BRACKET_P	6SR0900-0RM03-0AM0
	AUX.CONTACTOR	A5E35334120	6SR0900-0RM02-0AM0 \Auxiliary_switch	6SR0900-0RM02-0AM0
	SW OPERATOR	A5E35334133	SWITCH_COMMAND	6SR0900-0SM13-0AM0
TRIP MV RELAY	RELAY	A5E35282660	CONTACTOR_COPL
	RELAY	A5E35282647	CONTACTOR_COPL
	SUPPRESSOR	A5E35328473	ACC_CONTACTORS
	LOW PASS	A5E30204948	Filter_LOWPASS	6SR0900-0KM01-0AM0
	LATCHING RELAY	LDZ10506452	RELAY,LATCHING	6SR0900-0PM00-0AM0
	LATCHING RELAY	LDZ10506414	RELAY,LATCHING	6SR0900-0PM01-0AM0
FIBER OPTIC	FIBER OPTIC LINK CABLE	A5E45127002	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM10-0AM0
	FIBER OPTIC LINK CABLE	A5E45127003	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM11-0AM0
	FIBER OPTIC LINK CABLE	A5E45127004	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM12-0AM0
	FIBER OPTIC LINK CABLE	A5E45127005	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM13-0AM0
	FIBER OPTIC LINK CABLE	A5E45127014	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM13-0AM0
	FIBER OPTIC LINK CABLE	A5E45127009	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM15-0AM0
	FIBER OPTIC LINK CABLE	A5E45127010	FIBER OPTIC ASSY, DUPLEX	6SR0960-0LM16-0AM0
	FIBER OPTIC LINK CABLE	LDZ11500211.8	FIBER OPTIC ASSY, DUPLEX		LDZ085868C
	FIBER OPTIC LINK CABLE	LDZ11500211.10	FIBER OPTIC ASSY, DUPLEX
	FIBER OPTIC LINK CABLE	A5E03002012	FIBER OPTIC ASSY, DUPLEX
	FIBER OPTIC LINK CABLE	A5E03002015	FIBER OPTIC ASSY, DUPLEX
Reactor Cabinet	Blower	A5E02765231	AXIALFAN
	Switch_OVERCURRENT	A5E36500639	Switch_OVERCURRENT
	CONTACTOR	A5E32362953	CONTACTOR_AC
	SUPPRESSOR	A5E35328464	ACC_CONTACTORS
EMI	EMI FILTER	LDZ10506412	EMI FILTER	6SR3900-0KM02-1AM0
TEMP MONITOR	TEMP MONITOR	A5E30120295	4 CHANNEL
	TEMP MONITOR	A5E30120296	CONV ACC 4 CHANNLE EXTENTION
	TEMP MONITOR	A5E31243396	CONV ACC 8 CHANNLE EXTENTION
	TEMP MONITOR	A5E30241226	ModBus_INSIDE
LIFT	LIFT TROLLEY	A5E37046020	Power Cell Lift Trolley	6SR0960-0SM15-0AM0
Voltage regulator	Voltage regulator	A5E31200088	Voltage regulator	6SR5902-0SM00-0AM0
CRC	CRC CLEANER	LDZ10502871	CRC electrical cleaner
G3
Power Cell*	70 A Cell	LDZ14501000.070	G3 CELL NBH 70A 630V	6SR3902-0AB00-0AM0
	100 A Cell	LDZ14501000.100	G3 CELL NBH 100A 630V	6SR3902-0AC00-0AM0
	140 A Cell	LDZ14501001.140	G3 CELL NBH 140A 630V	6SR3902-0AD00-0AM0
	200 A Cell	LDZ14501002.200	G3 CELL NBH 200A 630V	6SR3902-0AE00-0AM0
	260 A Cell	LDZ14501002.260	G3 CELL NBH 260A 630V	6SR3902-0AF00-0AM0
Cell Input Fuses	Cell FUSE	LDZ10501431	G3 CELL FUSE	6SR3900-0JM41-0AM0
	Cell FUSE	LDZ10501432	G3 CELL FUSE	6SR3900-0JM42-0AM0
	Cell FUSE	LDZ10501433	G3 CELL FUSE	6SR3900-0JM43-0AM0
	Cell FUSE	LDZ10501434	G3 CELL FUSE	6SR3900-0JM44-0AM0
	Cell FUSE	LDZ10501435	G3 CELL FUSE	6SR3900-0JM40-0AM0
Cell Control Board	CCB	A1A10000432.31M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM43-0AD0	A1A10000432.31
	CCB	A1A10000432.34M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM44-0AD0	A1A10000432.34
	CCB	A1A10000432.30M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM42-0AD0	A1A10000432.30
	CCB	A1A10000432.00M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM38-0AD0	A1A10000432.00/LDZ10000432.00C
	CCB	A1A10000432.01M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM40-0AD0	A1A10000432.01/LDZ10000432.01C
	CCB	A1A10000432.02M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM41-0AD0	A1A10000432.02/LDZ10000432.02C
	CCB	A1A10000432.34M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM44-0AD0	10504423
	CCB	A1A10000432.91M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM47-0AD0	10504424
	CCB	A1A10000432.92M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM48-0AD0	10504422
	CCB	A1A10000432.93M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM50-0AD0	10504421
Air Filters	Air Filters	LDZ10501353	FILTER, 21.5"X18.5"X0.875	6SR3900-0FM01-0AM0
Air Filters	Air Filters	LDZ10501351	FILTER, 18.75"X18.75"X0.875	6SR3900-0FM10-0AM0
Hall Effect	500A HALL EFFECT CT	LDZ10501364	CURR TRNSDCR,CLSD LOOP	6SR0900-0HM01-0AM0
	Hall effect power supply	A5E33980677	HALLCT PWR	6SR0960-0EM01-0AM0	LDZ10501373/LDZ094888C
	Circuit breaker	A5E35282720	Switch_OVERCURRENT
	burden resistor	A1A164372.48	CURR XDUCER BURDEN	6SR0960-1CM22-0AD0	LDZ164372.48C
	burden resistor	A1A164372.26	CURR XDUCER BURDEN	6SR0960-1CM17-0AD0	LDZ164372.26C
	burden resistor	A1A164372.42	CURR XDUCER BURDEN	6SR0960-1CM18-0AD0	LDZ164372.42C
	burden resistor	A1A164372.46	CURR XDUCER BURDEN	6SR0960-1CM20-0AD0	LDZ164372.46C
	burden resistor	A1A164372.47	CURR XDUCER BURDEN	6SR0960-1CM21-0AD0	LDZ164372.47C
Blower Kit and start kit for RH56	22.4 blower	LDZ10501601	BLOWER,22.4",380V,50HZ	6SR3900-0GM04-0AD0
	Blower inlet ring	LDZ10501602	INLET RING,22.4"
	DAMPER	LDZ10501611	DAMPER,60"
	CIRCUIT BREAKER	A5E35283096	Switch_MOTOR
	CONTACTOR	A5E32362953	CONTACTOR_AC
	ACC-CONTACTOR	A5E35328464	ACC_CONTACTORS
Blower Kit and start kit for RH50	19.8 blower	LDZ10501603	BLOWER,19.8",380V,50HZ	6SR3900-0GM01-1AD0
	DAMPER	LDZ10501612	DAMPER,77"
	blower Inlet ring	LDZ10501604	INLET RING,19.8"
Cell Bypass	Bypass Contactor	LDZ14500013., 00	BYPASS CONTACTOR ASSY	6SR3960-0EA01-0AM0
	Bypass Control Board	A5E02634309	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EM08-0AD0	LDZ363662.01C
	Power Supply For Bypass	A1A363549.00	POWER SUPPLY ASSY FOR BYPASS	6SR3960-0EA11-0AD0	LDZ363549.00C
CAPACITOR	CAP	LDZ10501951	CAP EL TC CPR
CAPACITOR	CAP	LDZ10501952	CAP EL TC CPR
IGBT&POWER DIODE	IGBT	LDZ10503103	DUAL IGBT MODULE
	IGBT	LDZ10503105	IGBT MODULE
	POWER DIODE	LDZ10503009	PWR MODULE DIODE(+/-)
	POWER DIODE	LDZ10503008	PWR MODULE DIODE(+/-)
	POWER DIODE	A5E38625958	DUAL RECT. MODULE
CAP SHARE RESISTOR	CAP SHARE RESISTOR	LDZ10503251	RESISTOR
CAP SHARE RESISTOR	CAP SHARE RESISTOR	LDZ10503252	RESISTOR
SUPPERSSOR CAP	CAP MTLZD POLYPROP	LDZ10503201	CAP MTLZD POLYPROP
SUPPERSSOR CAP	CAP MTLZD POLYPROP	LDZ10503202	CAP MTLZD POLYPROP
HEAT SINK	HEAT SINK	LDZ10502901	HEATSINK
HEAT SINK	HEAT SINK	LDZ10502902	HEATSINK
WIRE KIT	WIRE HARNESS	LDZ14501000.KTWH	WIRE HARNESS
WIRE KIT	WIRE HARNESS	LDZ14501002.KTWH	WIRE HARNESS
PTC	PTC	A1A094595	PTC
G3E
Power Cell*	315 A Cell	LDZ31500082.315	G3E CELL,315A, 690V	6SR3902-0AG00-0AM0
	375 A Cell	LDZ31500082.375	G3E CELL,375A, 690V	6SR3902-0AH00-0AM0
	500 A Cell	LDZ31500082.500	G3E CELL,500A, 690V	6SR3902-0AJ00-0AM0	31000082.500
	660 A Cell	LDZ31500082.660	G3E CELL,660A, 690V	6SR3902-0AK00-0AM0	31000082.660
	720 A Cell	A5E02772515	G3E CELL,720A, 630V	6SR3902-0AL00-0AM0
Power Cell* U55	315 A Cell	A5E31299635	G3E CELL,315A, 690V, H	6SR3902-0AG01-0AM0
	375 A Cell	A5E31299652	G3E CELL,375A, 690V, H	6SR3902-0AH01-0AM0
	500 A Cell	A5E31299891	G3E CELL,500A, 690V, H	6SR3902-0AJ01-0AM0
	660 A Cell	A5E31300233	G3E CELL,660A, 690V, H	6SR3902-0AK01-0AM0
	720 A Cell	A5E31299628	G3E CELL,720A, 630V, H	6SR3902-0AL01-0AM0
Cell Input Fuses	Cell FUSE	LDZ10506512	G3E CELL FUSE	6SR3960-0JA00-0AD0
	Cell FUSE	LDZ10506511	G3E CELL FUSE	6SR3960-0JA01-0AD0
	Cell FUSE	LDZ10506515	G3E CELL FUSE	6SR3900-0JM47-0AM0
	Cell FUSE	LDZ10506516	G3E CELL FUSE	6SR3960-0JA03-0AD0	LDZ095786C
	Cell FUSE	A5E01654646	G3E CELL FUSE	6SR3900-0JM02-0AD0
Cell Control Board	ACCB	A5E34621797054	PCA 630/690/750V ACCB	6SR0960-0AM74-0AD0
	CCB	A1A10000432.54M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM26-0AD0	LDZ10000432.54C
	CCB	A5E03545933	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM52-0AD0
	ACCB	A5E34621797053	PCA 630/690/750V ACCB	6SR0960-0AM73-0AD0
	CCB	A1A10000432.53M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM45-0AD0	LDZ10000432.53C
	CCB	A5E03545931	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM51-0AD0
	CCB	A1A10000432.73M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM46-0AD0
	CCB	A5E03545937	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM56-0AD0
Hall Effect	2000A, HECT	LDZ10501376	CURR TRNSDCR,CLSD LOOP	6SR0900-0HM00-0AM0
	Circuit breaker	A5E35282720	Switch_OVERCURRENT
	burden resistor	A1A13000346.07	RESISTOR,HALL EFF BURD	6SR0960-1CM07-0AD0	LDZ13000346.07C
	burden resistor	A1A13000346.05	RESISTOR,HALL EFF BURD	6SR0960-1CM05-0AD0	LDZ13000346.05C
	burden resistor	A1A13000346.04	RESISTOR,HALL EFF BURD	6SR0960-1CM04-0AD0	LDZ13000346.04C
	burden resistor	A1A13000346.02	RESISTOR,HALL EFF BURD	6SR0960-1CM03-0AD0	LDZ13000346.02C
	burden resistor	A5E01700766	RESISTOR,HALL EFF BURD	6SR0960-1CM02-0AD0
Cell Bypass	Bypass Contactor	A5E02610994	HIGH CURR.CONTACTOR ASSY	6SR3960-0EA00-0AM0	A1A10000070.00
	Bypass Control Board	A1A10000416.00M	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EA03-0AD0	LDZ363662.00C
	Bypass Power Supply Secondaries	A1A363634.01	POWER SUPPLY	6SR3960-0EA01-0AD0	LDZ363634.01C
	Secondaries Bypass Power Supply	A5E02098552	POWER SUPPLY	6SR3900-0KM11-0AD0
CAP	CAP	LDZ10501952	CAP EL TC CPR
CAP	CAP	LDZ10501956	CAP EL TC CPR
IGBT & POWE DIODE	IGBT	LDZ10503116	DUAL IGBT MODULE
	IGBT	LDZ10503119	DUAL IGBT MODULE
	IGBT	A1A099068	DUAL IGBT MODULE
	POWER DIODE	LDZ10503005	PWR MODULE DIODE(+/-)
	POWER DIODE	LDZ10503006	PWR MODULE DIODE(+/-)
GCB	GATE CLAMP BOARD	A1A10000023.00M	PCA, GATE CLAMP (DUAL)		LDZ10000023.00C
CAP SHARE RESISTOR	CAP SHARE RESISTOR	LDZ10503256	RESISTOR
WIRE KIT	WIRE KIT	LDZ14500028.00	WIRE KIT
	WIRE KIT	LDZ14500028.01	WIRE KIT
	BLEEDER WIRE	LDZ11500139.06	R2 BLEEDER WIRE ASSY
G4 CN
Power Cell*	40A CELL	LDZ10500424.040	G4 CELL 40A, 750V	6SR4902-0AA00-0AM0
	70A CELL	A5E31386448	G4 CELL 70A, 750V	6SR4902-0AB02-0AM0
	100A CELL	A5E31449525	G4 CELL 100A, 750V	6SR4902-0AC02-0AM0
	140A CELL	A5E31450208	G4 CELL 140A, 750V	6SR4902-0AD02-0AM0
Power Cell* U55	40A CELL	A5E31271622	G4 CELL 40A, 750V, H	6SR4902-0AA01-0AM0
	70A CELL	A5E31459870	G4 CELL 70A, 750V, H	6SR4902-0AB03-0AM0
	100A CELL	A5E31459864	G4 CELL 100A, 750V, H	6SR4902-0AC03-0AM0
	140A CELL	A5E31459868	G4 CELL 140A, 750V, H	6SR4902-0AD03-0AM0
Cell Input Fuses	CELL FUSE	A5E31556481	G4 CELLFUSE	6SR4900-0JM07-0AM0	A5E31556479
	CELL FUSE	A5E31476702	G4 CELLFUSE	6SR4900-0JM08-0AM0	A5E31418506
	CELL FUSE	A5E31476700	G4 CELLFUSE	6SR4900-0JM10-0AM0	A5E31418599
	CELL FUSE	A5E31476394	G4 CELLFUSE	6SR4900-0JM06-0AM0	A5E31375401
Cell control board	ACCB	A5E34621797071	PCA 630/690/750V ACCB	6SR0960-0AM71-0AD0
	CCB	A1A10000432.71M	PCA 630/690/750V CELL CONTROL	6SR0960-1BA00-0AA0
	CCB	A5E03545935	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM53-0AD0
HALL EFFECT	500A, HECT	LDZ10501364	CURR TRNSDCR,CLSD LOOP	6SR0900-0HM01-0AM0
	burden resistor	A5E01473390	CURR XDUCER BURDEN	6SR0960-1CM15-0AD0
	burden resistor	A1A164372.48	CURR XDUCER BURDEN	6SR0960-1CM22-0AD0	LDZ164372.48C
	burden resistor	A1A164372.26	CURR XDUCER BURDEN	6SR0960-1CM17-0AD0	LDZ164372.26C
	burden resistor	A1A164372.42	CURR XDUCER BURDEN	6SR0960-1CM18-0AD0	LDZ164372.42C
Cell Bypass	BYPASS CONTATOR	A5E02634363	BYPASS CONTACTOR	6SR3960-0EA01-1AM0
	PCA BYPASS CONTROL	A5E02634309	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EM08-0AD0	LDZ363662.01C
	BYPASS POWER SUPPLY	A5E38384485	POWER SUPPLY ASSY,BYPASS,uH	6SR4900-0EM05-0AM1	LDZ10000484.00C
	FIBER OPTIC LINK CABLE	A5E03002023	FIBER OPTIC ASSY, DUPLEX	6SR0900-0LM00-0AM0
CAP	CAP	LDZ10501954	CAP EL TC CPR
CAP	CAP	A1A0101340	CAP EL TC CPR
G4
Power Cell*	40A CELL	LDZ10500424.040	G4 CELL 40A, 750V	6SR4902-0AA00-0AM0
	70A CELL	LDZ10500424.070	G4 CELL 70A, 750V	6SR4902-0AB00-0AM0
	100A CELL	LDZ10500424.100	G4 CELL 100A, 750V	6SR4902-0AC00-0AM0
	140A CELL	LDZ10500424.140	G4 CELL 140A, 750V	6SR4902-0AD00-0AM0
	200A CELL	LDZ10500494.200	G4 CELL 200A, 750V	6SR4902-0AE00-0AM0
	260A CELL	LDZ10500494.260	G4 CELL 260A, 750V	6SR4902-0AF00-0AM0
Power Cell* U55	40A CELL	A5E31271622	G4 CELL 40A, 750V, H	6SR4902-0AA01-0AM0
	70A CELL	A5E31271660	G4 CELL 70A, 750V, H	6SR4902-0AB01-0AM0
	100A CELL	A5E31302610	G4 CELL 100A, 750V, H	6SR4902-0AC01-0AM0
	140A CELL	A5E31302611	G4 CELL 140A, 750V, H	6SR4902-0AD01-0AM0
	200A CELL	A5E31307047	G4 CELL 200A, 750V, H	6SR4902-0AE02-0AM0
	260A CELL	A5E31307048	G4 CELL 260A, 750V, H	6SR4902-0AF02-0AM0
Cell Input Fuses	CELL FUSE	LDZ10506536	G4 CELLFUSE	6SR4900-0JM00-0AM0	LDZ10506536
	CELL FUSE	A1A099718	G4 CELLFUSE	6SR4900-0JM01-1AD0	LDZ10506537
	CELL FUSE	A1A099719	G4 CELLFUSE	6SR4900-0JM01-0AD0	LDZ10506538
	CELL FUSE	A1A099720	G4 CELLFUSE	6SR4900-0JM00-2AD0	LDZ10506539
	CELL FUSE	A1A0100502	G4 CELLFUSE	6SR4900-0JM01-2AD0	LDZ10506540
	CELL FUSE	A1A0100505	G4 CELLFUSE	6SR4900-0JM00-0AD0	LDZ10506541
	CELL FUSE	A1A099725	G4 CELLFUSE	6SR0960-0JM51-0AD0	LDZ10506547
	CELL FUSE	A1A099726	G4 CELLFUSE	6SR0960-0JM52-0AD0	LDZ10506548
	CELL FUSE	A1A099727	G4 CELLFUSE	6SR4900-0JM03-0AD0	LDZ10506549
	CELL FUSE	A1A099728	G4 CELLFUSE	6SR4900-0JM02-0AD0	LDZ10506550
	CELL FUSE	A5E02547653	G4 CELLFUSE	6SR4900-0JM04-0AM0
	CELL FUSE	A5E02547700	G4 CELLFUSE	6SR4900-0JM05-0AM0
Cell control board	ACCB	A5E34621797071	PCA 630/690/750V ACCB	6SR0960-0AM71-0AD0
	CCB	A1A10000432.71M	PCA 630/690/750V CELL CONTROL	6SR0960-1BA00-0AA0
	CCB	A5E03545935	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM53-0AD0
	ACCB	A5E34621797072	PCA 630/690/750V ACCB	6SR0960-0AM72-0AD0
	CCB	A1A10000432.72M	PCA 630/690/750V CELL CONTROL	6SR0960-1BA01-0AA0
	CCB	A5E03545936	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM54-0AD0
Air Filter	Air Filter	LDZ11500445.00	FILTER MP25, 690X415X22MM	6SR4960-0FA03-0AM0
	Air Filter	LDZ11500446.00	FILTER MP25, 483X198X22MM	6SR4960-0FA02-0AM0
	Air Filter	LDZ11500660.00	XFMR FILTER,571.5x457.2x25.4MM	6SR4900-0FM00-0AM0
	Air Filter	LDZ11500661.00	CELL FILTER,600x200x25.4MM	6SR4900-0FM10-0AM0
	Air Filter	A5E03927689	Filter_Assembly	6SR0900-0FM00-0AM0
	FILTER MAT	A5E03935625	FILTER MAT	6SR4900-0FM20-0AM0
	Air Filter	LDZ10501463	FILTER, 615x490x22MM	6SR3900-0FM00-0AM0
BLOWER KIT	RH50V BLOWER	A5E02466773	Fan,AC, RH50V	6SR4900-0GM00-0AD0
	INLET RING	LDZ10501604	INLET RING,19.8"
	CONTACTOR	A5E32362953	CONTACTOR_AC
	SUPPRESSOR	A5E35328464	ACC_CONTACTORS
	CIRCUIT BREAKER	A5E35283013	Switch_MOTOR
	BLOWE KIT	A5E03458919	BLOWER KIT,NO CAGE	6SR4900-0GM02-0AM0
	BLOWER	A5E34389197	BLOWER	6SR0900-0GA04-0AD0	LDZ10501659
	INLET RING	LDZ10501660	RING
	BLOWER PARTS	LDZ10505411	RES MET FL	6SR0900-0SM05-0AM0
	BLOWER PARTS	LDZ10503257	DIODE,ZENER
	BLOWER	A5E44574183	fan_RH63V	6SR0960-0GM00-0AM0
	INLET RING	A5E44574192	INLET RING	6SR0960-0GM01-0AM0
	CONTACTOR	A5E32362953	CONTACTOR_AC
	SUPPRESSOR	A5E35328464	ACC_CONTACTORS
	CIRCUIT BREAKER	A5E31763338	Switch_MOTOR
BLOWER Kit and START for RH56	RH56 BLOWER	LDZ10501601	BLOWER,22.4",380V,50HZ	6SR3900-0GM04-0AD0
	Blower inlet ring	LDZ10501602	INLET RING,22.4"
	CIRCUIT	A5E36500733	Switch_OVERCURRENT
	CONTACTOR	A5E32362953	CONTACTOR_AC
	ACC_SUPPRESSOR	A5E35328464	ACC_CONTACTORS
BLOWER Kit and START FOR RH63	RH63 Blower	LDZ10501650	AC FAN, 25.00"	6SR0900-0GA05-0AD0
	INLET RING	LDZ10501651	INLET RING,25"
	CIRCUIT	A5E35283013	Switch_MOTOR
	CONTACTOR	A5E32362953	CONTACTOR_AC
	ACC_SUPPRESSOR	A5E35328464	ACC_CONTACTORS
BLOWER Kit and START for RH71	RH71 BLOWER	LDZ10501652	AC FAN, 28.1"	6SR3900-0GM05-0AD0
	BLOWER INLET RING	LDZ10501653	INLET RING,28.1"
	CIRCUIT BREAKER	A5E31763338	Switch_MOTOR
	CONTACTOR	A5E32362953	CONTACTOR_AC
	ACC_SUPPRESSOR	A5E35328464	ACC_CONTACTORS
HALL EFFTECT	200A, HECT	A1A089834	CURR TRNSDCR,CLSD LOOP	6SR0960-0AE02-0AD0
	500A, HECT	LDZ10501364	CURR TRNSDCR,CLSD LOOP	6SR0900-0HM01-0AM0
	burden resistor	A5E01473390	CURR XDUCER BURDEN	6SR0960-1CM15-0AD0
	burden resistor	A1A164372.48	CURR XDUCER BURDEN	6SR0960-1CM22-0AD0	LDZ164372.48C
	burden resistor	A1A164372.26	CURR XDUCER BURDEN	6SR0960-1CM17-0AD0	LDZ164372.26C
	burden resistor	A1A164372.42	CURR XDUCER BURDEN	6SR0960-1CM18-0AD0	LDZ164372.42C
	burden resistor	A1A164372.46	CURR XDUCER BURDEN	6SR0960-1CM20-0AD0	LDZ164372.46C
	burden resistor	A1A164372.47	CURR XDUCER BURDEN	6SR0960-1CM21-0AD0	LDZ164372.47C
CELL BYPASS	BYPASS CONTACTOR	A5E03772188	BYPASS CONTACTOR ASSY	6SR4900-0EM01-0AM0
	BYPASS CONTATOR ASSEMBLY	A5E34919093	BYPASS CONTACTOR	6SR4900-0EM06-0AM0
	BYPASS CONTATOR	A5E02634363	BYPASS CONTACTOR	6SR3960-0EA01-1AM0
	POWER SUPPLY	A5E38384485	POWER SUPPLY ASSY, BYPASS, Uh	6SR4900-0EM05-0AM1	LDZ10000484.00C
	BYPASS BOARD	A5E02634309	PCA,W/FIRMWARE,BYPASS	6SR0960-0EM08-0AD0	LDZ363662.01C
CAP	CAP	LDZ10501954	CAP EL TC CPR
CAP	CAP	LDZ10501955	CAP EL TC CPR
IGBT&DIODE	IGBT	LDZ10503103	DUAL IGBT MODULE
	IGBT	LDZ10503118	DUAL IGBT MODULE
	POWER DIODE	A1A088199	DUAL RECT. MODULE
	POWER DIODE	LDZ10503008	PWR MODULE DIODE(+/-)
	POWER DIODE	A5E38625958	DUAL RECT. MODULE
GCB	GATE CLAMP BOARD	A1A10000428.00M	PCA GATE CLAMP BOARD W/RESISTOR
GCB	GATE CLAMP BOARD	A1A10000428.05M	PCA GATE CLAMP BOARD W/RESISTOR
RESITOR	CAP SHARE RESISTOR	LDZ10503258	RESISTOR
WIRE KIT	WIRE KIT	LDZ14500424.WHNS	WIRE HARNESS
WIRE KIT	WIRE KIT	LDZ14500494.WHNS	WIRE HARNESS
PTC	PTC	A1A094595	PTC
POWER CLIP	POWER CLIP	A5E32923133	DUAL POLE POWER CLIP		A5E01362067
Power Cell*	40A CELL	A5E33094595	G4 CELL 40A, 750V	6SR4902-0AA00-0AM1
	70A CELL	A5E32855090	G4 CELL 70A, 750V	6SR4902-0AB00-0AM1
	100A CELL	A5E33096198	G4 CELL 100A, 750V	6SR4902-0AC00-0AM1
	140A CELL	A5E32539903	G4 CELL 140A, 750V	6SR4902-0AD00-0AM1
	200A CELL	A5E35242752	G4 CELL 200A, 750V	6SR4902-0AE00-0AM1
	260A CELL	A5E35494212	G4 CELL 260A, 750V	6SR4902-0AF00-0AM1
	315A CELL	A5E37684782	G4E CELL 315A, 750V	6SR4902-0AG00-0AM1
	375A CELL	A5E36524726	G4E CELL 375A, 750V	6SR4902-0AH00-0AM1
Power Cell* U55	40A CELL	A5E33115305	G4 CELL 40A, 750V, H	6SR4902-0AA01-0AM1
	70A CELL	A5E33115306	G4 CELL 70A, 750V, H	6SR4902-0AB01-0AM1
	100A CELL	A5E33115308	G4 CELL 100A, 750V, H	6SR4902-0AC01-0AM1
	140A CELL	A5E33115309	G4 CELL 140A, 750V, H	6SR4902-0AD01-0AM1
	200A CELL	A5E35681166	G4 CELL 200A, 750V, H	6SR4902-0AE01-0AM1
	260A CELL	A5E35680951	G4 CELL 260A, 750V, H	6SR4902-0AF01-0AM1
	315A CELL	A5E38865746	G4E CELL 315A, 750V, H	6SR4902-0AG01-0AM1
	375A CELL	A5E38865742	G4E CELL 375A, 750V, H	6SR4902-0AH01-0AM1
Cell Input Fuses	CELL FUSE	A5E31556481	G4 CELLFUSE	6SR4900-0JM07-0AM0
	CELL FUSE	A5E31476702	G4 CELLFUSE	6SR4900-0JM08-0AM0
	CELL FUSE	A5E31476700	G4 CELLFUSE	6SR4900-0JM01-0AM0
	CELL FUSE	A5E31476394	G4 CELLFUSE	6SR4900-0JM00-2AM0
	CELL FUSE	A5E35399071	G4 CELLFUSE	6SR4900-0JM11-0AM0
	CELL FUSE	A5E35399062	G4 CELLFUSE	6SR4900-0JM12-0AM0
	CELL FUSE	A5E38495559	G4 CELLFUSE	6SR4900-0JM00-0AM1
	CELL FUSE	A5E38495560	G4 CELLFUSE	6SR4900-0JM01-0AM1
Cell control board	ACCB	A5E34621797071	PCA 630/690/750V ACCB	6SR0960-0AM71-0AD0
	CCB	A1A10000432.71M	PCA 630/690/750V CELL CONTROL	6SR0960-1BA00-0AA0
	CCB	A5E03545935	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM53-0AD0
	ACCB	A5E34621797072	PCA 630/690/750V ACCB	6SR0960-0AM72-0AD0
	CCB	A1A10000432.72M	PCA 630/690/750V CELL CONTROL	6SR0960-1BA01-0AA0
	CCB	A5E03545936	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM54-0AD0
	ACCB	A5E34621797002	PCA 630/690/750V ACCB	6SR0960-0AM82-0AD0
	CCB	A5E33503006002	PCA 630/690/750V CELL CONTROL	6SR4900-0AM27-0AD0
	CCB	A5E34890686002	PCA 630/690/750V CELL CONTROL 4000M	6SR0960-0AM61-0AD0
BLOWER Kit and START for RHA500	RHA500 Blower	A5E31418276	Centrifugal fan 19.8"	6SR4900-0GM00-0AM0
	INLET RING	A5E31418339	INLET RING
	CIRCUIT	A5E35283013	Switch_MOTOR
	CONTACTOR	A5E32362953	CONTACTOR_AC
	SUPPRESSOR	A5E35328464	SUPPRESSOR,ACC_CONTACTORS
BLOWER Kit and START for RHA450	RHA450 BLOWER	A5E31417482	Centrifugal fan 17.8"	6SR4900-0GM01-0AM0
	BLOWER INLET RING	A5E31418191	INLET RING 17.8"
	CIRCUIT	A5E35283096	Switch_MOTOR
BLOWER Kit and START for RHA560	RHA560 BLOWER	A5E32406616	Centrifugal fan 22"	6SR3900-0GM01-0AM1
	BLOWER INLET RING	A5E33846996	INLET RING 22"
	CIRCUIT BREAKER	A5E31763338	Switch_MOTOR
HALL EFFTECT	500A, HECT	A5E32401989	CURR TRNSDCR,CLSD LOOP	6SR0960-0AJ02-0AM1
	1000A, HECT	A5E00807402	CURR TRNSDCR,CLSD LOOP	6SR0960-0AD00-0AM1
	burden resistor	A5E01473390	CURR XDUCER BURDEN	6SR0960-1CM15-0AD0
	burden resistor	A1A164372.48	CURR XDUCER BURDEN	6SR0960-1CM22-0AD0	LDZ164372.48C
	burden resistor	A1A164372.26	CURR XDUCER BURDEN	6SR0960-1CM17-0AD0	LDZ164372.26C
	burden resistor	A1A164372.42	CURR XDUCER BURDEN	6SR0960-1CM18-0AD0	LDZ164372.42C
	burden resistor	A5E35426522	CURR XDUCER BURDEN	6SR4900-0CB00-0AM0
	burden resistor	A5E35426519	CURR XDUCER BURDEN	6SR4900-0CB01-0AM0
	burden resistor	A1A13000346.07	CURR XDUCER BURDEN	6SR0960-1CM07-0AD0
	burden resistor	A1A13000346.05	CURR XDUCER BURDEN	6SR0960-1CM05-0AD0
Cell Bypass	BYPASS CONTATOR	A5E32187356	BYPASS CONTACTOR	6SR4900-0EM00-0AM0
	BYPASS CONTATOR	A5E02634363	BYPASS CONTACTOR	6SR3960-0EA01-1AM0
	BYPASS CONTATOR	A5E35230339	BYPASS CONTACTOR	6SR4900-0EM04-0AM0
	PCA BYPASS CONTROL	A5E02634309	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EM08-0AD0	LDZ363662.01C
	BYPASS POWER SUPPLY	A5E38384485	POWER SUPPLY ASSY,BYPASS,uH	6SR4900-0EM05-0AM1
CAP	CAP	A5E32573147	CAP EL TC CPR
	CAP	A5E35399008	CAP EL TC CPR
	CAP	A5E36104642	CAP EL TC CPR
IGBT & DIODE	IGBT	LDZ10503103	DUAL IGBT MODULE
	IGBT	LDZ10503118	DUAL IGBT MODULE
	IGBT	A5E31543362	DUAL IGBT MODULE
	POWER DIODE	A5E32573152	DUAL RECT. MODULE
	POWER DIODE	LDZ10503008	DUAL RECT. MODULE
	POWER DIODE	A5E38625958	DUAL RECT. MODULE
	POWER DIODE	A5E32841087	DUAL RECT. MODULE
GCB	GATE CLAMP BOARD	A1A10000428.00M	PCA GATE CLAMP BORD
	GATE CLAMP BOARD	A1A10000428.05M	PCA GATE CLAMP BORD
	GATE CLAMP BOARD	A5E35045443001	PCA GATE CLAMP BORD
WIRE KIT	WIRE KIT	A5E32308995	WIRE HARNESS
	WIRE KIT	A5E35066999	WIRE HARNESS
	WIRE KIT	A5E38837964	WIRE HARNESS
PTC	PTC	A1A094595	PTC
PTC	PTC	A1A094726	PTC
G4E
Power Cell	315A CELL	A5E37684782	G4E CELL 315A, 750V	6SR4902-0AG00-0AM1
	375A CELL	A5E36524726	G4E CELL 375A, 750V	6SR4902-0AH00-0AM1
	500A CELL	A5E36184862	G4E CELL 500A, 750V	6SR4902-0AJ00-0AM1
	660A CELL	A5E36184868	G4E CELL 660A, 750V	6SR4902-0AK00-0AM1
	750A CELL	A5E45164424	G4E CELL 750A, 750V	6SR4902-0AN00-0AM1
Power Cell* U55	315A CELL	A5E38865746	G4E CELL 315A, 750V, 4000M	6SR4902-0AG01-0AM1
	375A CELL	A5E38865742	G4E CELL 375A, 750V, 4000M	6SR4902-0AH01-0AM1
	500A CELL	A5E36223126	G4E CELL 500A, 750V, 4000M	6SR4902-0AJ01-0AM1
	660A CELL	A5E36223115	G4E CELL 660A, 750V, 4000M	6SR4902-0AK01-0AM1
Cell Input Fuses	CELL FUSE	A5E38495559	G4 CELLFUSE	6SR4900-0JM00-0AM1
	CELL FUSE	A5E38495560	G4 CELLFUSE	6SR4900-0JM01-0AM1
	CELL FUSE	A5E36109491	G4 CELLFUSE	6SR4900-0JM13-0AM0	A5E36104157
	CELL FUSE	A5E36109932	G4 CELLFUSE	6SR4900-0JM14-0AM0	A5E36104174
	CELL FUSE	A5E45293415	G4 CELLFUSE	6SR4900-0JM70-0AM1
	CELL FUSE	A5E36047963	G4 CELLFUSE	6SR4900-0JM01-3AD0
Cell control board	ACCB	A5E34621797002	PCA 630/690/750V ACCB	6SR0960-0AM82-0AD0
	CCB	A5E33503006002	PCA 630/690/750V CELL CONTROL	6SR4900-0AM27-0AD0
	CCB	A5E34890686002	PCA 630/690/750V CELL CONTROL U55	6SR0960-0AM61-0AD0
	ACCB	A5E34621797001	PCA 630/690/750V ACCB	6SR0960-0AM81-0AD0
	CCB	A5E33503006001	PCA 630/690/750V CELL CONTROL	6SR4960-0AM00-0AD0
	CCB	A5E34890686001	PCA 630/690/750V CELL CONTROL U55	6SR0960-0AM60-0AD0
	ACCB	A5E34621797003	PCA 630/690/750V CELL CONTROL	6SR0960-0AM80-0AD0
HALL EFFTECT	1000A, HECT	A5E00807402	CURR TRNSDCR,CLSD LOOP	6SR0960-0AD00-0AM1
	1000A, HECT	A5E38508031	CURR TRNSDCR,CLSD LOOP	6SR4900-0HM00-0AD0
	burden resistor	LDZ13000346.07	CURR XDUCER BURDEN	6SR0960-1CM07-0AM0
	burden resistor	A1A13000346.05	CURR XDUCER BURDEN	6SR0960-1CM05-0AD0
	burden resistor	A1A13000346.04	CURR XDUCER BURDEN	6SR0900-1CM00-0AM0
	burden resistor	A1A13000346.02	CURR XDUCER BURDEN	6SR0900-1CM01-0AM0
	burden resistor	A5E03413543	CURR XDUCER BURDEN	6SR4900-1CM00-0AD0
Pre-Charge	OVERCURRENT SWITCH	A5E36198585	SWITCH_OVERCURR
	UNDERVOLT SWITCH	A5E36199283	ACC_SWCH_UNDERVOLT
	CIRCUIT BREAKER	A5E36199121	ACC_Circuit breaker	6SR0900-0KM05-0AM0
	CIRCUIT BREAKER	A5E36201756	ACC_SWITCH
	CONTACTOR	A5E36105267	CONTACTOR_AC
	CONTACTOR	A5E35282647	CONTACTOR_COPL
	CONTACTOR SNUBBER	A5E35328473	ACC_CONTACTORS
	PUSH BUTTON	A5E36377092	SWITCH_COMMAND_PRESS	6SR0900-0RM01-0AM0
	AUXILIARY SWITCH	A5E35334120	Auxiliary_switch	6SR0900-0RM02-0AM0
	PUSH BUTTON BRACKET	A5E35334172	ACC_SWITCH_BRACKET	6SR0900-0RM03-0AM0
	ASM MONITOR	A5E02376768	ASM_MONITOR
	WAGO RELAY	LDZ10501494	WAGO RELAY MODULE	6SR0900-0RM04-0AM0
	CAP	A5E36109436	CAP_MKP_DMJ_MC	6SR0900-0SM07-0AM0
	RESISTORS	A5E36104570	RES_WIRE_POWER	6SR0900-1CM02-0AM0
CELL BYPASS	BYPASS CONTATOR	A5E02634363	BYPASS CONTACTOR	6SR3960-0EA01-1AM0
	BYPASS CONTATOR	A5E35230339	BYPASS CONTACTOR	6SR4900-0EM04-0AM0
	PCA BYPASS CONTROL	A5E02634309	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EM08-0AD0
	BYPASS POWER SUPPLY	A5E38384485	POWER SUPPLY ASSY,BYPASS,Uh	6SR4900-0EM05-0AM1
	BYPASS CONTATOR	A5E42921775	BYPASS CONTACTOR	6SR4900-0EM07-0AM0
	BYPASS CONTATOR	A5E35963048	BYPASS CONTACTOR	6SR3900-0KM04-0AM0
	PCA BYPASS CONTROL	A1A10000416.00M	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EA03-0AD0
	BYPASS POWER SUPPLY	A5E33720060	POWER SUPPLY ASSY,BYPASS,Uh	6SR0960-0EM18-0AD0
IGBT&DIODE	IGBT	A5E31543362	DUAL IGBT MODULE
	IGBT	A5E32841088	DUAL IGBT MODULE
	IGBT	A5E33032687	DUAL IGBT MODULE
	POWER DIODE	A5E32841087	DUAL RECT. MODULE
	RECTIFIER HEAT SINK	A5E34831359	RECTIFIER HEAT SINK
GCB	GATE CLAMP BOARD	A5E35045443001	PCA GATE CLAMP BORD W/RESISTOR
GCB	GATE CLAMP BOARD	A1A10000023.00M	PCA GATE CLAMP BORD W/RESISTOR
SUPPERSSOR	CAP SUPRESSOR	A5E34722396	CAP_MKP
G5
G5 VALUE POWER CELL	40A CELL	A5E39021149	G5 VAULE CELL 40A, 750V	6SR5902-0AA02-0AM1
	40A CELL WITH BYPASS	A5E39021146	G5 VAULE CELL 40A, 750V with Bypass	6SR5902-0AA13-0AM1
	70A CELL	A5E39021143	G5 VAULE CELL 70A, 750V	6SR5902-0AB02-0AM1
	70A CELL WITH BYPASS	A5E38977502	G5 VAULE CELL 70A, 750V with Bypass	6SR5902-0AB13-0AM1
	100A CELL	A5E42740268	G5 VAULE CELL 100A, 750V	6SR5902-0AC02-0AM1
	100A CELL WITH BYPASS	A5E42740240	G5 VAULE CELL 100A, 750V with Bypass	6SR5902-0AC13-0AM1
	140A CELL	A5E42740246	G5 VAULE CELL 140A, 750V	6SR5902-0AD02-0AM1
	140A CELL WITH BYPASS	A5E42740130	G5 VAULE CELL 140A, 750V with Bypass	6SR5902-0AD13-0AM1
	200A CELL	A5E44574249	G5 VAULE CELL 200A, 750V	6SR5902-0AE02-0AM1
	200A CELL WITH BYPASS	A5E42881731	G5 VAULE CELL 200A, 750V with Bypass	6SR5902-0AE13-0AM1
	260A CELL	A5E42881719	G5 VAULE CELL 260A, 750V	6SR5902-0AF02-0AM1
	260A CELL WITH BYPASS	A5E42881257	G5 VAULE CELL 260A, 750V with Bypass	6SR5902-0AF13-0AM1
G5 PERFORMANCE POWER CELL	40A CELL	A5E37417009	G5 PERORMANCE CELL 40A, 750V	6SR5902-0AA02-0AM0
	40A CELL WITH BYPASS	A5E37417012	G5 PERORMANCE CELL 40A, 750V with Bypass	6SR5902-0AA13-0AM0
	70A CELL	A5E37417022	G5 PERORMANCE CELL 70A, 750V	6SR5902-0AB02-0AM0
	70A CELL WITH BYPASS	A5E37417024	G5 PERORMANCE CELL 70A, 750V with Bypass	6SR5902-0AB13-0AM0
	100A CELL	A5E40739638	G5 PERORMANCE CELL 100A, 750V	6SR5902-0AC01-0AM0
	100A CELL WITH BYPASS	A5E40739666	G5 PERORMANCE CELL 100A, 750V with Bypass	6SR5902-0AC00-0AM0
	140A CELL	A5E40739640	G5 PERORMANCE CELL 140A, 750V	6SR5902-0AD00-0AM0
	140A CELL WITH BYPASS	A5E40739812	G5 PERORMANCE CELL 140A, 750V with Bypass	6SR5902-0AD01-0AM0
	200A CELL	A5E40873342	G5 PERORMANCE CELL 200A, 750V	6SR5902-0AE01-0AM0
	200A CELL WITH BYPASS	A5E40873334	G5 PERORMANCE CELL 200A, 750V with Bypass	6SR5902-0AE00-0AM0
	260A CELL	A5E40873345	G5 PERORMANCE CELL 260A, 750V	6SR5902-0AF00-0AM0
	260A CELL WITH BYPASS	A5E40873344	G5 PERORMANCE CELL 260A, 750V with Bypass	6SR5902-0AF01-0AM0
	40A CELL	A5E37417000	G5 PERORMANCE CELL 40A, 450V	6SR5902-0AA00-0AM0
	40A CELL WITH BYPASS	A5E37417002	G5 PERORMANCE CELL 40A, 450V with Bypass	6SR5902-0AA11-0AM0
	70A CELL	A5E37417014	G5 PERORMANCE CELL 70A, 450V	6SR5902-0AB00-0AM0
	70A CELL WITH BYPASS	A5E37417019	G5 PERORMANCE CELL 70A, 450V with Bypass	6SR5902-0AB11-0AM0
Cell Input Fuses	CELL FUSE	A5E39696191	G5 CELLFUSE	6SR5902-0JM01-0AM0
	CELL FUSE	A5E39487345	G5 CELLFUSE	6SR5902-0JM02-0AM0
	CELL FUSE	A5E31476700	G5 CELLFUSE	6SR5902-0JM03-0AM0
	CELL FUSE	A5E31476394	G5 CELLFUSE	6SR5902-0JM04-0AM0
	CELL FUSE	A5E35399071	G5 CELLFUSE	6SR4900-0JM11-0AM0
	CELL FUSE	A5E35399062	G5 CELLFUSE	6SR4900-0JM12-0AM0
	CELL FUSE	A1A099725	G5 CELLFUSE	6SR0960-0JM51-0AD0
	CELL FUSE	A1A099726	G5 CELLFUSE	6SR0960-0JM52-0AD0
	CELL FUSE	A1A099719	G5 CELLFUSE	6SR4900-0JM01-0AD0
	CELL FUSE	A1A099720	G5 CELLFUSE	6SR4900-0JM00-2AD0
	CELL FUSE	A1A0100502	G5 CELLFUSE	6SR4900-0JM01-2AD0
	CELL FUSE	A1A0100505	G5 CELLFUSE	6SR4900-0JM00-0AD0
	CELL FUSE	A1A099717	G5 CELLFUSE	6SR4900-0JM00-1AD0
	CELL FUSE	A1A099718	G5 CELLFUSE	6SR4900-0JM01-1AD0
BLOWER Kit and START for RHA560	RHA560 BLOWER	A5E32406616	Centrifugal fan 22"	6SR3900-0GM01-0AM1
	BLOWER INLET RING	A5E33846996	INLET RING 22"
	RHA560 BLOWER	A5E44882190	Centrifugal fan 22"	6SR5900-0GM00-0AM0
	BLOWER INLET RING	A5E33846996	INLET RING 22"
	CIRCUIT BREAKER	A5E31763338	Switch_MOTOR
HALL EFFTECT	500A, HECT	A5E39896940	CURR TRNSDCR,CLSD LOOP	6SR0960-0HM15-0AD0	A5E32401989
	500A, HECT	A5E38507829	CURR TRNSDCR,CLSD LOOP	6SR5900-0HM00-0AM0
	burden resistor	A5E01473390	CURR XDUCER BURDEN	6SR0960-1CM15-0AD0
	burden resistor	A1A164372.48	CURR XDUCER BURDEN	6SR0960-1CM22-0AD0
	burden resistor	A1A164372.26	CURR XDUCER BURDEN	6SR0960-1CM17-0AD0
	burden resistor	A1A164372.42	CURR XDUCER BURDEN	6SR0960-1CM18-0AD0
	burden resistor	A5E35426522	CURR XDUCER BURDEN	6SR4900-0CB00-0AM0
	burden resistor	A5E35426519	CURR XDUCER BURDEN	6SR4900-0CB01-0AM0
Cell Bypass	PCA BYPASS CONTROL	A5E37926678	PCA W/FIRMWARE, BYPASS CONTROL	6SR5900-0EM01-0AD0
	PCA BYPASS CONTROL	A5E40857482	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0AM83-0AD0
	BYPASS POWER SUPPLY	A5E38292328	POWER SUPPLY ASSY,BYPASS,uH	6SR5902-0EM00-0AM0
CAP	CAP	A5E36635506	CAP EL TC CPR
	CAP	A5E42793912	CAP EL TC CPR
	CAP ADAPTER	A5E39564951	CAPACITOR ADAPTER
	CAP	A5E41558648	CAP EL TC CPR
	CAPACITOR CLAMP	A5E39953080	CAPACITOR CLAMP
CCB	CCB	A5E36464150001	PCA, 750AC
	CCB	A5E39272776001	PCA, 750AC
	CCB	A5E39272776003	PCA, 750AC
	CCB	A5E39272776002	PCA, 750AC
POWER BOARD	PCB	A5E37171129001	PCA, 750AC GENV POWER BOARD
POWER BOARD	PCB	A5E39414982001	PCA, 750AC GENV POWER BOARD
IGBT&DIODE	DIODE	A5E32573152	DIOD_MOD
	DIODE	A5E38625958	DIOD_MOD
	IGBT	A5E39465674	IGBT
	GCB	A5E35045443002	GCB
	IGBT	A5E39465971	IGBT
	GCB	A5E35045443003	GCB
CELL BYPASS	BYPASS	A5E37110177	BYPASS CONTACTOR ASSEMBLE
CELL BYPASS	BYPASS	A5E40727031	BYPASS CONTACTOR ASSEMBLE
WIRE KIT	BLEEDER WIRE HARNESS	A5E37707792	WIRE KIT
	WIRE KIT	A5E40742596	WIRE KIT
	WIRE KIT	A5E41408016	WIRE KIT
CAP RESISTOR	CAP SHARE RESISTOR	A5E36544578	RESISTOR
CAP RESISTOR	RESISTOR CLIP	A5E42574675	RESISTOR CLIP
G3E-8MW
Power Cell	315A CELL	A5E33723144	G3E CELL,315A, 690V	6SR3902-0AG00-0AM1
	375A CELL	A5E33723143	G3E CELL,375A, 690V	6SR3902-0AH00-0AM1
	500A CELL	A5E33723142	G3E CELL,500A, 690V	6SR3902-0AJ00-0AM1
	550A CELL	A5E32373996	G3E CELL,550A, 690V	6SR3902-0AM00-0AM1
Power Cell* U55	315A CELL	A5E34167658	G3E CELL,315A, 690V, H	6SR3902-0AG01-0AM1
	375A CELL	A5E34167656	G3E CELL,375A, 690V, H	6SR3902-0AH01-0AM1
	500A CELL	A5E34167655	G3E CELL,500A, 690V, H	6SR3902-0AJ01-0AM1
	550A CELL	A5E34167654	G3E CELL,550A, 690V, H	6SR3902-0AM01-0AM1
Cell Input Fuses	CELL FUSE	A5E33783835	G3E CELL FUSE	6SR3960-0JA00-0AM1
	CELL FUSE	A5E33783830	G3E CELL FUSE	6SR3960-0JA01-0AM1
	CELL FUSE	A5E33783816	G3E CELL FUSE	6SR3960-0JA00-0MM1
	CELL FUSE	A5E33783603	G3E CELL FUSE	6SR3960-0JA03-0AM1
Cell control board	ACCB	A5E34621797054	PCA 630/690/750V ACCB	6SR0960-0AM74-0AD0
	CCB	A1A10000432.54M	PCA 630/690/750V CCB	6SR0960-0AM26-0AD0
	CCB	A5E03545933	PCA 630/690/750V 4000M CELL CONTROL	6SR0960-0AM52-0AD0
	ACCB	A5E34621797053	PCA 630/690/750V ACCB	6SR0960-0AM73-0AD0
	CCB	A1A10000432.53M	PCA 630/690/750V CELL CONTROL	6SR0960-0AM45-0AD0
	CCB	A5E03545931	PCA 630/690/750V 4000M CELL CONTROL	6SR0960-0AM51-0AD0
HALL EFFECT	HALL EFFECT	A5E00807402	CURR TRNSDCR,CLSD LOOP	6SR0960-0AD00-0AM1
	burden resistor	A1A13000346.07	RESISTOR,HALL EFF BURD	6SR0960-1CM07-0AD0	LDZ13000346.07C
	burden resistor	A1A13000346.05	RESISTOR,HALL EFF BURD	6SR0960-1CM05-0AD0	LDZ13000346.05C
	burden resistor	A1A13000346.04	RESISTOR,HALL EFF BURD	6SR0960-1CM04-0AD0	LDZ13000346.04C
	burden resistor	A5E32402039	RESISTOR,HALL EFF BURD	6SR0900-0SM06-0AM0
Cell Bypass	BYPASS CONTATOR	A5E02610994	BYPASS CONTACTOR	6SR3960-0EA00-0AM0
	PCA BYPASS CONTROL	A1A10000416.00M	PCA W/FIRMWARE, BYPASS CONTROL	6SR0960-0EA03-0AD0
	BYPASS POWER SUPPLY	A1A363634.01	POWER SUPPLY ASSY,BYPASS,uH	6SR3960-0EA01-0AD0
	FIBER OPTIC LINK CABLE	A5E03001817	FIBER OPTIC ASSY, DUPLEX,	6SR3900-0EM00-0AM0
CAP& CAP TRAY	CAP	A5E32972596	KOND_AL_EL
CAP& CAP TRAY	CAP TRAY	A5E32348386	CAP TRAY
WIRE KIT	WIRE KIT	LDZ14500028.00	GEN3E WIRE KIT
WIRE KIT	WIRE KIT	A5E33165156	GEN3E WIRE KIT

El variador de voltaje medio refrigerado por aire de elección

Máxima eficiencia, calidad de energía y protección.

ROBICON Perfect Harmony

Respuestas para la industria.

ROBICON Perfect Harmony

Rendimiento probado refrigerado por aire

El ROBICON Perfect Harmony de media tensión refrigerado por aire

Los variadores de frecuencia (VFD) de Siemens están diseñados para

proporcionan la máxima versatilidad, eficiencia y disponibilidad del proceso.

El ROBICON Perfect Harmony GenIIIe y Gen IV refrigerados por aire

entregan características centrales sobresalientes y significativas

ventajas competitivas, como entrada de alta calidad de potencia

y salida, junto con alta disponibilidad.

Además de la versatilidad de la unidad ROBICON Perfect Harmony es

refrigeración por aire forzado disponible en GenIIIe y Gen IV. Redundante

Los sopladores son una opción para todas las unidades enfriadas por aire.

Estos sistemas de accionamiento de frecuencia variable totalmente integrados en un solo

La línea incluye el transformador de aislamiento, la electrónica de potencia y los sistemas de control y enfriamiento. No se requiere cableado en el sitio del cliente

para conectar las secciones ensambladas, y el acceso a todos los componentes es

fácil. El panel de control se abre para acceder a la energía y al motor.

conexiones, y las celdas se pueden extraer fácilmente cuando el mantenimiento es

necesario.

Características y Beneficios

La armonía perfecta de ROBICON

VFD refrigerado por aire de un vistazo

• Diseño confiable refrigerado por aire

• Entrada de energía limpia (cumple con IEEE-519)

• Factor de potencia de 0,95 en todo

rango de velocidad

• Salida sinusoidal casi perfecta

permite la adaptación a motores existentes

• La tecnología PWM multinivel significa

no se requiere motor especial

• Puede aplicarse a la inducción,

motores sincrónicos y de rotor bobinado

• Herramienta de control de la unidad (interfaz de Windows)

• Topología Perfect Harmony probada

• Opciones de alta disponibilidad para avanzados

bypass de celda (ProToPS)

• Opción para ventiladores redundantes

Bypass de celda avanzado

La función Advanced Cell Bypass permite

el ROBICON Perfect Harmony refrigerado por aire

unidades para permanecer operativas en caso de

una falla celular al pasar por alto una celda averiada.

Dependiendo del requisito del proceso y

la configuración del variador de frecuencia,

una falla de celda podría tener un mínimo o ningún

impacto en el proceso; la salida del motor

la calidad de la energía permanece dentro de los límites definidos

directrices.

Mentalidad de ProToPS Process-First

Proceso de ROBICON Perfect Harmony

Estrategia de protección tolerante (ProToPS)

proporciona un sistema jerárquico de

advertencias que mantienen ROBICON Perfect

Accionamientos Harmony refrigerados por aire en línea y

en control de su proceso. Viajes en coche

y las interrupciones del proceso solo ocurren

en circunstancias extremas. PROTOPS

da tiempo al operador para

evaluar una perturbación de VFD y responder

apropiadamente para evitar el apagado del sistema.

Datos técnicos de un vistazo:

Especificación

Conexión de suministro de línea

• Voltaje de línea: 2,3 a 13,8 kV + 10% / –5%

• Frecuencia: 50/60 Hz +/– 2,5 / 3,0 Hz

• Factor de potencia de línea:> 0,95

• Entrada de cable superior o inferior

Conexión motor

• Voltajes del motor:

- GenIV 2,3 a 6,6 kV

- GenIIIe 2,3 a 7,2 kV

• Entrada de cable superior o inferior

Calidad de energía

• Eficiencia del convertidor (sin transformador):> 98,5%

• Eficiencia total del sistema VFD:> 96,5%

Voltaje auxiliar

• 380 V / 50 Hz, 400 V / 50 Hz, 415 V / 50 Hz *

• 460 V / 60 Hz, 480 V / 60 Hz *

Rectificador de lado de línea

• Transformador de aislamiento integrado con aluminio

o bobinados de cobre opcionales

• Rectificador de diodo de 18 pulsos mínimo sin

retroalimentación regenerativa

Inversor del lado del motor

• Topología PWM de varios niveles

• Celdas de potencia LV-IGBT

Enfriamiento

• Refrigerado por aire forzado con opcional

ventiladores redundantes

Grado de protección

• NEMA 1 / IP21, opcional hasta IP42

Condiciones ambientales

• Temperatura: 0–40 ° C (32–104 ° F), hasta 50 ° C

(122 ° F) con reducción de potencia

• Altitud de instalación: hasta 1000 m (3300 pies) y

hasta 4000 m (13.200 pies) con reducción de potencia

• Humedad: <95% sin condensación de humedad

* otros están disponibles opcionalmente

Funciones de seguridad (no completas)

• Protección contra cortocircuitos y fallas a tierra

• Protección contra sobrecorriente, sobrevoltaje y bajo voltaje

• Protección contra pérdida de voltaje de línea

• Protección contra sobrecalentamiento (VFD y motor)

• Protección contra sobrevelocidad y bloqueo (motor)

• Monitorización del circuito de refrigeración

• Autodiagnóstico de celdas de control y potencia

Controlar

• Control V / Hz sin codificador de velocidad

• Control vectorial con y sin codificador de velocidad (opcional)

• Precisión de velocidad: +/– 0,1% con codificador de velocidad,

+/– 0,5% sin codificador de velocidad

• Precisión de par: +/– 2%

• Rango de debilitamiento del campo 1: 3

• Frecuencia de salida máxima: 330 Hz

(por encima de 167 Hz con reducción de potencia)

E / S de control

• Entradas analógicas: 3 *

• Salidas analógicas: 2 *

• Entradas digitales: 20 *

• Salidas digitales: 16 *

• Codificador de velocidad (opcional)

• Comunicación: Modbus, opcional: DeviceNet, PROFIBUS,

Red de control *

Normas

• NEMA, IEC, CE, UL, CSA

Selección de opciones adicionales

• Sistema de protección tolerante al proceso ProToPS

• Ventiladores redundantes

• Bypass de celda avanzado

• Filtro EMC

• Calentador anticondensación

• Aumento de la clase de protección hasta IP42

• Sistemas de enclavamiento con llave

• Conducto con bridas para conexión a un sistema de escape externo

• Módulos de E / S adicionales

• Comunicación en serie con varios sistemas de bus

• CoInstrumentos de control y visualización en la puerta.

• Conectores de puerto Ethernet y / o RS232

• Monitorización PT100 (devanados y cojinetes del motor)

• Descargadores de sobretensión de clase de distribución (transformador)

• Seccionador de puesta a tierra de entrada y salida

• Estrangulador para longitudes de cable largas

* adicional usando módulos opcionales

Tensión del motor 3,3 kV

Salida

Actual

[UN]

Tipo

clasificación

[kVA]

Salida del eje

[kW] [CV]

Transformador

[kVA] Número de pedido (MLFB) Número de generación de

contorno de celdas

40225189254300 6SR4102-0 [] A33-0 [] [] 0 GenIV 9 A

70400331444450 6SR4102-0 [] B34-5 [] [] 0 GenIV 9 A

100 570473634700 6SR4102-0 [] C37-0 [] [] 0 GenIV 9 A

140 800 662 887 900 6SR4102-0 [] D38-7 [] [] 1 GenIV 9 A

200 1140970 1300 1500 6SR4102-0 [] E41-5 [] [] 0 GenIV 9 A

260 1485 1261 1690 1750 6SR4102-0 [] F41-7 [] [] 0 GenIV 9 A

315 1800 1527 2047 2250 6SR3102-1 [] G42-2 [] [] 0 GenIIIe 9 B

375 2140 1818 2437 2500 6SR3102-1 [] H42-5 [] [] 0 GenIIIe 9 B

500 2855 2424 3250 3500 6SR3102-1 [] J43-5 [] [] 0 GenIIIe 9 B

Voltaje del motor 4.0 / 4.16 kV

Salida

Actual

[UN]

Tipo

clasificación

[kVA]

Salida del eje

[kW] [CV]

Transformador

[kVA] Número de pedido (MLFB) Número de generación de

contorno de celdas

40 275 229 307 400 6SR4102-0 [] A34-0 [] [] 0 GenIV 9 A

70480401538600 6SR4102-0 [] B36-0 [] [] 0 GenIV 9 A

100 690 573 768 800 6SR4102-0 [] C38-0 [] [] 0 GenIV 9 A

140965802 1075 1100 6SR4102-0 [] D41-1 [] [] 0 GenIV 9 A

200 1385 1175 1576 1750 6SR4102-0 [] E41-7 [] [] 0 GenIV 9 A

260 1800 1528 2048 2250 6SR4102-0 [] F42-2 [] [] 0 GenIV 9 A

315 2265 1925 2581 3000 6SR3102-3 [] G43-0 [] [] 0 GenIIIe 12 B

375 2700 2292 3073 3500 6SR3102-3 [] H43-5 [] [] 0 GenIIIe 12 B

500 3600 3056 4097 5000 6SR3102-3 [] J45-0 [] [] 0 GenIIIe 12 B

630 4540 3851 5162 6000 6SR3102-3 [] K46-0 [] [] 0 GenIIIe 12 B

Voltaje del motor 6.0 kV

Salida

Actual

[UN]

Tipo

clasificación

[kVA]

Salida del eje

[kW] [CV]

Transformador

[kVA] Número de pedido (MLFB) Número de generación de

contorno de celdas

40 415 344 461500 6SR4102-2 [] A35-0 [] [] 0 GenIV 15 C

70725602807900 6SR4102-2 [] B38-7 [] [] 0 GenIV 15 C

100 1035860 1152 1250 6SR4102-2 [] C41-2 [] [] 0 GenIV 15 C

140 1450 1203 1613 1750 6SR4102-2 [] D41-7 [] [] 0 GenIV 15 C

200 2075 1763 2363 2500 6SR4102-2 [] E42-5 [] [] 0 GenIV 15 C

260 2700 2292 3073 3500 6SR4102-2 [] F43-5 [] [] 0 GenIV 15 C

315 3270 2777 3722 4000 6SR3102-5 [] G44-0 [] [] 0 GenIIIe 15 B

375 3895 3306 4432 5000 6SR3102-5 [] H45-0 [] [] 0 GenIIIe 15 B

500 5195 4408 5909 6000 6SR3102-5 [] J46-0 [] [] 0 GenIIIe 15 B

630 6550 5554 7445 8000 6SR3102-5 [] K48-0 [] [] 0 GenIIIe 15 B

Tensión del motor 6,6 kV

Salida

Actual

[UN]

Tipo

clasificación

[kVA]

Salida del eje

[kW] [CV]

Transformador

[kVA] Número de pedido (MLFB) Número de generación de

contorno de celdas

40455378507 600 6SR4102-2 [] A36-0 [] [] 0 GenIV 15 C

70 800662 887900 6SR4102-2 [] B38-7 [] [] 0 GenIV 15 C

100 1140 946 1268 1500 6SR4102-2 [] C41-5 [] [] 0 GenIV 15 C

140 1600 1324 1775 2000 6SR4102-2 [] D42-0 [] [] 0 GenIV 15 C

200 2285 1939 2600 3000 6SR4102-2 [] E43-0 [] [] 0 GenIV 15 C

260 2970 2521 3380 3500 6SR4102-2 [] F43-5 [] [] 0 GenIV 15 C

315 3600 3055 4095 5000 6SR3102-7 [] G45-0 [] [] 0 GenIIIe 18 B

375 4285 3636 4875 5000 6SR3102-7 [] H45-0 [] [] 0 GenIIIe 18 B

500 5715 4849 6500 7000 6SR3102-7 [] J47-0 [] [] 0 GenIIIe 18 B

615 7040 5968 8000 8000 6SR3102-7 [] K48-0 [] [] 0 GenIIIe 18 B

A: GenIV_4.0 / 4.16 kV C: GenIV_6.0 / 6.6 kV

Salida

Voltaje

Longitud del gabinete del motor

Dimensionamiento del gabinete del sistema

Altura del gabinete Profundidad del gabinete Altura de la jaula del ventilador

[kW] [hp] mm pulgada mm pulgada mm pulgada mm pulgada

4.0 / 4.16 kV

148–814 200–1100 1676 66

3100 122

1067 42 610 24

925–1665 1250–2250 2083 82

1250 45

838 33

6.0 / 6.6 KV

222–925 300–1250 3658 144696 27,5

1110–2590 1500–3500 4166 164 787 31

Salida

Voltaje

Longitud del gabinete del motor

Dimensionamiento del gabinete del sistema

Altura del gabinete Profundidad del gabinete Altura de la jaula del ventilador

[kW] [hp] mm pulgada mm pulgada mm pulgada mm pulgada

3,3 kV

1295–1850

2220–2960

1750-2500

3000–4000

4369 172

2324 91,5

1270 50

673 26,5

4775 188

4 kV

1480–1850 2000–2500 4878 192

2220–2960 3000–4000 5283 208

3700–4440 5000–6000 5893232

6 kV

1665–1850 2250–2500 5893232

1372 54

2220-2960

3700–4440

3000–4000

5000–6000

6299

6909

248

272

5180 7000 6909 272 2527 99,5

6,6 kV – 7,2 kV

1850 2500 5893232

2324 91,5 2220–2960

3700–4440

5180–5920

3000–4000

5000–6000

7000–8000

6299 248

6909 272

6909 272 2527 99,5

B: GenIIIe

Siemens AG

Sector industrial

Unidades grandes

CORREOS. Recuadro 47 43

90025 NÜRNBERG

ALEMANIA

www.siemens.com/robicon-perfect-harmony

Sujeto a cambios sin previo aviso

No de pedido: E20001-A30-P590-X-7600

Dispo 21503

21/16984 GD.LD.XX.SIGM.52.9.03 WS 11083.

Impreso en Alemania

La información proporcionada en este folleto contiene meramente

descripciones o características de desempeño que en el caso real de

el uso no siempre se aplica como se describe o que puede cambiar como resultado

de un mayor desarrollo de los productos. Una obligación de proporcionar el

respectivas características sólo existirán si se acuerda expresamente en el

términos del contrato.

Todas las designaciones de productos pueden ser marcas comerciales o nombres de productos de

Siemens AG o empresas proveedoras cuyo uso por parte de terceros para su

propios fines podrían vulnerar los derechos de los propietarios.

Previous : Siemens Robicon GH180 Medium Voltage Converter CAP A5E32972596 CAP TRAY A5E32348386 Capacitor Next : BYPASSPOWERSUPPLY A1A363634.01 6SR3960-0EA01-0AD0 FIBEROPTICLINKCABLE A5E03001817 6SR3900-0EM00-0AM0

Copy product links

Long by picture save/share

BYPASS CONTATOR A5E02610994 6SR3960-0EA00-0AM0 PCA BYPASS CONTROL A1A10000416.00M 6SR0960-0EA03-0AD0

INQUIRY

Inquiry MORE+

Inquiry Content：

You have no items to require

Add Successfully

Continue To Visit Inquiry Now

We are the world's leading supplier of spare parts for medium voltage drives of various brands

GET IN TOUCH

East Sun Industrial Centre, No 16 Shing Yip Street Kl, Hongkong

Call us : +852 5261 7322

Email us : [email protected]

SITEMAP

分类标题

BUSINESS HOURS

Monday to Friday : 9 am to 6 pm

Saturday : 9 am to 12 am

Sunday : Closed Support Hours in 24/7 Everyday

DISCLAIMER:

We are not an authorized distributor, reseller or representative of the following products presented on this website. All Product names and logos throughout this site are trademarks of their respective holders. Use of them DOES NOT imply any affiliation with or endorsement by them.

Cancel

添加微信好友，详细了解产品

使用企业微信
“扫一扫”加入群聊

复制成功

添加微信好友，详细了解产品

我知道了

BYPASS CONTATOR A5E02610994 6SR3960-0EA00-0AM0 PCA BYPASS CONTROL A1A10000416.00M 6SR0960-0EA03-0AD0

BYPASS CONTATOR A5E02610994 6SR3960-0EA00-0AM0 PCA BYPASS CONTROL A1A10000416.00M 6SR0960-0EA03-0AD0

分享至微信
